Hausammann H115.0557 Manual

H115.0557 Manual for automatic
dispenser for sanitizer

Technical Specification

Product Dimension : 25 x 15 x 10cm
Battery : Alkaline AA 1.5v (4 Pcs)
Battery Life : > 20000 times / Shot, Stanby mode 2 years
Volumn / Shot : 1-2 ml / Shot
Speed / Shot : 0.6 ~ 0.8s / Shot
Sensing Distance : 1cm ~ 10cm

Feature

1) Sensing: Sensor will activate only around sensing area,
one shot / sensing, maximum sense distance 10cm
2) Sensing Setting:
1) Switch upwards Figure 1, 2 shots / sensing
2) Switch downwards Figure 2, 1 shots / sensing
3) Low Battery Indicators: Low battery indicator see
Figure 1 Flashes red rapidly when batteries should
be changed ) See Figure 3.
4) 4)Low Liquid Indicators: Low liquid indicator see
Figure 2 Flashes green rapidly level is low and
need change the bottle with full liquid. See Figure
3.
5) Product Mal function: Flashes red and green
rapidly See Figure 1 and Figure 2

Operation

Place hand at the bottom center of product, about 1 cm ~
10cm distance, Wait around 1 second for soap to dispense. If
need more soap, just move hand away from sensing area,
then move hand back to sensing area. Repeat if necessary

Precaution

1. Product install at indoor with proper ventilation. Avoid direct sun light and rain.
2. During transportation, container with liquid should be remove from the product to avoid liquid
leaking to the product controller and circuitry
3. When indicator low battery flashes, batteries need to be replaced as soon as possible.
4. Product can be cleaned with damp cloth and wipe with dry cloth later. Do not splash with
water.
Manual automatic dispenser www.hausammann.com
