ADJUSTME TDH3 Datasheet

Data sheet for TDH3

Normal operation

• TDH3 is connecting to control box. Press any button. 3-digits display shows current desk height in centimeters.
• Press or button to adjust the desk height.
• When no button has been pressed for 10 seconds, display goes off. Press any button to light up the display again.
• When no button has been pressed for 30 seconds, the system goes to <0.1 W standby mode. Long press any button
to wake the system up. Display shows desk height again.

Reset

• Press both and buttons at the same time for 3 seconds. Continue pressing the buttons until both columns
are in lowest position. When finish reset, the control box makes a beep and the buttons can be released.
• When conducting reset, the display shows "000" in last 100mm stroke. When finish reset, the display shows
starting height again.
• If releasing and buttons before the display shows "000", the desk goes back to normal operation.
If releasing and buttons after the display shows "000", the user has to finish the reset to go back to
normal operation.
• Reset is necessary at first operation of the desk.

Memory position

• TDH3 supports 3 memory positions.
1. Operate the desk to preferred height and then press S for 2 sec and the digital display will start to flashing for 3 sec.
2. Press any of and the display will show P1, P2 or P3 when position has been stored.
3. Now, hold any of the buttons
• Stored postion can only be overwritten, not to be cleared.
info@adjustme.eu | www.adjustme.eu | © 3/2019 by ADJUSTME | All rights reserved | A part of
until the desk reaches the stored height.
