1/5TH GASOLINE POWERED HOBBY ENGINE
HY30CC/32CC
Warning:
-This gas powered engine is not a toy. Incorrect operation would cause a serious injury and damage
to property.
-Read and understand this manual carefully before operating your engine. Being very familiar
with safe use is necessary before handling this engine.
30CC
32CC
20141023
Advertisement
Summary of Contents for Fuelie HY30CC
- Page 1 1/5TH GASOLINE POWERED HOBBY ENGINE HY30CC/32CC 30CC 32CC Warning: -This gas powered engine is not a toy. Incorrect operation would cause a serious injury and damage to property. -Read and understand this manual carefully before operating your engine. Being very familiar with safe use is necessary before handling this engine.
- Page 2 Technical Data Of Gasoline Engine Introduction Dear Customer: 1E36F 30CC 1E37F 32CC Item Thank you for purchase our 1E28-34F , 1E28-36F,and 1E32-36F hobby gasoline Single-cylinder, two-stroke, Single-cylinder, two-stroke, Structure Type engine. wind cooling wind cooling We are keen to provide good service for you. Being familiar with the safety/usage Displacement (ml.) 30.4 31.9...
- Page 3 A. General Warnings: D. Breaking-in of engine 1. Recommended to be used for breaking-in of engine: 1.Verify all screws and nuts are firmly secured on the engine. Verify the engine with all wirings l No.90-No.93 gasoline as the fuel l FC two-stroke gas engine oil as the lubricant well-connected and a complete oil tubing.
- Page 4 Therefore, re-adjust high/low end mixture needle until the engine run smoothly. -Maintenance Not only optimum performance desires for engine speed at a considerate rpm, but it also requires 1.Keep the engine surface clean. Always clean oil stains off after use. smooth acceleration and/or deceleration for the engine without stalling.
-
Page 5: Engine Exploded View
30CC( 25085 )&32CC( 25086 ) Common Below Special parts for 30CC Engine Exploded View. Engine Exploded View 30002 30003 25082 Below Special parts for 32CC Engine Exploded View. 25082(30CC) 25083(32CC) 25070 25071 25 0 7 9 32002 32003 25083 2508 4 250 4 9 25051 25054... - Page 6 30CC&32CC Common Parts 30CC&32CC Common Parts 25015-Crank Group 1P 25002-Washer 25016-Oil Seal 25017-Flange Screw 25058-Flange Screw 25003-Spring M5*25 M6*20 25018-Flywheel 25019-Half Month Key 25020-Flange Nut 25005-Washer 25004-Gear Friction 1P 25006-Sunk Screw 25007-Clutch Connector 25008-Flange Screw 25021-Gear Fan Cover 25022-Screw M5*20 4P 25023-Starter M6*17 M5*15...
- Page 7 30CC&32CC Common Parts 30CC&32CC Common Parts 1P 25079-Flange screw 25081-Cylinder ring 25034-Piston Pin 25046-Branch Pipe 1P 25048-Flange Screw 25047-Carburetor Pad M5*23 M5*20 25035-Circlip 25037-Needle Bearing 25038-Elastic ring 25050-Filtration Pad 1P 25051-Air Cleaner 1P 25052- Air Cleaner Foundation 1P 25056-Sponge 25039-Gasket 25040-Lgniter 25041-Flange Screw 25054-Flange Screw...
- Page 8 Parts For 30CC Engine 25082-Cylinder 30002-Piston Curl 30003-Piston Parts For 32CC Engine 25083-Cylinder 32002-Piston Curl 1P 32003-Piston...
