LBT-1-GPS

OPERATION MANUAL

BAIT BOAT FISHING FINDER

GPS+COMPASS+SONART

Table of Contents

Need help?

Do you have a question about the LBT-1-GPS and is the answer not in the manual?

Questions and answers

Summary of Contents for LUCKYSMART LBT-1-GPS

Page 1 LBT-1-GPS OPERATION MANUAL BAIT BOAT FISHING FINDER GPS+COMPASS+SONART...
Page 2 Preface LUCKYSMART Thanks for choosing products. In order to operate this product quickly and safely,Please read this manual carefully before operating. LUCKYSMART always follows the strategy of continuous development. Therefore, LUCKYSMART reserves the right to modify and improve the products description LUCKYSMART in the document without previous notice.
Page 3 Precautions 1. Safety precautions ・Do not use this product in harsh environments such as wind, rain, lightning,and high-voltage lines. Electronic equipment ・Do not use this device in places where the use of wireless devices is clearly pro- hibited. otherwise.It may interfere with other electronic equipment or cause other dangers.
Page 4: Table Of Contents
Contents Product introduction Product packing list Installation Install the probe Install GPS receiver Install the antenna Connect cable Power User Guide Precautions 13-14 Screen display description Electronic compass key operation Go to waypoint navigation How to create a waypoint How to set a waypoint as a target point How to set the name and icon of the waypoint How to know the distance of the boat from the shore and the target point...
Page 5 Clutter suppression Sonar tones Chart Speed System Language Backlight Alarm Fish Alarm Shallow alarm Arrival alarm Offcourse Alarm Display Voltage Alarm Boat Voltage Alarm Units Measurement Unit Sonar units Time setting Format Direction setting Factory set About 25-30 Common problems and solutions...
Page 6: Product Introduction
Product introduction LBT-1-GPS is an electronic product that integrates GPS navigation and sonar systems that is specially used for various remote control bait boats and other sm- all boats. This product combines sonar, GPS navigation and electronic compass functions. No matter if you are a new hand or a professional angler, It is easy to use this pro- duct .
Page 7: Product Packing List
Product packing list Device GPS receiver 1)GPS receiver 2)Double-side tap Launcher Probe 1)Device power cable-(Dry battery) 1)Probe 2)Lock knob 3)Rubber sleeve 2)Device power cable-(Storage battery) Note: Different rubber sleeves are ma- 3)Control box power cable tched according to different boat types. 4)Control box 5)Antenna extension line 6)Control box antenna...
Page 8: Install The Probe
Installation to bait boat 1.Install the probe Warning: Please do not install the probe near the motor of the boat. Otherwise, the electronic noise caused by the motor and the bubbles generated by the prope- ller will greatly degrade the sonar performance of the product. Generally recom- mended to install at a distance from the bow of boat that the position of 1/3 of the length of the bait boat.
Page 9 2） A bait boat with a groove for installing the probe in the hull (No. 2 rubber sleeve) There is a groove at the bottom of the bait boat for installing probes. LBT-1-GPS comes with aappropriative No. 2 rubber sleeve . The installation steps are basical- ly the same as in 1 above.
Page 10 probe installation Introduction Probe Lock knob No. 3 rubber sleeve 1) Use a screwdriver to remove the probe decorative cover from the bottom of the ship. 2) Assemble the probe and ru- bber pad, and pass the assem- bled probe through the probe hole.
Page 11: Install Gps Receiver
1) Choose an appropriate location on the boat (the location is flat, normally fixed on the head of the boat) 2) Fix the GPS receiver on the bow with double-sided tape (Note: For LBT-1-GPS, the gray arrow must be consistent with the bow direction).
Page 12: Install The Antenna
3.Install the antenna of control box 1) Find the hole reserved for installing the antenna extension cable at the stern of the bait boat. 2) Remove the nut and washer on the antenna extension cable. 3) Pass the screw part of the antenna extension cable through the reserved hole from the cabin.
Page 13: Power
Power Device power Control box power Recommended voltage 10-13V 9.5-13V Maximum voltage 16.8V 1.The device can use 8*AA batteries or an external power supply. -When using 8*AA batteries for power supply, please discharge the batteries cor- rectly according to the schematic diagram on the base of the device. -When using an external power supply, you can use the standard power cord to connect it to an external power.
Page 14: Precautions
How to use Precaution Please use this product when the satellite status bar shows yellow or blue (mea- ning the GPS signal is strong enough) Red: 0-3 satellites Yellow: 4-6 satellites Blue: more than 6 satellites Note: If the number of satellites column all turn blue, it means that the product has recei- ved signals from 12 satellites.
Page 15 Arrow represents north waypoint Distance from boat to the target waypoint Compass Distance from bait boat to device Compass GPS receivers have a built-in electronic compass system. When you correctly in- stall the GPS receiver on the boat, you can know the heading of the bow at any time by observing the pointer of the electronic compass on the screen.
Page 16: Key Operation
