- Page 1 ELECTRIC CONVECTOR WITH A POSSIBILITY OF MOUNTING LEGS MODEL TX , T17 OPERATION INSTRUCTIONS...
- Page 2 2. GENERAL This manual is designed for convector electric THERMOVAL model T17 and TX (hereinafter referred to as heaters). Heaters belong to the class of modern heating equipment stationary type, using hot air for heating buildings and building installations.
- Page 3 Other data reported in Table 1. Tabel 1 Nominal power consumption, Nominal power, А 10,8 Dimensions, mm, no more 490×115×45 600×115×45 740×115×45 890×115×45 400×115×45 than (length×width×height) 3. ELEMENTS - Heater - 1 pcs. - Brackets for wall mounting 1 set - 2 pcs.
- Page 4 WARNING! To avoid overheating, do not cover his radiator. NOT ALLOWED: ● partially or completely block the ventilation holes in the radiator grilles ● place near a heater, inflammable materials and objects ● install the heater directly under the electrical socket ●...
- Page 5 draught.1 draught.2 draught. 3 draught. 4 5.5 - Heating type IP24 can be installed in bathrooms, swimming pools (see Fig. 4). In this case, the installation of the heater of this type is not allowed: a zone (1) bathrooms, swimming pool, etc .; in the zone (2), where a person located in the bath, shower or swimming pool can reach a heater or its cord.
- Page 6 be aligned with the markings on the housing of the heater or the control unit. The radiator is ready to operate - (circuit controls the heater is shown in Figures 5 and 6). 1 – the thermostat knob 2 – switch power control (off switch for heater models without power controller) 3 –...
- Page 7 at the point. 6.3 of this manual. To remove the top of the heater and pull up on each other - until the output of the lower tap holes on the bottom of the handle of the discharge grille of the radiator and the heater is then pulled down and we remove it from the upper hooks handles.
- Page 8 EN 62233: 2008 EN 55014-1: 2006 + A1: 2009 + A2: 2011 EN 55014-2: 1997 + A1: 2001 + A2: 2008 EN 61000-3-2: 2006 + A1: 2009 + A2: 2008 during the lifetime (10 years) in strict compliance with the requirements of this manual. During the warranty period, in the case of disclosure of significant defects that arose through the fault of the manufacturer, the consumer is entitled to a free repair, replacement or refund of its value in accordance with the requirements of the Law "On Protection of Consumer Rights".
