5 Using UnipicK+™
5.1 Terminology
Starting position:
Home position:
Standby position:
5.2 Power
To turn power on, turn the black switch on the back panel of the Control Box. At this point the
screen and a green indicator light will turn on (Figure 2). To turn off the unit, press the switch
again.
Highest vertical position for the DCU; the initial position when the
unit is first turned on and capillary has been mounted or after it is
reset.
Calibration of Collecting/Dissecting or Dispensing position of the
DCU tip determined by the user. Homing is performed prior to
every collection/dissection and dispensing procedure.
1 mm above the Home position for Acquisition mode. DCU will
be lifted to Standby position after each single acquisition or
dispensing event. DCU returns to Standby position after each
sampling until the Home position (Acquisition plane or Dispensing
plane) or the system has been reset.
7
