Summary of Contents for POLYLUX T Series

  • Page 1 MANUAL DE INSTALACIÓN Y MANTENIMIENTO (SERIE Txx) INSTALLATION AND MAINTENANCE MANUAL (Txx SERIES)
  • Page 2 POLYLUX no se hará responsable del coste de reparación/substitución. If any damage caused by the forwarder is not indicated in the delivery note during the receipt of goods, POLYLUX will not be held responsible for the cost of repair/replacement. 2.2. Descarga y manejo 2.2.
  • Page 3 Para garantizar un correcto funcionamiento, los transformadores deben ser almacenados cumpliendo unos requisitos mínimos. To ensure a proper operation, the transformers must be store fulfilling minimum requirements. Se debe evitar almacenar los transformadores al aire libre. Outdoor storage of the transformers is to be avoided. POLYLUX | Ref.: DT-E-1303-01...

  • Page 4: Instalación

    ANAN Cooling ANAN Temperatura ambiente 30ºC Ambient temperature 30ºC ≥ 8 kVA ≥ 8 kVA Pernos de elevación Lifting eyebolts ≤ 400 kVA ≤ 400 kVA Prensaestopas y Cable glands and silent- Incluido Included silent-block blocks POLYLUX | Ref.: DT-E-1303-01...
  • Page 5 9) Conectar la carga a los terminales del 9) Connect the load to the terminals of the secundario secondary POLYLUX | Ref.: DT-E-1303-01...
  • Page 6 All connections must be tightened as per the torques abovementioned. An improper tightening may cause irreversible damage to the transformer. 5) Asegúrese de que la puesta a tierra esté 5) Ensure that the ground point is properly correctamente conectada a los terminales. connected to the terminals. POLYLUX | Ref.: DT-E-1303-01...
  • Page 7 Por seguridad, en ningún caso se debe manipular el transformador. Una vez manipulado, POLYLUX no se hace responsable de los posibles daños y la garantía pierde su validez. For safety reasons, in no case the transformer must be manipulated. Once manipulated, POLYLUX holds no responsibility for any damage and the warranty becomes void.
  • Page 8 Francia AP-7 Sabadell Terrassa N-150 C-58 N-150 C-58 AP-7 Cerdanyola Francia del Vallès Inglaterra Ripollet Tarragona España Europa Sincrotró Alba BP-1413 Alemania Barcelona N-150 Francia Barcelona BP-1413 Parc Tecnològic Mar Mediterráneo del Vallès Sant Cugat Italia España C-58 Barcelona...
