AquaLighter 30 Quick Manual

Fig.1 1. LED illumination lamp AquaLighter 2
2. Driver current
3. Foot mounting
4. Switch
AquaLighter 2 Illumination Lamp User Manual Guide
Dear Sir and Madam,
We thank you for choosing our product. We assure you that you will be
satisfied with the work of this illumination lamp. Please, study this User
Manual Guide before use in order to avoid problems connected to its usage.
Intended Use and Specifications of the Product
AquaLighter 2 LED illumination lamp is designed to function over the water
surface and is used for illumination of the freshwater aquariums. The
movable feet allow you to use the illumination lamp for aquariums of different
length. The source of illumination of the lamp is bright LEDs produced by
CREE (USA). The power supply is by current LED drivers. The illumination
lamp can be used for aquariums with a wall thickness of up to 12 mm.
Technical characteristic
Types:
30
Parameters:
Voltage + frequency AC 110~230V (50-60Hz) / DC~ 48V, 380mA
Light temperature, K 6500-7000
Power, Watt 11
Luminous flux, Lum 1080
Length, mm 300
Ingress protection rating - IP67
Safety Usage Rules
The device you have purchased is manufactured in compliance with the
norms applicable on the territory of Ukraine and the European Union. For
long lasting and safe usage, please do study the safety rules listed below:
1. This device is designed to be used only within indoor areas and only for its
intended use.
2. The voltage rating of the power supply system has to be exactly the same as
the voltage rating indicated on the device.
3. This lamp is protected against moisture (degree of protection IP67). The
device can withstand short-term immersion in water without loss of capacity.
In the case of contact of the device with water, wipe the water off the surface
and wait until the device is dry before operating.
5. It is forbidden to repair or change the electrical cord as well as install extra
elements on it. If the electrical cord of the device was damaged, contact
technical support.
6. Before you switch on the illumination lamp, please make sure it is fixed
safely on the walls of the aquarium.
Preparation for Work
Fasten the feet on the body of the illumination lamp as shown in Fig. 1.
To mount the lamp under the aquarium cover, fix it with special fittings
(supplied) as shown in Fig. 2.
Assembly and Startup
Place the illumination lamp on the aquarium, moving the feet along the body
Fig.2
of the device until you reach the necessary length. Having fixed the
illumination lamp safely on the walls of the aquarium, plug in the plug of the
power supply block into the socket driver current on the illumination lamp.
The device is ready to use. Connect the power supply block to the power
supply system. Turn on the switch on the body current driver.
Maintenance
The device does not require any special maintenance. If necessary, clean off
residues resting on the body of the illumination lamp with the help of soft
tissue or a sponge.
Dismantling and Utilization
You cannot dispose of electrical appliances that are out of order into regular
garbage. Proper selection, collection, and utilization of this type of waste will
contribute to preserving the valuable resources of the environment.
The user is held liable for delivery of the used equipment to the special
collecting point, where it will be accepted free of charge.
Warranty
The manufacturer gives a warranty of 24 months from the purchase date.
The warranty covers damages that appeared due to the fault of the
manufacturer, i.e., material defects, etc. The warranty does not cover
damages that appeared due to the improper or unintended use of illumination
lamp.
Attention! Any trials to change the structure of the device, or dismantling of
the device, that fall out of the scope of regular intended use or maintenance
60 90
lead to loss of warranty obligations.
In case improper functioning of the device is detected, contact technical
support. The warranty shall be considered valid if the date of production
22 33
indicated on the product coincides with the date of production in the warranty
2160 3240
paper. The present warranty conditions do not exclude, limit, or cease the
600 900
rights of the buyer granted by the applicable legislation of the country where
the sale was made.
YOUR
LED LAMP
FOR AQUARIUM
Aquarium comes alive!
30 cm
60 cm
90 cm
www.aqualighter.com
