L710 EVB User Manual

Version： V1.0

Date：

2019-08-08

Shanghai Mobiletek Communication Ltd

Table of Contents

Need help?

Do you have a question about the LYNO L710 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mobiletek LYNO L710

Page 1 L710 EVB User Manual Version： V1.0 Date： 2019-08-08 Shanghai Mobiletek Communication Ltd...
Page 2 This document contains proprietary technical information which is the property of Shanghai Mobiletek Communication Ltd. copying of this document and giving it to others and the using or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages.
Page 3 FCC Caution: (1)Exposure to Radio Frequency Radiation. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.
Page 4 L710 EVB User Manual Version History Author Date Version Description of change 2019-08-8 V1.0 Initial Contents 1 ABOUT THIS DOCUMENT..................4 1.1 Scope of applications......................... 4 Copyright© Shanghai Mobiletek Communication Ltd...
Page 5: Table Of Contents
5.6 Headset Interface..........................14 5.7 Antenna interface..........................14 5.8 Audio interface（TBD）.........................15 5.9 LED indicating lamp........................16 5.10 The others............................18 6 ACCESSORIES AND ASSEMBLY..............20 6.1 EVB Assembly..........................20 6.2 EVB Accessory..........................21 6.3 Driver install.............................22 Copyright© Shanghai Mobiletek Communication Ltd...
Page 6 L710 EVB User Manual 6.4 Dial configuration..........................26 1 About this document 1.1 Scope of applications This document describes the basic specifications of the L710 IoT Module EVB (hereinafter referred to as Copyright© Shanghai Mobiletek Communication Ltd...
Page 7: Writing Purpose
Introduce L710 module and L710 EVB application interface 5Accessory and Assembly Introduce L710 EVB Accessory and assembly(hardware and software) 1.3 Support and reference documentation list In addition to the hardware development documentation, we also provide the development board Copyright© Shanghai Mobiletek Communication Ltd...
Page 8: Abbreviations
Table 1-2 is the relevant abbreviation and English interpretation of the whole document. Table 1- 2 Abbreviation ullnameinEnglish Abbreviation Electro-Static discharge Universal Serial Bus UART Universal Asynchronous Receiver Transmitter SDCC Secure Digital Card Controller USIM UniversalSubscriber Identification Module Serial Peripheral Interface Inter-Integrated Circuit Pulse-coded Modulation Input/output Copyright© Shanghai Mobiletek Communication Ltd...
Page 9: Abstract
To help developers to develop, debug, test L710 series 4 GIoT LTE module. Below and mark shows L710 the main functions of the development board. In this article, we will in the subsequent chapters on the function of each part is described. Copyright© Shanghai Mobiletek Communication Ltd...
Page 10: Power Supply
Switch S1 to the bottom when using battery power. The power indicator (LED1 next to the power switch) will light up when the system is powered on. As shown in the figure below: Copyright© Shanghai Mobiletek Communication Ltd...
Page 11: Key Description
When power supply for the EVB, the The lower left corner of the PWRKEY button on the board, long press 500 MS, can open the module, and press the PWRKEY button Copyright© Shanghai Mobiletek Communication Ltd...
Page 12: Forced Usb Download Key
Press the WDOG key and the PWRKEY key at the same time will disable the watchdog function. Normally on, the watchdog function is enabled, the system will feed the dog regularly. The watchdog button is mainly used for software debug. Copyright© Shanghai Mobiletek Communication Ltd...
Page 13: Application Interface
AT instruction, data transmission, etc. When using, you need to dial the switch S4 to the right as shown in the arrow direction below. Copyright© Shanghai Mobiletek Communication Ltd...
Page 14: Usb（At Uart）Interface
DEBUG serial port. In use, you need to dial the switch S4 to the left. After the serial port is inserted into USB, DB9 serial port is closed. Sending AT can only use the USB virtual serial port mentioned in 5.2. Copyright© Shanghai Mobiletek Communication Ltd...
Page 15: Usb 2.0 Interface
L710 support one single voltage (1.8V) SIM interface, but for the convenience of users, we have provided two SIM holder interface. it’s standard SIM card slot and Micro SIM card slot. Each SIM slot automatic identification (correspond change the SIM support voltage) show as below figure: Copyright© Shanghai Mobiletek Communication Ltd...
Page 16: Headset Interface
