  • Page 1 SMART POT EKO User guide. Please make sure to read this User Guide prior to using your unit.
  • Page 2 Contents. Welcome. Before you begin. Important safeguards & cautionary information. What's included. Cooker parts overview. Getting started. Open and close lid. Install and remove sealing ring. Install and remove pressure release valve. Install and remove float valve. Install and remove anti-block shield. Install condensation collector.
  • Page 3 Welcome to team nutricook ® Life is complicated. Eating healthy doesn’t have to be. There’s really no easier way to streamline your healthy lifestyle than with this mighty appliance. We are constantly working to create recipes that are EASY. DELICIOUS. NUTRITIOUS.
  • Page 4 Before you begin. • Remove all packaging materials from in and around the cooker and verify that all parts are accounted for. • Place the cooker on a stable, level surface, away from external heat sources. • Read all Important safeguards and cautionary information in this User guide.
  • Page 5 Building a smoothie. Important safeguards & cautionary information. Warning! This appliance cooks with pressure. To avoid the risk of serious injury, carefully read all instructions before operating this appliance. When using any electrical appliance, basic safety precautions should always be observed, including the following critical information.
  • Page 6 Only use accessories like pressure cooking lid, sealing rings and • CAUTION: The inner pot can be heavy when filled with food. inner pots authorized by nutricook to reduce the risk of any ® Extreme caution must be observed when taking out the inner pot damage and injury.
  • Page 7 ELECTRICAL SAFETY ELECTRICAL INFORMATION: For safety reasons, the cord length of this appliance was selected to CAUTION: To avoid risk of electric shock, never immerse the cord, reduce Safety Hazards that may occur with a long cord. Extension plug, or cooker base in water or other liquids. cords are available and may be used if care is exercised in their use.
  • Page 8 What's included. • 1000 WATT COOKER BASE • STAINLESS STEEL COOKING POT • STEAM RACK • SOUP SPOON • RICE PADDLE • MEASURING CUP • USER GUIDE Product Specification: MODEL CAPACITY POWER VOLTAGE WEIGHT DIMENSION SMART POT 220-240 V 1000 W 5.4 kg 32.5x32.3x37.36 cm 50/60 Hz...
  • Page 9 Cooker parts overview. top of lid inner pot float valve pressure release valve stainless steel inner pot lid handle lid marker cooker base bottom of lid handle cooker base rim sealing ring rack sealing ring control panel locking pin float valve silicone cap anti-block shield rice spoon...

  • Page 10: Getting Started

    Getting started. Find delicious recipes online at: nutricookworld.com nutricookworld...
  • Page 11 *NOTE: It is recommended to have more than one sealing ring. The sealing ring is an integral part of product safety. Close: Grip handle and lower Only use authorized nutricook sealing ® down the lid to cooker base remove ring or Replace your sealing ring every rim.
  • Page 12 Install and remove Install and remove pressure release valve. float valve. Install: Position pressure When pressure builds up inside your release valve on pressure cooker, the float valve pops up. This release hole and press down. indicates the cooker is pressurized and prevents you from opening the lid.
  • Page 13 Install and remove Install condensation anti-block shield collector. Install: The anti-block shield safely prevents On back of cooker base , align grooves of the condensation food from entering the pressure collector over tabs and push condensation collector until it locks into release hole to avoid blockage and place.

  • Page 14: Venting Methods

    (e.g. porridge, stews, sticky liquids, The inner pot is an integral part of product safety. Always use an soup, etc.). Food content may spatter authorized nutricook inner pot made for this model when cooking. out from the pressure release valve.

  • Page 15: Control Panel Details

    Control panel details. Natural Release (NR): Leave the pressure release valve in the Sealing position. The cooker dissipates heat so pressure releases naturally overtime. 3. Allow cooker to cool down naturally until the float valve drops down. This may take 10 to 15 minutes or even longer, depending on the SOUP RICE ‫ﺣﺴﺎء‬...

