Summary of Contents for COMELZ COM52
- Page 1 1 COMELZ_ITALIA COM52-INGL COMPUTERIZED THERMOCEMENTING AND FOLDING MACHINE COM52 INSTRUCTION MANUAL COMELZ s.p.a. Telefono +39 0381 42401 COMELZ_ITALIA 27029 Vigevano - Italia Telefax +39 0381 42064 http://www.comelz.com Viale Indipendenza, 55 E-mail: info@comelz.com...
- Page 2 2 COMELZ ITALIA COM52-INGL Model COM52 Serial No. Manufactured in Telefono 0381 / 42401 COMELZ COMELZ s.p.a. Telefax 0381 / 42064 27029 Vigevano - Italia E-mail: comelz@tin.it ITALIA Viale Indipendenza, 55...
- Page 3 3 COMELZ ITALIA COM52-INGL COMPUTERIZED THERMOCEMENTING AND FOLDING MACHINE COM52 INSTRUCTION MANUAL Telefono 0381 / 42401 COMELZ COMELZ s.p.a. Telefax 0381 / 42064 27029 Vigevano - Italia E-mail: comelz@tin.it ITALIA Viale Indipendenza, 55...
- Page 4 4 COMELZ ITALIA COM52-INGL Model COM52 Serial No. Manufactured in Telefono 0381 / 42401 COMELZ COMELZ s.p.a. Telefax 0381 / 42064 27029 Vigevano - Italia E-mail: comelz@tin.it ITALIA Viale Indipendenza, 55...
-
Page 5: Table Of Contents
8.6.6.4 Presser foot - lifting............................ 14 8.6.6.5 Knife................................15 8.6.7 WORK AREA ILLUMINATION, picture 15....................15 8.7 MECHANICAL ADJUSTMENTS...................... 15 8.7.1 Snip length................................. 15 8.7.2 Creaser foot working pressure........................... 15 COMELZ s.p.a. Telefono +39 0381 42401 COMELZ_ITALIA 27029 Vigevano - Italia Telefax +39 0381 42064 http://www.comelz.com... - Page 6 10.3 LUBRICATION..........................16 10.4 TESTING SAFETY DEVICES......................16 11 PRODUCT FLAWS AND THEIR CAUSE................16 12 ERROR CODES..........................16 13 WEAR AND SPARE PARTS.....................17 14 DISMANTLING THE COM52 FOLDING MACHINE............17 15 SOUND LEVEL OF THE COM52 FOLDING MACHINE........... 17 16 WIRING DIAGRAM........................18...
-
Page 7: Description Of The Machine
COM52-INGL DESCRIPTION OF THE MACHINE The Computerized Folding Machine COM52 manufactured by COMELZ and outlined in picture 1, is used to fold and at the same time cement the edge of leather components and other materials of similar nature. The operator guides the component piece against a guide and under a creaser foot that holds the material and spreads the cement. -
Page 8: Intended And Unintended Use Of The Machine
COM52-INGL INTENDED AND UNINTENDED USE OF THE MACHINE The COM52 machine was designed to fold and cement the edge of leather pieces and other materials with similar features. It is commonly used to manufacture shoes, leather-ware and leather garments. Unconventional use can cause serious injuries to the operator and damage the machine. -
Page 9: Environment
9 COMELZ_ITALIA COM52-INGL ENVIRONMENT • Do not place the machine in rooms with explosion or fire hazard. • Shelter the machine from bad weather. PREPARATION OF THE MACHINE FOR THE INSTALLATION CLEANING AND INSPECTING • Make sure that the various components of the machine were not damaged during transportation and handling. -
Page 10: Cement, Picture 8
10 COMELZ_ITALIA COM52-INGL The machine can store in memory the parameters for 99 types of folding. When the machine is turned on, the D5 display shows a number that indicates the selected folding style. T14 and T15 - To select one recorded folding style. -
Page 11: Feed, Picture 9
11 COMELZ_ITALIA COM52-INGL 8.6.3 FEED, picture 9. Feed parameters distinguished as: • OUTSIDE CORNER • STRAIGHT • INSIDE CORNER which indicate the operating conditions that can be met while folding a work-piece. The following parameters can be set: 8.6.3.1... -
Page 12: Feed Pitch
12 COMELZ_ITALIA COM52-INGL the knife are started also while folding ample corners, whereas the selection of segments on top makes the adjustments only in correspondingly tighter corners. Generally, select bottom D2 lights when processing rigid materials and top D2 lights when processing soft materials. -
Page 13: Creaser Foot, Pictures 11, 12 And 13
13 COMELZ_ITALIA COM52-INGL 8.6.5.1 Creaser foot, pictures 11, 12 and 13 Adjust the position of the creaser foot by means of the directional buttons T3-T4-T5-T6: • Adjust the foot vertically, leaving a clearance of approximately 0,5 mm from the work release arm when this is in its higher position. -
Page 14: Operation Mode, Picture 14
14 COMELZ_ITALIA COM52-INGL 8.6.6 OPERATION MODE, Picture 14 Picture 14 8.6.6.1 Feed T36 – It selects various feed modes for the piece being processed. D17 - They indicate the selected mode. • Pedal The operator starts operations by pressing the pedal •... -
Page 15: Knife
15 COMELZ_ITALIA COM52-INGL • Pedal The creaser foot goes up when the pedal is released. • Start photocell The creaser foot goes up when the start photocell is uncovered. • Pedal + start photocell The creaser foot goes up when the pedal is released and the start photocell is uncovered. -
Page 16: Maintenance Of The Machine
16 COMELZ_ITALIA COM52-INGL Minimum level should not be lower than 2 cm. 10 MAINTENANCE OF THE MACHINE The machine does not require specific preventive maintenance. Caution! Always turn the machine off when carrying out maintenance. 10.1 REPLACEMENT OF THE KNIFE, picture 12 •... -
Page 17: Wear And Spare Parts
• Metallic parts of the machine must be disassembled and grouped according to the type of material. They must then be demolished and melted separately. 15 SOUND LEVEL OF THE COM52 FOLDING MACHINE Under standard working conditions the sound level is:... -
Page 18: Wiring Diagram
18 COMELZ_ITALIA COM52-INGL 16 WIRING DIAGRAM...
