BRN DISPLAY 500 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DISPLAY 500
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for BRN DISPLAY 500

Summary of Contents for BRN DISPLAY 500

  • Page 1 DISPLAY 500 USER MANUAL...

  • Page 2: Table Of Contents

    Contents About the user manual ..................... 2 Material and external dimensions ..................2 Real product and dimension figure :(unit: mm)................2 Function summary ......................3 Button function ........................ 5 Normal operation ......................6 (1). On/off function ........................6 (2). Display interface ........................8 (3).
  • Page 3 Figure 2...

  • Page 4: Function Summary

    3. Function summary 500 is a Multifunctional display. 500 function Summary(Figure 3-1) ◆ Kilometers or miles scale selection ◆ Current speed indication ◆ Rotational informations: Total distance indication, Riding distance indication, Time (Hours:Minutes) ◆ Backlight indication (switch backlight) ◆ PAS level selection, Error code definition ◆...

  • Page 6: Button Function

    Display during use(without backlight)（figure 3-3） Figure 3-3 Display during use(with backlight)（figure 3-4） Figure 3-4 The display could be the left and right hand type according with bike manufacturer choice. Button function 500 has two buttons including ON/OFF/UP and SET/DOWN.（figure 4）...
  • Page 7 Figure 4 Pressing the ON/OFF/UP button for 3 seconds you can turn the system on Once the system is ON, pressing shortly the UP button means to shift to higher assistance levels. Pressing the UP button for 3 seconds shut the system off. Pressing the SET/DOWN button shortly means to shift to lower assistance levels.

  • Page 8: Normal Operation

    5.Normal operation To switch on the system first you have to switch one the battery. Than you can operate the commands on the display trough buttons. The system will start in 0 assistance mode. It means that the system will not start if you push the pedals.
  • Page 9 Figure 5-1 Distance is shown in figure 5-2 as ODO, Distance from the last Switch On is showed as TRIP. Figure 5-2 Pedal assistance level is shown in figure 5-3. Figure 5-3...

  • Page 10: Turn On (Off) Backlight

    Battery capacity is shown in figure 5-4.( The remaining power 2 out 5,it means 40% of the battery capacity is remained) Figure 5-4 (3)Turn on (off) backlight Clicking button together with , and after the display initializing for 3s , the light starts to work.

  • Page 11: Battery Indication

    Figure 5-5 (5) Battery indication There will be five bars shown on the screen if the battery capacity is very high enough. The less bars will show on the screen if the capacity of the battery is less. When the battery is almost dead, the last bar will flash. You need to charge the battery immediately.

  • Page 12: General Setting

    Figure 5-7 6.General setting (1) Speed unit setting, km/h and mph switching When the display is power on, you can hold buttons for 10s to enter into the speed unit settings interface. You can change the speed unit to kilometers or miles by clicking button.( It will return to the main operation interface if you doesn’t click any button in 5s).

  • Page 13: Warnings

    Battery of the system should be charged once the display show that it is at lower level or when the system shut off because out of current. Charge periodically (at least every 2 weeks) the battery. Keep the battery at least 50% charged when the bike will be left for long time not used.
