Summary of Contents for AWNLUX W5700
-
Page 3: Table Of Contents
CONTENTS Package Components..........3 Preparation..............5 Installation..............6 Motor limit position adjustment........11 Operation.……………………………………………..12 Maintenance..……………………………………..15 WARNING Please read and insure you understood this instruction before install, adjust, service and maintain the awnings. This awning must be installed and serviced by qualified person. Please be sure to take good care of this ma- nual for daily maintenance ! -
Page 4: Package Components
Package Components W5700 DESCIPTION ITEM Fabric lock rail Fabric tube Left arm Right arm M5x40 Hex head screws M6x50 Screw M6x60 Hex head screws Ø4.2x13.5 Self-tapping screw M6X16 Screw Hand crank belt Switch Adjustable rod... - Page 5 Package Components W5700C DESCIPTION ITEM Fabric lock rail Fabric tube Left arm Right arm M5x40 Hex head screws M6x50 Screw M6x60 Hex head screws Ø4.2x13.5 Self-tapping screw M6X16 Screw Hand crank belt Switch Fabric tube connector Adjustable rod...
-
Page 6: Preparation
Preparation 1. Please open the package, and check all the accessories according to the part list are complete. 2. Please confirm that install tools are ready, such as hand drill, tape measure, screwdriver, marker pen and Ladders Etc. 3. According to your purchased awning size, mark the 6 fixation points for installation. (The six fixation-points positions should be calculated according to the calculation formula bellow) Total Width (Upper) Awning Width... -
Page 7: Installation
Imperial Size Measurement position sheet Unit:ft/in 8’ 9’ 10’11’12’13’14’15’16’17’18’19’20’21’ Awning Width 〃 Total Width (Upper) A+2.95 〃 Fabric lock Width A-5.12 〃 Fabric Width A-9.84 〃 Total Width (Bottom) A+2.36 〃 Folded arm Height 77.17 〃 Extension (Max.) REMARK: “A”=Awning width (Left arm center to right arm center) Please check the above measurement sheet carefully, and calculate the correct installation position accordingly. - Page 8 2. Install the open arm in the pre-marked installation position, as shown in Pic.2 & Pic.3-a. Please put the belt behind the arm before installation, see Pic. 3-b. Pic.2 Pic.3 3. After arms are fixed, please use offered belt tie up the left & right arm , avoiding private injure see pic.3-c ATTENTION ! If you choose our modular type(W5700C)
- Page 9 fabric tube fabric tube connector 2. Roller tube fabric fixation a. Insert the poly cord into valance fabric slop.See Pic.a b. Finished step “a” and slide the valance fabric into groove No.1. See Pic.b c. Pull the fabric to hole No.2 direction. d.
- Page 10 Step.3 Fabric fixation on Car Find out the poly cord and get across fabric loop, then put the fabric into the fabric lock rail, see Pic.5 Fabric poly cord Pic.5 Step.4 Please install the roller tube on the left arm and right arm , see PIC.6 Remark: Please Be sure the connect motor part is on right arm.
- Page 11 Step.7 After adjust motor limit position, Please open the awning completely, and remove the temporary wires.Please Connect the power cord of the motor from the hole on the right side arm, then connect with cable which put inside of the arm, and then hide the connector in the protection shell, See Pic.8.
-
Page 12: Motor Limit Position Adjustment
Step.10 Motor (DC 12V) limit position adjustment. Motor limit position: To control awning close or open max. position by adjusting the winding number of the motor's positive and negative direction Upper hole control awning close CLOSE Bottom hole control awning open OPEN Pic.11 Remark:... -
Page 13: Operation
How to operate awning OPEN AWNING Attention: Maintain a horizontal distance of at least 2.5m between fully open awning and any permanent object. Do NOT face awning toward permanent objects that may interfere with awning operation.Failure to obey this caution could result in injury. Switch Appearance May Vary Pic.15 Switch instructions... - Page 14 2. Keep CLEAR of openings around adjustable pitch arm assembly while adjusting awning pitch (slope). Adjustable pitch arm assembly (bottom arm) will telescope. Failure to obey this caution could result in injury.Do NOT allow corner of entry door to contacts awning fabric. Otherwise, obrading wear or tearing of awning fabric could be occured.Pull top arm assembly down to lower FRTA to desired height.While holding top arm assembly in place, tighten adjustable knob to set pitch (slope).
- Page 15 4.Close Awning a. Loosen adjustable knobs to allow awning to reset to original position. Then lightly tighten knobs on both arm assemblies to help ensure rattlefree travel.Pull top arm assembly down to verify knob is NOT too tight. Adjustable pitch arm as-sembly MUST still slide as normal. see Pic.15 b.
-
Page 16: Maintenance
ATTENTION Failure to obey the following notices could damage product or property! 1.Precautions: Failure to obey the following notices could damage product or property a. Do NOT use insecticides or other sprays near awning fabric. These could cause stains, and could adversely affect fabric’s ability to repel water. b.
