SEPTEMBER 2021
Portable Charger Guide
PRODUCT NUMBER PT00045331

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT00045331 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RIVIAN PT00045331

  • Page 1 SEPTEMBER 2021 Portable Charger Guide PRODUCT NUMBER PT00045331...
  • Page 2 All information in this document and all vehicle software is subject to copyright and other intellectual property rights of Rivian Automotive, LLC, its affiliates, or its licensors. This material may not be modified, reproduced, or copied, in whole or in part, without the prior written permission of Rivian Automotive, LLC, its affiliates, or its licensors.
  • Page 3: Table Of Contents

    Contents IMPORTANT SAFETY INSTRUCTIONS Precautions Grounding Instructions Safety Symbols on Hardware Labels Parts Diagram Attach or Remove an Adapter OPERATING  INSTRUCTIONS Attach and Charge Track Duration of Charge Light Bar States Detach the Portable Charger USER  MAINTENANCE INSTRUCTIONS MOVING  AND  STORAGE  INSTRUCTIONS INSTALLATION ...
  • Page 4: Important Safety Instructions

      Don't use the Portable Charger outside of the guidelines detailed in this guide.   The Portable Charger works with Rivian vehicles only. Don't use the Portable Charger for any other purpose or to charge any other vehicle.   Don't use the Portable Charger if it is defective or damaged in any way or if it doesn't work.
  • Page 5   Don't tamper with or try to service the Portable Charger by taking it apart. It's not user-serviceable. Contact Rivian for repair.   Don't twist or place significant strain on the Portable Charger. Don't apply excess force to or impact the Portable Charger controller.
  • Page 6   Don't plug the Portable Charger into an electrical outlet or unplug it from a power outlet that is underwater or in snow. If the charger is plugged into an electrical outlet, turn off the breaker before unplugging it.   Don't charge the vehicle if you, the vehicle, or the Portable Charger is exposed to severe weather.
  • Page 7: Grounding Instructions

    Grounding Instructions This product must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment grounding conductor and grounding plug.
  • Page 8: Safety Symbols On Hardware Labels

    Safety Symbols on Hardware Labels The following symbols may appear on labels on the Portable Charger. Risk of Electric Shock Danger Equipment Ground Instruction Manual UL  Logo...
  • Page 9: Parts Diagram

    Parts Diagram Rivian Portable Charger (PT00045331)   1. Plug   2. Controller   3. Light bar   4. Cable   5. 120 V AC charge adapter   6. 240 V AC charge adapter...
  • Page 10: Attach Or Remove An Adapter

                  Attach or Remove an Adapter   To attach an adapter to the Portable Charger, push the adapter connector into the cable controller port until the adapter connector clicks into place.   To remove an adapter, pull the adapter connector out of the cable controller port.
  • Page 11: Operating  Instructions

    OPERATING  INSTRUCTIONS   Before you attach the Portable Charger to an electrical outlet, check the Portable Charger and the electrical outlet for damage. If either is damaged, don't attach the Portable Charger to the electrical outlet.   Use only a 120 V, 208 V, or 240 V AC power supply with a 50/60 Hz wall outlet with a dedicated and properly grounded circuit rated for the adapter you're using.
  • Page 12: Track Duration Of Charge

    Track Duration of Charge Charge time can change depending on:   Power voltage and current   Battery temperature   Ambient temperature During a charge session, you can see data such as charge progress, time remaining to charge, and mileage estimates on the driver display or in the mobile app.
  • Page 13: Light Bar States

    Light Bar States Light Bar State Meaning White (solid) Available Green (pulsing) Charging Green (solid) Charging complete Red (pulsing) Error Red (solid) Error If the charger displays an error, troubleshoot the issue (page 16).   Detach the Portable Charger When the vehicle is done charging, the light ring around the vehicle charge port turns solid green. Press the button on the Portable Charger plug then pull to remove the Portable Charger plug from the vehicle.
  • Page 14: User  Maintenance Instructions

    USER  MAINTENANCE INSTRUCTIONS When you need to clean the Portable Charger, wipe it with a damp cloth. Don't use abrasive substances or materials. NOTE Ensure that you don't get water in the Portable Charger connection points. Follow the safety instructions  (page 4). MOVING ...
  • Page 15: Installation  Instructions

    INSTALLATION  INSTRUCTIONS Holes in the back of the Portable Charger controller provide a way to hang the controller on a wall.   1. Find a location on the wall near an electrical outlet.   For outdoor use, select a location between 24 in (600 mm) and 4 ft (1.2 m) above the ground.  ...
  • Page 16: Troubleshoot Your Portable Charger

    Troubleshoot Your Portable Charger Don't tamper with or try to service the Portable Charger by taking it apart. It's not user-serviceable. Contact Rivian for repair. If this happens It may be caused by this Try this   1. Unplug the Portable Charger from...
  • Page 17: Specifications

    7.1 lb (3.2 kg) Maximum operating altitude 14,108 ft (4,300 m) Enclosure type NEMA Type 6 Ventilation Not required Compatible vehicle inlet J1772 Adapters NEMA 5-15 120 V / NEMA 14-50 240 V UL file number E520745 Product number PT00045331...
  • Page 18: Customer Service

    Still need help? Connect with us.     Customer Engagement Center Roadside Assistance 24/7 (888) RIVIAN1 / (888) 748-4261 (844) RIVIAN4 / (844) 748-4264 customerservice@rivian.com rivian.com Support Center and Chat         Insurance Service 24/7 (888) RIVIAN8 / (888) 748-4268...
  • Page 19 Page left intentionally blank.
  • Page 20 PART NUMBER PT00262083-A...
