Summary of Contents for SmartPro Optimum-1

  • Page 2: Table Of Contents

    CONTENTS 1.INTRODUCTION 05-06 2.DISCLAMERS, EXCLUSIONS AND LIMITATIONS OF LIABILITY 3.QUICK START GUIDE 07-15 4.FEATURES AND ADVANTAGES 16-18 5.PRODUCT SPECIFICATIONS 6.DEVICE ACCESSORIES AND OVERVIEW 20-22 7.POWERING THE DEVICE 22-24 8.CALIBRATION 25-27 9.TESTING PROCEDURES 28-35 10.TEST RESULTS 36-38 11.OTHER FEATURES 39-43 12.SAFETY INFORMATION 13.SAFE HANDLING / MAINTENANCE 44-45 14.TROUBLESHOOTING...

  • Page 3: Introduction

    1.INTRODUCTION 1.INTRODUCTION Congratulations for having our SmartPro Optimum-I (SPO-I). The very first and unique handheld diamond multi-tester using a special UV LEDs with fiber optic technology that designed for identifying between Natural Diamond, CVD/HPHT, all types of Moissanite, various shapes and carat weight from 0.015 carat to 10 carat for polished diamonds...

  • Page 4: Disclamers, Exclusions And Limitations Of Liability

    Please read and note SMARTPRO WARRANTY TERMS AND CONDITIONS as stated in the warranty card. SmartPro warranty for its subject to proper use by its user in accordance with all the terms and conditions as stated in the relevant user manual and shall cover only manufacturing defects.
  • Page 5 2.DISCLAMERS, EXCLUSIONS AND LIMITATIONS OF LIABILITY SmartPro shall not be responsible for any damage or loss resulting from the use of the product or user manual, and under no circumstances shall SmartPro, its manufacturer or any of its subsidiaries,licensors, distributors, resellers, servants and/or agents be liable for any direct or indirect damages resulting from the use of this product.

  • Page 6: Quick Start Guide

    3. QUICK START GUIDE 3. QUICK START GUIDE 3.1) Turn ON/Turn OFF 1. Plug the USB cable from to Output port of Power bank /Adaptor to an Input port of SPO-I 2. Press and hold the Switch for 3 seconds to turn ON/OFF Bluetooth UV Torch Press Start!
  • Page 7 3. QUICK START GUIDE 3.2) Calibration 1. Cover the Probe tip 2. Click at “START” to begin the calibration CLOSE the tester's PROBE with its PROTECTOR the press START for calibration...
  • Page 8 3. QUICK START GUIDE 3.3) Functions Bluetooth UV Torch Press Start!
  • Page 9 3. QUICK START GUIDE Item display Meaning Testing START/ STOP Press Start! DIAMOND MOISSANITE Information&Test results CVD/HPHT Ready! UV Torch ON / OFF Rotate Display Bluetooth ON/OFF...
  • Page 10 3. QUICK START GUIDE 3.4) Test Setup Bluetooth UV Torch NOTE: Don’t move probe away from Gem.
  • Page 11 3. QUICK START GUIDE 3.5) Testing Result 1. Detected Natural Diamond (Type Ia) 2. Detected Synthetic Moissanite 3. Detected Synthetic Diamoud (CVD or HPHT) Bluetooth UV Torch Testing... Don’t move probe away from Gem. Bluetooth UV Torch UV Torch Bluetooth UV Torch Bluetooth DIAMOND...
  • Page 12 3. QUICK START GUIDE 3.6) Torch mode. UV Torch ON UV Torch OFF UV Torch Bluetooth Torch ON!
  • Page 13 3. QUICK START GUIDE 3.7) Rotate display Press for the display rotation Screen rotation button Right-handed Left-handed...
  • Page 14 3. QUICK START GUIDE 3.8) Bluetooth SPO-I can connect to Smartpro App just need active the Bluetooth! Bluetooth ON Bluetooth OFF Download the Smartpro App using these QR Code:...

