Summary of Contents for smooth X bike SMB-XBIKE
- Page 1 OWNER’S MANUAL CAUTION: THE MAXIMUM USER WEIGHT LIMIT ON THIS PRODUCT SHOULD NOT EXCEED 136KG / 300LBS The Product May Vary Slightly From the Picture Shown Above VER-20140905 MADE IN CHINA...
- Page 2 Seat Cushion Disclosure ALL NEW MATERIALS Consisting of: PP+PU+FOAM Date of Manufacture: Oct. 2014 Model # SMB-XBIKE Lot # CF168...
- Page 3 ““S AFETY NSTRUCTIONS” WARNING: To reduce the risk of serious injury, read the following safety instructions before using the item Read all warnings posted on the equipment. Follow all safety instructions in this manual. Read this Owner's Manual and follow it carefully before using the equipment. Make sure that it is properly assembled and all fasteners are tightened before use.
- Page 4 smoothXbike Too often, our busy lifestyles limit our time and Thank you for choosing the . We take opportunity to exercise. This equipment provides a great pride in producing this quality product and hope convenient and simple way to get your body in shape it will provide many hours of quality exercise to make and achieve a happier and healthier lifestyle.
- Page 5 “H ARDWARE DENTIFICATION HART” Unpack the box in a clear area. Review the Hardware Kit List below. This chart is provided to help identify the hardware used in the assembly process. For you convenience most of the hardware is preinstalled. Do not dispose of the packing material until the trial period has expired.
- Page 6 “A SSEMBLY OOLS” PLEASE NOTE: WE DO NOT RECOMMEND USING POWER TOOLS FOR ASSEMBLY THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY: ALLEN WRENCH WRENCH “A SSEMBLY NSTRUCTIONS” – TEP1 Base Support Frame Assembly Open the frame of the bike by pulling the upper After unpacking the smoothXbike, remove portion of the bike outward.
-
Page 7: Seat Assembly
“A SSEMBLY NSTRUCTIONS” – TEP2 Seat Assembly This hardware is pre-installed 3x #22 3x #16 1. Attach the seat to the seat post. The seat studs will insert through the seat post holes 2. Secure the seat to the seat post using 3×M8 flat washers (22) and 3x M8 Nylock nuts (16). - Page 8 “A SSEMBLY NSTRUCTIONS” – TEP3 Seat Installation and Handlebar Assembly This hardware is located in the hardware Seat Adjuster Knob 1. Insert the seat adjustment knob into the mainframe by turning the knob 5 times clockwise. 2. After threading the adjustment knob in to the mainframe, pull the knob outward while inserting the seat post into the mainframe.
- Page 9 “A SSEMBLY NSTRUCTIONS – TEP4 Console Assembly NOTE: Do not tighten the computer bolts until all bolts are installed This hardware is pre-installed 4x #4 4x #6 1. Insert the console frame into the bike main frame as pictured on the left. 2.
-
Page 10: Pedal Assembly
SSEMBLY NSTRUCTIONS” – TEP5 Pedal Assembly RIGHT SIDE LEFT SIDE 1. Using your hands, thread the Left Pedal 2. Using your hands, thread the COUNTER-CLOCKWISE onto Right Pedal CLOCKWISE onto the the LEFT crank arm. After the RIGHT crank arm. After the pedal is pedal is hand tightened use the hand tightened use the supplied supplied wrench to completely... - Page 11 “A SSEMBLY NSTRUCTIONS” – TEP6 Battery Installation Note: The computer monitor will not function without 2 AA batteries. Batteries not included. Open the battery door on the back of the computer Insert the batteries in the direction shown on the left. Replace the battery door Verify that the computer wire from the bike frame and the console are connected.
- Page 12 “S NSTALLATION and DJUSTMENT” Warning: Do not use the smoothXbike without verifying that the seat is locked in place. Before moving or using the bike, pull upward on the seat to verify it cannot be removed 1. Turn the seat adjustment 2.
-
Page 13: Adjusting The Resistance
smoothXbike NFOLDING the Open the frame of the bike by Place the locking pin in the first Remove the frame locking pin pulling the upper portion of the pin hole, to lock the frame in from the first locking position. bike outward. - Page 14 “C OMPUTER ISPLAY” Note:The computer will not function without 2 AA batteries. Scan: This function allows the computer to scan through each workout data readout automatiallly(Time, Speed, Distance, Odometer (ODO) Pulse, Calories) To enable the scan function press the selection button (I) until the selection symbol (H) is pointing at scan. Time: Displays the time spent during your workout.To view the time press the selection button (I) until the selection symbol (H) is pointing at time.
- Page 15 “C OMPUTER ISPLAY” Workout Data Ranges Time 00:00 to 99:59 Min Speed 0.0 to 999.9MPH Distance 0.00 to 999.9Mi Calories 0 to 9999 Cal Pulse 40 to 240 BPM “C OMPUTER ISPLAY PERATION” Selecting the Data on the Display Press the selection button to display the preferred data reading. The selection symbol will highlight the current data being displayed.
- Page 16 XPLODED IAGRAM”...
- Page 17 “P IST” Item Name Q'TY XB-1 Seat pad XB-2 Computer XB-3 Handlebar XB-4 Bolt M6X12 XB-6 Flat washer M6 XB-7 Main frame XB-8 Pedal(right)1/2-20 with strap XB-13 Pedal(left)1/2-20 with strap XB-9 Curved washer M8 XB-10 Carriage bolt M8*50 XB-11F Front support XB-11R Rear support XB-12...
- Page 18 LIMITED HOME USE WARRANTY – smoothXbike Warranty Warranty Coverage: smoothXbike warrants to the original owner that each new product will be free from defects in workmanship and material, under normal use and conditions. Period of Coverage: The Warranty on this product runs from the date of original purchase using the following schedule: Model Name Plastics, Upholstery and Wear and Tear Parts Frame and Mechanical Parts...
- Page 19 This page is intentionally blank...
- Page 20 Customer Service Toll Free ·· 855-663-5643...