Key operation Menu key/Power key Return key 1） Power on/oﬀ Return to the previous menu 2） Menu selection Arrow key Conﬁrm key 1) Complete menu selection 1) Move to select an option 2) Conﬁrm settings 2) Increase or decrease option value Zoom in/out key Used to zoom in or zoom out the GPS track map...
Page 17: Go To
Go to Waypoint navigation The waypoint refers to the location that the fisherman prefers personally in a cert- ain fishing area. These points may be the usual make bait, may also be judged wh- ere there are more fish based on past experience. Or a place where big fish often haunt, etc.
Page 18: How To Set A Point As The Origin
How to know the distance of the boat from the shore and the target point You can see an option [Home pos.] on the display. This option represents the distance from the boat to the origin. Note: This product defaults to the point of origin when the GPS receiver is powered on.
Page 19: Route Navigation
Route navigation List of all saved tracks. How to create a new route 1)When the boat sails for a certain distance from the origin, you can observe the corresponding track on the screen. At this time, you can choose to save this track as a route: 1) Press the MENU button to enter the [Go To] menu, select [Course] and press the ENTER...
Page 20: Menu Operation
Menu operation Sonar settings Sensitivity Sensitivity is the sonar intensity. The stronger the sensitivity, the more sonar signals will be returned and displayed on the screen, and the more sensitive feedback from the underwater situation will be. But if the water is very shallow, too high sensitivity will also increase the reflected sound wave signal too much, resulting in the wrong signal being displayed.
Page 21 Sonar color The sonar color is used to change the display color of the sonar image, which can better distinguish underwater, fish, etc. Sonar colors are available in red, blue and gray. Chart speed Set the frequency of sonar data sampling. Note: The more frequently the sonar data is collec- ted, the more accurate the underwater situation di- splayed on the screen.
Page 22 System Language Language setting is to switch the languages of different countries. Under this menu, you can choose your pr- eferred language (Chinese and English 2 languages). Backlight The backlight is to adjust the screen brightness. Alarm Fish alarm Fish alarm refers to the alarm set when different fish icons appear.
Page 23 Arrival alarm Arrival alarm means that when the distance between Alarm Alarm the boat and the target point is less than or equal to the preset value, the device will make an alarm. At the same time, a prompt message will be displayed on the screen: "Approching the target position".
Page 24 Oﬀcourse Alarm Offcourse means that when the boat deviates from the preset route, the device will make an alarm. At the same time, a prompt message will be displayed on the screen: "The route deviated". Main voltage When the main device power supply voltage is lower than the set value, the fish finder will make an alarm.
Page 25 Sonar unit Set the unit of depth and temperature. Timezone Please choose a different time zone in different coun- tries (regions), For example: China: 8 Germany, France, Netherlands, Italy, Poland: 1 Bulgaria, Romania, Ukraine, Greece: 2 Russia: 3 For more time zone, please refer to: http://www.worldtimezone.com Format Set the unit used to determine latitude and...
Page 26 Common problems and solutions Problems Solutions 1)Please turn on the sensor first, and then turn on the Screen display : device. Otherwise, this message will be displayed on "Please turn on the screen. the sensor" 2)Please ensure that the radio environment is in good condition.
Page 27 Problems Solutions 1)The compass will malfunction due to magnetic ma- terials. Therefore, when installing the GPS receiver, keep away from the following magnetic materials: ma- gnets, iron, nickel, etc. The distance is recommended The compass does to exceed 30 cm. not indicate the right direction 2)The accuracy of the electronic compass is usually...
Page 28 Problems Solutions All sonar equipment has 2 blind spots. A blind spot is 0.5 meters down from the surface of the water. Anoth- er blind spot is 0.3 meters from the bottom of the water. No ﬁsh detected If the fish is in the blind spot, the fish finder is difficult (Clear that there are ﬁsh in the water) to detect.
Page 29 Product Speciﬁcation Circular error probability: 2.5m GPS positioning accuracy Actual measurement accu- racy: 1.0m Waypoint Track Wireless frequency 433MHz GPS and wireless Wireless operating range 300m functions Show boat speed Show latitude and longitude 50 channels Update rate: 1 second Hot start <1 second (in open Satellite environment)
Page 30 Product Speciﬁcation GPS receiver cable length 0.7m Others Probe cable length 0.6m Operating temperature range -10°~ 50°C The following data can be displa- yed: distance to the target point, distance to the origin, boat speed, GPS data display time to reach the target, number of satellites, azimuth, angle, track memory, date, device voltage, etc.
Page 31 Product Speciﬁcation The fish shape recognition function can define the display level of the fish school size, so as to meet the purpose of fishing friends to catch only big fish or only small fish. Digital The detected fish-shaped symbol can visually display the depth Sonar position of the fish.
