Summary of Contents for MUX Wall Socket
- Page 1 Wall Socket Product and Installation Guide www.mux.life...
- Page 2 Product Overview Mux Wall Socket is a Wi-Fi enabled smart device, which allows you to plug and control any electronic appliance via the Mux Life App. Additionally you can set timers, apply schedules and control the devices via virtual assistants. Detailed statistics help you monitor the usage of your devices.
- Page 3 Front Side Power Button LED light Socket Screw Live / Hot Wire Neutral Wire Back Side...
- Page 4 If you have met the above electrical requirements, proceed with the installation: Step 1 Switch off the circuit breaker of the respective room. Use an electrical tester to confirm if electric current is passing through. Step 2 Unscrew and Remove existing wall socket.
- Page 5 Step 3 Identify Live, Load, Neutral and Ground lines. Step 4 Connect the Smart Device to your sub-box wiring as mentioned in the table. N - Black Wire L - Red Wire...
- Page 6 The table mentions sub-box wiring details. Sub-box Wiring Mux Wall Socket Live / Hot Wire Neutral Wire Step 5 Fix the Smart Device to the wall and look for the LED status. For the LED status, see the table on next...
- Page 7 To put the device in reset mode, press and hold the power button on the device for 6 seconds (until the blue LED starts flashing). The device is now in reset mode. You can now add it to your Mux Life account.
- Page 8 App Download Download the Mux Life App from the Google Play / App Store or scan the QR code. App Setup Scan the QR code to watch an installation video to setup Mux Life App. Caution - Wrap electrical tape around the wire nuts to make sure the copper conductor is fully concealed.
