Page 1 ATTENTION !!! PLS ADD OIL BEFORE USE THE MACHINE FLAIL MOWER #EFD...
Page 2 FOREWORD The purpose of this manual is to assist you in operating and maintaining your Flail mower. Read it carefully before operating and maintaining the Flail mower, it furnishes the specifications, construction, instructions and also the maintenance. Some information may be general in nature due to unknown and varying conditions.
Page 3: Table Of Contents
CONTENTS CHAPTER Ⅰ SAFETY INFORMATION..............3 1.1 Safety First......................3 1.2 Safety Signs....................4 CHAPTER Ⅱ SPECIFICATIONS................5 2.1 Brief Introduction....................5 2.2 Specifications and Parameters for Flail Mower........5 CHAPTER Ⅲ OPERATION..................6 3.1 Checking Before Operating................6 3.2 Adjusting the Height..................6 3.3 Regulating the Tension of Driving Belt............7 3.4 Staring up......................8 CHAPTER Ⅳ...
Page 4: Chapter Ⅰ Safety Information
CHAPTER Ⅰ SAFETY INFORMATION PLEASE NOTE Make sure all potential operators of this equipment review this manual and all safety messages contained within. 1.1 Safety First Read this service manual before using the machine. This safety alert symbol indicates important safety messages in this manual.
Page 5: Safety Signs
Don’t start the machine in a closed place (due to the smoke from the tractor). 1.2 Safety Signs 1.2.1 Care of Safety Signs 1. Keep safety signs clean and legible at all times. 2. Replace safety signs that are missing or have become illegible. 3.
Page 6: Chapter Ⅱ Specifications
CHAPTER Ⅱ SPECIFICATIONS 2.1 Brief Introduction series Flail mower is designed for pulverizing grass and short bramble, and shall EFGCH be used in the indicated purpose. The Flail mower consists of a rotating shaft with many blades attached to it. The blades cut the grass while traveling over the working area.
Page 7: Chapter Ⅲ Operation
CHAPTER Ⅲ OPERATION CAUTION: Be familiar with the machine before starting. Read this manual carefully to learn how to operate the machine safely and how to set it to provide maximum field efficiency. 3.1 Checking Before Operating ATTENTION: Only use universal joint conforming to CE standard and protect them properly.
Page 8: Regulating The Tension Of Driving Belt
be regulated correctly. When regulating the working height, loosen the screw (1), remove the screws (2) on both sides; regulate the roller height (see following drawing); fix the parts on the set position. The lowest hole is the highest working height; put the screws (2) into the set hole; tighten screw (1) and screws (2).
Page 9: Staring Up
3.4 Staring up Before starting the machine, control and adjust the following items: Tension of trapezoidal driving belt.  Oil level of gear.  Point of lubrication  All bolts, nuts and screws.  Working Position Moving Position In order to keep the machine stable, install the supporting frame on the machine when the machine is stopped (see above drawing).
Page 10: Chapter Ⅳ Service And Maintenance
CHAPTER Ⅳ SERVICE AND MAINTENANCE 4.1 Service 4.1.1 FLUIDS AND LUBRICANTS 1. Grease: Use multi-purpose lithium based grease. 2. Gear Box Oil: Use N46 drive &hydraulic dual-purpose oil or equivalent for all operating conditions. Each Gearbox Capacity: 0.85 liter 3. Storing Lubricants: Your machine can operate at top efficiency only if clean lubricants are used.
Page 11: Storage
IMPORTANT: Check the oil level only when the unit is cold and the machine is on the level. 4.2.2 SEASON MAINTENANCE Check the machine as below beside the terms of daily maintenance.  Check the oil in gearbox; replace it if it is bad. ...
Page 12: Operation After Storage
Recoat the parts rubbed and damaged for anti corrosion. Store the machine in a dry, level area. Support the frame with planks if require. 4.4 Operation After Storage Before the machine is started up, check the following items regularly: Check oil level and add it if not enough. Check and tighten all screws and nuts;...
Page 13: Chapter Ⅴ Illustrated Parts Catalogue
CHAPTER Ⅴ ILLUSTRATED PARTS CATALOGUE The manual contains a parts list for your machine. It is divided into major sections, which correspond to the groups shown in the Table of Contents and the accompanying illustration. The first page of each major section lists the contents of that section, each of which consists of exploded views and related tabular listings.
Page 14: Flail Mower Assembly
5.1 Flail Mower Assembly...
Page 15 Name &Specifications Part NO. Remark EF100.00.122 Fender EF100.00.121 Fender EF100.00.123 Shaft for fender GB879-86 Elastic cylindrical pin 4x22 GB97.1-85 Plain washer 10 FMR120.105 Lockpin plate FMR120.104 Pin for lifting(D) 200.56.011-1 Lockpin EFGCH120.018 Connecting bracket（L） EFGC120.101 Splint GB6184-86 Locking nut M10 GB5783-86 Bolt M10X70 GB97.1-85...
Page 16 RK120.113 Big belt ptlley GB/T1154-97 Strap A965 RK120.110 Small belt ptlley GB1152-89 Oil cup M8X1 GB5783-86 Bolt M12X30 GB93-87 Spring washer 12 EFGC120.013 Base plate （L） EFGC120.014 Base plate （R） Blade axle subassembly EFGCH120.102 Supporting tube EFGCH120.104 Guide rail EFG120.101 Supporting for roller （R）...
Page 18: Gearbox Assembly
Gear Box Assembly Ser.No Part No Name ＆Specification Remarks GB13871-94 Oil seal 35×62×10 GB893.1-86 Circlip 62 GB/T276-94 Bearing 6007 EFGC120.133 Shaft GB1096-79 Key A10X40 EFGC120.132 Connected sleeve EFGC120.131 Paper gasket GB1096-79 Key A10X70 XH50.300Z.02 Gearbox assembly EFGC120.018 Shaft tube weldment ZBT 32001.3-87 Retainer GB93-87...
Page 20 Part NO. Name &Specifications Remark UC207-Z Bearing with flange 90207 Blade axle weldment EFG120.013 GB5782-86 Bolt M12x80 EF100.00.101 Sleeve Blade EF100.00.102 GB6184-86 Locking nut M12 GB13871-94 Oil seal FB55X80X8 Oil-sealing sleeve RK120.109...
Page 21 The information contained in this operations manual is a general introduction only. The information contained herein may be modified at any time, for any reason. Modification may affect the details or specifications of the product described in this manual. Therefore, users –...