GPS antenna interface. Main antenna interface adopts SMA head, connected to the supporting external antenna by cable; GPS antenna USES IPX interface. As shown in the figure below: Copyright© Shanghai Mobiletek Communication Ltd...
Page 17: Audio Interface（Tbd
SPK end, and 8 ohm horn can be welded to the SPK end. Toggle switch as shown in the figure below: Figure5-8: CODEC SWITCH S2 S3 The default audio solution on EVB development board is NAU8814, so the external audio channel Copyright© Shanghai Mobiletek Communication Ltd...
Page 18: Led Indicating Lamp
Switch S2 to the top, and software pull GPIO25 up, the LED on LED3 NETLIGHT Network indicator LED4 I2C_SDA I2C/GPIO Multiplexing channel LED5 SPI_MISO_BLSP2 SPI/GPIO Multiplexing channel LED6 I2C_SCL I2C/GPIO Multiplexing channel LED7 WAKEUP_IN Wake up the interrupt Copyright© Shanghai Mobiletek Communication Ltd...
Page 19 L710 EVB User Manual LED8 STATUS System status indicator LED9 ISINK ISINK LED11 MB_GPIO_0 GPIO Enable Pin LED12 SPI_CLK SPI/GPIO Multiplexing channel LED13 SPI_MOSI SPI/GPIO Multiplexing channel LED14 SPI_CS SPI/GPIO Multiplexing channel Table 5-1: Copyright© Shanghai Mobiletek Communication Ltd...
Page 20: The Others
In addition, for the convenience of users, we also can all use the module to the interface of the derivation, using 2.54 mm spacing standard dupont line can be connected. Interface is located in the development board above the upper right corner, specific interface function as shown in the figure Copyright© Shanghai Mobiletek Communication Ltd...
Page 21 4 EAR_OUT_P 6 GND 8 SPK_OUT_P1 10 SPK_OUT_N1 1 MIC1_P 3 MIC1_N 5 GND 7 MIC1_IN_P 9 MIC1_IN_M Table 5-2 Note: the above figure and above table are the corresponding relations between form and practice. Copyright© Shanghai Mobiletek Communication Ltd...
Page 22: Accessories And Assembly
EVB board parts altogether consists of four parts: 1) the EVB board substrate, 2) module board, 3) module loading board connection EVB board substrate connection column and nuts, 4) EVB board pillar base plate and screw. L710 module and loading board column and nutPillar and the screw Copyright© Shanghai Mobiletek Communication Ltd...
Page 23: Evb Accessory
Under normal circumstances, A complete set of equipment should include power adapter (A) DC power supply line, Micro USB cable (B), (C) rod antenna, (D) RF cable line. As shown in the figure below: Figure 6-2： Accessories and the connection diagram Copyright© Shanghai Mobiletek Communication Ltd...
Page 24: Driver Install
Type: Single-stage sub-antenna GSM 850/1900:Gain: 3dBi NB-IoT B2/CAT-M B2:Gain: 3dBi NB-IoT B4,B5,B12,B13,B26;CAT-M B4,B5,B12,B13,B26 :Gain: 4dBi Support band: CATM/NB B2,B4,B5,B12,B13,B26, GSM 850MHZ PCS 1900MHZ 6.3 Driver install Unzip file: QUD.WIN.1.1 Installer_10037.3.zip and click setup.exe to install driver Copyright© Shanghai Mobiletek Communication Ltd...
Page 25 L710 EVB User Manual Select “WWAN-DHCP is not used to get IPAddress”, then Next Select “I accept the terms in the license agreement”, then Next Copyright© Shanghai Mobiletek Communication Ltd...
Page 27 L710 EVB User Manual Check “Always trust software from “QUALCOMM” Incorporated”, then Install Power on the L710 module and connect USB cable, Drivers have been installed successfully if the Device Manager panel display the following: Copyright© Shanghai Mobiletek Communication Ltd...
Page 28 1. Open win->Computer(right click) ->Properties->Device Manager 2. On Advance TAB, type AT+CGDCONT=1,”IP”,”CMNET” and save it NOTES: The third argument for APN, defined by operators. China unicom 2g network: uninet China unicom 3g network: 3gnet China mobile: cmnet or cmwap Copyright© Shanghai Mobiletek Communication Ltd...
Page 29 L710 EVB User Manual 3. Open Network and Sharing Center, then set up a new connection or network Copyright© Shanghai Mobiletek Communication Ltd...
Page 31 L710 EVB User Manual Type Dial-up phone number, User name, Password, then Connect NOTES: *99***1# cmnetcmnet just for china mobile Please consult the operators to obtain information before connect Copyright© Shanghai Mobiletek Communication Ltd...
Page 33 814 MHz~849 MHz 859 MHz~894 MHz GSM850 824 MHz — 849MHz 869 MHz — 894 MHz GSM1900 1850 MHz — 1910MHz 1930 MHz — 1990MHz Table 2-2 Conducted transmission power Working Band Max Power Min Power Copyright© Shanghai Mobiletek Communication Ltd...
Page 34 -113 -123.8 = Total – 10.8dBm HD-FDD -114 -124.8 = Total – 10.8dBm HD-FDD -114 -124.8 = Total – 10.8dBm HD-FDD -114 -124.8 = Total – 10.8dBm HD-FDD -114 -124.8 = Total – 10.8dBm HD-FDD Copyright© Shanghai Mobiletek Communication Ltd...