  • Page 15: Features And Advantages

    4. FEATURES AND ADVANTAGES 4. FEATURES AND ADVANTAGES 4.1) FEATURES 3 in 1 Distinguisher: Beep sound indicator Natural Diamonds Auto Testing Function All types of Synthetic Moissanites No warm up time before testing Synthetic CVD / HPHT Diamonds Automatic Power OFF NOTE: CZ ,GGG ,YAG ,Glass, and other Simulants can’t be tested.
  • Page 16 4. FEATURES AND ADVANTAGES 4.2) Advantages : Torch mode for diamond fluorescent test Display by 2.4" colorful Touch LCD LED light source mercury-free Right and Left-hand user-friendly Easy to operate with Touch screen Bluetooth connectivity...

  • Page 17: Product Specifications

    5.PRODUCT SPECIFICATIONS 5.PRODUCT SPECIFICATIONS Device Dimensions 57 (W)x177.5(L)x30(H) mm. Device Weight 160 g. Device Display 240x320pixels LCD 2.4 inches Touchscreen Device Input 5 V / 1-2 A. Dimension 65.5x133x10.1 mm. Power Bank Weight 120 g. Capacity 5000 mAh. Input 5 V/ 2.0 A. Output 5 V/ 2.1 A.

  • Page 18: Device Accessories And Overview

    6. DEVICE ACCESSORIES AND OVERVIEW 6. DEVICE ACCESSORIES AND OVERVIEW 6.1) Device Accessories 1. OPTIMUM-I Tester 2. Power adaptor 3. Power bank 4. USB cable 5. Cleaning cloth 6. Stone tray...
  • Page 19 6. DEVICE ACCESSORIES AND OVERVIEW 6.2) Device Overview 1. Micro USB port 2. Power switch 3. Buzzer 4. LCD touch screen 5. LED light source 6. Test probe 7. Probe tip protector 8. Battery Percentage 9. USB type A Output Port 10.
  • Page 20 6. DEVICE ACCESSORIES AND OVERVIEW 6.3) Display Overview 1. Start/Stop Testing 2. Status and Results 3. UV Torch 4. Rotate display 5. Bluetooth Connectivity Bluetooth UV Torch Press Start!

  • Page 21: Powering The Device

    7. POWERING THE DEVICE 7. POWERING THE DEVICE 7.1) USB Plug the cable side of USB to Wall Adaptor or Power Bank and the side of Micro to the device. 7.2) Press and hold the Power Switch for 3 seconds to turn ON the device. Device Turned ON:...
  • Page 22 7. POWERING THE DEVICE 7.3) Press and hold the Power Switch for 3 seconds to turn OFF the device. Shutting Down... Device Turned OFF: NOTE: Device will automatically be turned off after 5 minutes of idle.

  • Page 23: Calibration

    8. CALIBRATION 8. CALIBRATION 8.1) After turning ON the device make sure that the probe tip protector is attached to the tester’s probe before pressing the “ START ” button. Click Button to begin the calibration CLOSE the tester's PROBE with its PROTECTOR the press START for calibration...
  • Page 24 8. CALIBRATION 8.2) While the device is calibrating, do not remove the Probe’s protector. Please wait... Don't remove the cover.
  • Page 25 8. CALIBRATION 8.3) Done calibration. Remove the Probe Tip Protector then start testing. Bluetooth UV Torch Press Start...

