Summary of Contents for ADV TRIBE K390A1HR
- Page 2 I N S T A L L A T I O N M A N U A L H AND LE BAR R AISERS...
- Page 3 STEP 1: DISASSEMBLY OF HANDLEBAR UNIT In order to Fit the ADV Tribe Raiser kit , Detach the Handlebar clamp cap (2) by un bolting the top cap bolt(1) using Allen Key. Once handlebar is detached, remove the Handlebar clamp bottom (4) by undoing the Allen bolt (3) using appropriate Allen key.
- Page 4 STEP 2: RAISER KIT ASSEMBLY Now bolt the raiser spacer (3) using the M10 bolt (1) provided with the kit in configuration as shown in figure. (Note: Do check the orientation of the raiser spacer; same can be identified by matching the grooving pattern step on the spacer) Once the bottom clamp and raiser kit is attached, mount the handlebar and secure it.
