Page 1: Table Of Contents
If you are not entirely satisfied with this Unpacking product, please return it to the nearest ALDI store within 60 days from the date of purchase, for a full refund or replacement, or take advantage of our Intended use after sales support by calling the supplier’s Customer Service Hotline.
Page 2: Contents Of Box
Overview/Utilisation Utilisation Contents of Box Contents of Box 1x Motor unit (6) 1x First blower tube (4) 1x Second blower tube (5) 1x Graduated fuel bottle (15) 1x Tool with screwdriver and spark plug wrench (16) 1x Capacity bag (17) 1x Bent tube (18) 1x Vacuum tube (19) 1x Suction vacuum tube (20)
Page 3 Utilisation...
Page 4: Explanation Of Symbols
Explanation of symbols Explanation of symbols Read and observe operating instructions and safety instructions before commission- ing! Wear eye protection. Warning! Denotes risk of personal injury, loss of life, or damage to the tool in case of non-observance. Warning! Risk of injury! Never put your hands close to the blades.
Page 5: Introduction
Introduction Wear robust footwear and work gloves when using the device! Air speed vacuum/blower. Warranty class. One year warranty. I. INTRODUCTION Congratulations on choosing to buy a FERREX® product. All products brought to you by FERREX® are manufactured to the highest standards of performance and safety, and as part of our philosophy of customer service and satisfac- tion, are backed by our comprehensive 1 Year Warranty.
Page 6: Layout
Layout/Unpacking and carefully observed by each operator prior to starting the work. Only persons who have been trained in the use of the Petrol Blower Vacuum and have been informed on the related dangers and risks are allowed to use the Petrol Blower Vacuum. The required minimum age must be met.
Page 7: Intended Use
Unpacking/Intended use • Inspect the equipment and accessories for transport damage. In case of complaints the supplier is to be informed as soon as possible. • If possible, keep the packaging until the end of the guarantee period. • Read the operating instructions to make yourself familiar with the device prior to using it. •...
Page 8: General Safety Warnings
Intended use/General Safety Warnings • The device must not be used for commercial, technical or industrial applications. • If you are not sure whether working conditions are safe or unsafe, do not work with the machine. WARNING! For your own safety, please thoroughly read this manual and the general safety instructions before turning the device on.
Page 9 General Safety Warnings • Do not wear wide clothing or jewellery. Wear long trousers to protect your legs. Wear safety helmet for long hair. Loose clothing, jewellery, and long hair can get caught in the moving parts. Wear suitable and du- rable tight working clothes.
Page 10 General Safety Warnings Usage and treatment of the device • Do not overload the appliance. Use the correct tool for your work. You will be able to work better and more safely within the given perfor- mance boundaries. • Do not use an device with a defective switch. An device tool that cannot be switched on or off is dangerous and must be repaired.
Page 11: Technical Data
Technical data • To reduce the fire risk keep the motor and silencer free from cutting re- mainders, leaves and lubricants. • Keep handles dry, clean and free of fuel mixture. • Do not refuel a running engine or an engine that is hot. Residual risks Even if used properly, residual risks can exist even if the relevant safety regulations are complied with due to the design determined by the in-...
Page 12: Attachment And Operation
Technical data/Attachment and operating Subject to technical changes! Information concerning noise emission measured according to relevant standards: Sound pressure = 97 dB(A) Sound power = 108.4 dB(A) Guaranteed sound power level: L = 110 dB(A) Uncertainty = 3 dB(A) Wear ear-muffs. The impact of noise can cause damage to hearing.
Page 13 Attachment and operating the tube and turn it 90° clockwise, in order to permanently fix it in place. • Fix the first blower tube (4) to the air outlet using the screw (K) and its washers (L). • Align the second blower tube(5) compartment with the protrusion (P) of the first blower tube, push the tube and turn it 90°...
Page 14 Attachment and operating • That all moving parts move smoothly. • That the protective flap (E) is closed and that all security switches (F) are activated (fig. 15). Fuel and oil Recommended fuels Use only a mixture of unleaded petrol and special 2-stroke engine oil. Mix the fuel mixture as indicated in the fuel mixing table.
