ALPHA DISPLAY
Engineering Specification
Model No. : APR-A1500-(A)(B)(C)(D)
Ver.
Date
1.0
Jan. 11. 2012
Contact Details
Head Office, Factory & R&D Center
#502 103-dong, Bucheon Techno Park 364, Samjeong-dong
Ojeong-gu, Bucheon City, Gyeonggi-do, Korea, 421-741
http://www.alphadisplay.co.kr
Tel. +82-32-321-8029 Fax. +82-32-325-8075
APR-A1500-(A)(B)(C)(D) Engineering Specification
15.0 inches Flat Panel Monitor
Table of Contents
Revision History
Page
N.A
Initial Release
2
2
2
4
5
8
9
10
11
Change Description
CONFIDENTIAL
Page 1 of 11
Advertisement
Table of Contents
Summary of Contents for ALPHA DISPLAY APR-A1500-A
-
Page 1: Table Of Contents
ALPHA DISPLAY CONFIDENTIAL Engineering Specification Model No. : APR-A1500-(A)(B)(C)(D) 15.0 inches Flat Panel Monitor Table of Contents 1. Description 2. General Features 3. Specification 4. Environmental and Reliability Specification 5. OSD Control Functions & Keypad Description 6. Cable Pin Configuration (Connectors) 7. -
Page 2: Description
Suffix Power Option (A : AC Power IN, B : DC12V-In, C : DC18V-In, D : DC24V-In, E : DC10~32V-In) * Please contact sales department of alpha display for touch screen and chassis type in detail. Panel ▪ Panel Module... - Page 3 ALPHA DISPLAY CONFIDENTIAL Rise Time (Tr) Typ. 5.7 mSec Response Time Fall Time (Tf) Typ. 2.3 mSec Average Brightness Typ. 400 cd/m (Min.320 cd/m Panel Dimension 326.5 mm (W) x 253.5 mm (H) x 13.1 mm (D) Back Light System...
-
Page 4: Environmental And Reliability Specification
ALPHA DISPLAY CONFIDENTIAL Regulation ▪ Safety & Ergonomics EMC(EMI/EMS) RoHS Compliant In compliance with the essential requirements and other relevant provisions of European Union Directive 2002/95/EC (RoHS). 4. Environmental and Reliability Specification * This specification depends on LCD panel characteristic. Please refer to panel specification in detail. -
Page 5: Osd Control Functions & Keypad Description
ALPHA DISPLAY CONFIDENTIAL 5. OSD Control Functions & Keypad Description 5-1. OSD Control Functions Top Menu Sub Menu Item Value Top Menu Sub Menu Control Description PICTURE - Analog RGB & Digital RGB Input Brightness Adjust the brightness of image. (Increment/Decrement) Back Light Adjust the luminance of back light. - Page 6 ALPHA DISPLAY CONFIDENTIAL Color Temp. Select the preset of the color temperatures such as Reddish, Bluish or User. User’s color can be changed by a user. Red - Adjust the RED color temperature for User’s color. Green - Adjust the GREEN color temperature for User’s color.
- Page 7 ALPHA DISPLAY CONFIDENTIAL (Auto Adjust) image, if pressed on No OSD menu. (analog RGB input only) (on No OSD Menu) SELECT Change the current source input to another if pressed on No OSD Menu. MENU+SELECT Locked or Unlocked OSD menu control. (toggled)
-
Page 8: Cable Pin Configuration (Connectors)
ALPHA DISPLAY CONFIDENTIAL 6. Cable Pin Configuration Analog RGB Cable (15 Pin Mini D-SUB Connector) Green (SOG in) Ground - Sync Blue No Connection Ground DDC Serial Data Ground Horizontal or Composite Sync Ground - Red Vertical Sync Ground – Green DDC Serial Clock Ground –... -
Page 9: Standard Display Mode
ALPHA DISPLAY CONFIDENTIAL 7. Standard Display Mode Horizontal Vertical Mode Resolution Pixel clock Remark Frequency Polarity Frequency Polarity 640x350 31.47 KHz 70.1 Hz 25.18 MHz 720x400 31.47 KHz 70.1 Hz 28.32 MHz VESA 640x480 31.47 KHz 60.0 Hz 25.18 MHz... -
Page 10: Mechanical Specification
ALPHA DISPLAY CONFIDENTIAL 8. Mechanical Specification APR-A1500-(A)(B)(C)(D) Engineering Specification Page 10 of 11... -
Page 11: Appendix1. Touch Screen Specification
ALPHA DISPLAY CONFIDENTIAL Appendix1. Touch Screen Specification Touch Screen ▪ * This specification depends on Touch Screen characteristic. Please refer to Touch Screen specification in detail. Model Inotouch, B150N18AG26-01 (15inch 5-Wire Resistive Touch) Active Area 304.5mm x 228.5mm (11.99” x 9.00”) Viewing Area 307.5mm x 231.5mm (12.11”...
