Summary of Contents for Austa GB1080
- Page 1 Induction Cooker...
- Page 2 Induction Index Cooker • Introduction • Type of Induction Cooker • Working Principle • Benefits • Comparison • Guide to use • Technical Parameters • Warranty • FAQs...
- Page 3 Induction Introduction Cooker Austa Induction Cooker is a safe and excellent substitute for gas, microwave and other cooking appliances in use. We provide Induction cooker to customers which suits their requirements at the market leading prices. Along with this we also provide proper after sales service for the Induction Cooker within a fixed time period.
- Page 4 Induction Type of Induction Cooker Cooker Model No. GB1080 Description Power: 1800W, 220-230 VOLT Control Push button Digital Display Timer 2 hours (max) Levels of Power 800W to 1800W Levels of TEMP 60 to 240 Cooking Function Others Timer lock function N.W.
- Page 5 Induction Type of Induction Cooker Cooker Technical specification of Induction cooker AB 333 AB 333 Sr. No. Features Max power 2000W Min power 120W Total function Max temperature Min. temperature Electrical option Show both in put voltage and electricity consumption. Timer preset 1 min - 24 hours...
- Page 6 Induction Type of Induction Cooker Cooker Technical Specification of AB 369 AB 369 Sr. No. Features Max power 2000W Min power 200W Max temperature Min. temperature Electrical option Show both in put voltage and electricity consumption. Timer preset 1 min - 3 hours...
-
Page 7: Working Principle
Induction Working Principle Cooker The mechanism of Austa Induction Cooker is based on Faraday’s law of induction which states that, “Any change in the magnetic environment of a coil of wire will cause a voltage (electromagnetic force or emf) to be induced in the coil.”... -
Page 8: Heating Principle
Induction Heating Principle Cooker The panel is made up of high strength and anti-shock ceramic. Under the panel is the wire coil, electricity transistor and control system and placed above the panel, is the flat cookware where the vessel is kept for cooking. - Page 9 • Sleek and portable: The best feature of Austa Induction Cooker is its size and looks. It is a portable, sleek and sophisticated looking device which reduces the table top clutter in your kitchen and also gives it a trendy look.
- Page 10 Induction Benefits Cooker • Protective features: The device gives Error Messages if there is any problem in its functioning like unsuitable vessel, over heat alarm, high voltage or low voltage error alarm, sensor open or short circuit alarm, empty vessel and inside circuit error alarm. •...
- Page 11 Induction Comparison Cooker...
- Page 12 Induction Comparison Cooker Stated Power vs. Delivered Power: Type Efficiency Power Delivered Power Induction 2.8 KW 2.52 KW 3.5 KW 1.75 KW Halogen 2.2 KW 1.32 KW Electric Coil or 2.0 KW 1.1 KW Cast Iron...
- Page 13 Induction Comparison Cooker Time required for boiling 2 liters of water: Type Temperature of Cook Top Power Induction 4 min.46 sec 8 min.18 sec Halogen 9 min.00 sec Electric Coil or 9 min.50 sec Cast Iron...
- Page 14 Induction Guide to use Cooker • In order to start the Induction cooker, connect the main chord to an AC 230v main supply and switch on the plug to give power to the cooking plate. When on, the power LED will flash, indicating power supply.
- Page 15 Induction Guide to use Cooker Requirements of vessel: Only flat bottom vessels with a base made of stainless steel, steel or iron casting should be used. Vessels made up of Ceramic, Glass, Aluminum, Pottery, Brass etc. will not work on the induction cooker.
-
Page 16: Function Buttons
Induction Function Buttons Cooker The control panel has the following buttons. Sr. No. Button Name ON/OFF button To start or stop the Induction Cooker Type of Temperature For setting type of Temperature pattern Increase Heat button For increasing the Heating/ Timing Decrease Heat button For decreasing the Heating/ Timing Auto Temperature... -
Page 17: Warranty
Induction Warranty Cooker • The Company offers one year warranty for the product for repairing or replacing parts free of cost against any manufacturing fault. • Plastic body and ceramic plate which are breakable are not covered in warranty. • Electronic parts damaged due to voltage surge do not come under warranty. - Page 18 Induction Warranty Cooker • Damage due to normal wear & tear, improper maintenance, improper use & altered or repaired by anyone other than an authorized person of the Company, shall void the warranty. • Any surface scratch or cosmetic changes due to wear & tear shall render the warranty void.
- Page 19 Induction Cooker Any negative effects caused by the magnetic coil? Ans: No negative effect is caused by the magnetic coil. On the contrary, it maintains the nutrients such as vitamins and proteins in the food. How much electricity is consumed in on hour? Ans: An average of 1.8 Units is consumed in an hour Why the induction cooking is better the gas cooking?
- Page 20 Induction Cooker What type of utensil material is compatible for induction Cooker? Ans: Only flat bottom vessels with a base made of stainless steel, steel or iron casting utensil material is compatible for Induction cooker. How different is Induction cooking from Microwave cooking? Ans: Induction cooker uses electricity to produce a magnetic field which sends Eddy Currents into iron items of the vessel used.
- Page 21 Induction Contact Us Cooker NIMH Technolinks Head Office 1101, 11th Floor, Ankush Apartment, 10th Khetwadi Road, Mumbai-400004, India. Mob.: +91-9820944410 • Tel.: +91-22-23811121 Email: kharishmehta.nimh@gmail.com / info@nimh.in Visit us at: www.nimh.in Factory Khasra No. 573/409, Sai Road, Dharampur, Baddi, Dist: Solan, H.P India.