  • Page 16: Smart Features

    Smart features. Time Controls. to increase cooking time – to decrease cooking time Auto-Save Cooking Mode and Time. Hour/Min Hour Minute to select between field depending on the time that needs to be adjusted. The selected field blinks. For Pressure Cooking Programs: Note: Hour/Min is not applicable for Sauté.
  • Page 17 Auto keep warm. Once cooking begins, the adjusted time will be automatically saved to the selected cooking program and cooking mode and overrides Sauté and Yogurt, the Keep During program selection except for the factory default settings. The next time you select the same cooking Warm indicator light automatically illuminates.
  • Page 18 Restore smart cooking programs original settings. Display message when Rice program is running and Preheating under cycle. Smart Cooking Programs To restore the original settings of the Smart Cooking Program individually, press and hold the button of the you wish to restore when the cooker is on standby mode until cooker Hour and Minute indicator (First two digits refer to beeps.

  • Page 19: Initial Test Run

    Smart Cooking Programs Initial test run. Table. In order to familiarize yourself with the Smart Pot and start cooking with your favourite recipe, it is highly recommended for first time users to do a test run. This optional but recommended test run will complete in about 15 minutes.
  • Page 20 Sauté. Keep Warm 13. When the time has been completed and function is turned off, screen displays and beeps 5 times. Note: If Auto Keep Warm is activated, the cooker goes to Keep Sauté • is a non-pressure cooking program which can be used in Warm mode immediately after the cycle and counts up from place of pots and pans for simmering, browning and searing.

  • Page 21: Pressure Cooking Programs

    Pressure cooking 9. When maximum temperature is reached, screen displays 10 seconds followed by the countdown time. Note: programs. • Ensure you add your ingredients on the inner pot immediately once Hot is displayed to avoid overheating. 10. When cooking time has been completed, screen displays and beeps 5 times.
  • Page 22 Remove the inner pot from the cooker base. Cooking Cooking Suggested Venting Notes 3. Add food including the liquid ingredients in the inner pot. Programs Modes Method Note: • For pressure cooking programs, do not fill the inner pot Moist cake Press Cake/Adjust button repeatedly higher than the MAX line.
  • Page 23 Slow cook. after the pressure cooking time has been completed. If you wish Auto Keep Warm Keep Warm to turn off the function, press the button. The indicator light goes off. Note: Slow Cook program does not use pressure during the cooking You can deactivate the Auto Keep Warm function during •...
  • Page 24 Yogurt. Note: Refer to the Smart Cooking Programs Table for the default • time for each cooking mode including the adjustable time range. This is a non-pressure cooking program which is used for making Slow Cook Auto Keep Warm Yogurt. It involves two steps – Pasteurizing Milk and Culturing Yogurt. 11.

  • Page 25: Care And Maintenance

    Care & maintenance. Note: When Yogurt function is set to High mode, no time • adjustments can be made. START 9. Press button to begin cooking. Note: If START button is not pressed after program settings, the • cooker automatically begins cooking after 10 seconds. WARNING: 10.

  • Page 26: Troubleshooting

    Troubleshooting. Cleaning Methods Issue Possible Cause Solution Part Cleaning Tip Dishwasher Hand Wash Wipe Clean The sealing ring is not properly Check the position of the sealing ring and ensure Safe (submerged) (damp cloth) installed it is properly installed in the sealing ring rack. Difficulty closing lid.

  • Page 27: Warranty

    EXCLUSIONS AND LIMITATIONS This Nutricook Two-Year Limited Warranty applies only to Nutricook products distributed by or for Nutricook that can be identified by the “Nutricook” trademark, trade name, logo and bar code. Nutricook’s Two-Year Limited Warranty does not apply to any other products that may appear to be authentic, but were not distributed/sold by Nutricook.
  • Page 28 Repair or replacement of the product (or, if repair or replacement is not feasible, a refund of the purchase price) is the exclusive remedy of the consumer under this limited warranty. Nutricook shall not be liable for any incidental or consequential damages for breach of this limited warranty or any implied warranty on this product.
  • Page 29 SMART POT EKO nutricook | www.nutricookworld.com | All rights reserved. ® Illustrations may differ from the actual product. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice. NC-SP104-IM...