Page 15 Attachment and operating • Wear safety gloves. • Avoid contact with skin and eyes. • Make sure you observe the “Safety Instructions” paragraph. • Only ever refuel the tool outdoors or in sufficiently ventilated rooms. • Clean around the filling area. Contaminants in the tank will cause operating prob- lems.
Page 16 Attachment and operation PREPARE THE MACHINE The machine can be used as both a blower and a vacuum collector. For both of these uses it is necessary to correctly arrange the appropriate accessories included with the equipment. Warning: Unpacking and completing the assembly should be done on a flat and stable surface, with enough space for moving the machine and its packaging, always making use of suitable equipment.
Page 17 Attachment and operation Note: If the engine does not start up even after several attempts, read the section „Engine troubleshooting“. Note: Always pull the starter cord out in a straight line. If it is pulled out at an angle, then friction will occur on the eyelet.
Page 18 Attachment and operation To empty the bag: • Switch the engine off. • Open the zipper and empty the bag without disconnecting it from the fitting tube. • IMPORTANT When used as a vacuum collector do not collect damp grass or leaves to avoid clogging the rotor and bag.
Page 19: Working Instructions
Working instructions VIII. Working instructions Operation • Do not smoke while refuelling or operating equipment. • Do not touch or let your hands or body come in contact with a hot muffler or spark plug wire. • Due to the danger of exhaust fumes, never operate blower in a confined or poorly ventilated area.
Page 20: Maintenance
Maintenance IX. Maintenance Important! Always pull out the spark boot plug each time before carrying out any cleaning. Never immerse the equipment in water or other liquids in order to clean it. Store the petrol multi-garden tool in a safe and dry place out of the reach of children. Cleaning •...
Page 21 Maintenance Clean the air filter (Fig. 4) Soiled air filters reduce the engine power by supplying too little air to the carburetor. Dust and pollen plug up the pores of the filter made of foamed plastic. Regular checks are therefore essential. •...
Page 22 Maintenance/Storage Service information Please note that the following parts of this product are subject to normal or natural wear and that the following parts are therefore also required for use as consumables. Wear parts*: Spark plug, Air filter, Fuel filter, Capacity bag * Not necessarily included in the scope of delivery! X.
Page 23: Storage
Storage/Disposal and recycling Transport • Allow the engine to cool down (approx. 5min). • Empty the capacity bag if necessary. • Make sure that the Petrol Blower Vacuum is always in an upright position so that no fuel can escape. Secure the unit against tipping over! XI.
Page 24: Troubleshooting
Troubleshooting XII. Troubleshooting The table below contains a list of fault symptoms and explains what you can do to reme- dy the problem if your equipment fails to work properly. If the problem still persists after working through the list, please contact your nearest service workshop. Important hint in case of sending the equipment to a service station: Due to security reasons please see to it that the equipment is sent back free of oil and petrol!
Page 25 Troubleshooting Machine does not • Air filter is contaminated. • Clean the air filter or replace work at full power. • Carburetor set up incorrectly. • Contact the service centre. • Capacity bag is full • Check the exhaust. • Capacity bag is dirty •...
Page 26: Warranty Details
Petrol Blower Vacuum Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.
Page 27: Repair And Refurbished Goods Or Parts Notice
Please be assured though, refurbished parts or replacements are only used where they meet ALDI’s stringent quality specifications. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your com- plaint.
Page 28 In the event of a product fault, please call the Customer Service hotline. Please ensure that you have the product details (as shown on this card) at hand so that we are able to respond quickly and eciently as possible. You can also register your product at https://www.aldi.com.au/en/about-aldi/product-registration/ to keep up-to-date with important product information.
Page 29 To Make a Claim This warranty against defects is provided by ALDI Stores, Locked Bag 56, St Marys Delivery Centre, NSW 2760, Phone (02) 9675 9000. If a defect in the goods appears within 1 year (the identified period on the packaging), you are entitled to claim a warranty, please contact or send all warranty claims to: ROSSMAC PTY.