  • Page 26: Testing Procedures

    9.TESTING PROCEDURES 9.TESTING PROCEDURES 9.1) Press to Begin testing mode. or Press to End testing mode. Note: This button is disabled when the analyzing process is on-going.
  • Page 27 9.TESTING PROCEDURES 9.2) “READY!” will be displayed. Start testing by placing the tester probe tip on the stone’s table. UV Torch Bluetooth...
  • Page 28 Tester’s Setup Tester’s Setup The Tester’s Probe should always be placed on center area as much as possible on the TABLE FACET.
  • Page 29 Tester’s Setup ACCURATE TESTING The Probe’s Tip placed within Table Facet...
  • Page 30 Tester’s Setup INACCURATE TESTING Have an angle between Probe out from the area Have distance between the probe tip and of table facet the probe tip and table table side of the diamond side of diamond...
  • Page 31 9.TESTING PROCEDURES 9.3) If the probe sensor detects nearly object device will start testing. The “READY” will change color from Black to Blue color with beep sound. UV Torch Bluetooth...
  • Page 32 9.TESTING PROCEDURES Bluetooth UV Torch...
  • Page 33 9.TESTING PROCEDURES 9.4) If the testing doesn’t begin please lift the probe again away from Gemstone then there will be a beep sound indicating the object/stone has been detected. Bluetooth UV Torch Ready! if Auto-test doesn’t started, Lift the Probe again. NOTE: Make sure that the UV LEDs are not blocked by anything while testing..

  • Page 34: Test Results

    10. TEST RESULTS 10. TEST RESULTS 10.1) Diamond result: Detected Natural Diamond (Type Ia) Bluetooth UV Torch TEST RESULT...
  • Page 35 10. TEST RESULTS 10.2) Moissaniite result : Detected Synthetic Moissanite Bluetooth UV Torch TEST RESULT...
  • Page 36 10. TEST RESULTS 10.3) CVD/HPHT result: Detected Synthetic Diamond (CVD or HPHT) Bluetooth UV Torch TEST RESULT CVD/HPHT NOTE: For the Natural diamond-type IIa SPO-I will show the result as the CVD/HPHT because it has similarly no Nitrogen impurities.

  • Page 37: Other Features

    11. OTHER FEATURES 11. OTHER FEATURES...
  • Page 38 11. OTHER FEATURES 11.1) UV Torch SPO-I also has a UV torch mode. If help you to view color fluorescence diamond. UV torch mode ON UV torch mode OFF...
  • Page 39 11. OTHER FEATURES 11.2) Rotate display Press Screen rotation button for the display rotation Right-handed Left-handed...
  • Page 40 11. OTHER FEATURES 11.3) Bluetooth SPO-I can connect to Smartpro App just need active the Bluetooth! Bluetooth ON Bluetooth OFF...
  • Page 41 11. OTHER FEATURES 11.4) Test Result Counter T h i s C o u n t e r i s a v a i l a b l e i n t e s t i n g m o d e t o h e l p t o u s e r i n m o n i t o r i n g t e s t c o u n t . T o R e s t a r t t h e c o u n t e r t o z e r o , c l i c k t h e S T O P b u t t o n t h e n c l i c k t h e S T A R T b u t t o n Natural Diamond test count CVD/HPHT test count...
  • Page 42 11. OTHER FEATURES You can download the Smartpro Instrument mobile application from...

  • Page 43: Safety Information

    12. SAFETY INFORMATION 12. SAFETY INFORMATION SPO-I uses UV LEDs that radiate UV light during operations. Since UV light can be harmful to eyes, do NOT look directly into the UV light, even though an optical instrument. In the case of the light reflection, UV protective glasses are required to use in order to avoid damage by the light.
  • Page 44 13. SAFE HANDLING / MAINTENANCE 13.3) Operating temperature of SPO-I is designed to work in ambient temperatures between 32° and 95° F (0° and 35° C) and stored in temperatures between-4° and 113° F (-20° and 45° C). SPO-I can be damaged and tester life shortened if stored or operated outside of these temperature ranges.

  • Page 45: Troubleshooting

    14.TROUBLESHOOTING If Calibration Error please try to restart the tester and do follow the “CALIBRATION PROCEDURES” Calibration Error! Please restart the tester. Code:A609C1555C0583 If the device has no power, check the USB cable is properly connected. If using the Power bank, check the battery level. If empty, charge it before using it.
