FL20 USER MANUAL TABLE OF CONTENTS 1. Important safety information 1.1. Prevent accidents and risks to health 1.2. Prevent product damage and malfunction 1.3. Operation 2. General description 3. Operation 3.1. Adjusting the headset 3.2. Adjusting the microphone position (FL20 IA & FL20 P) 3.3.
• Only clean the product with a soft, dry cloth. Never repair or attempt to repair a faulty product yourself. Contact FACTEM. Only replace the product parts for which the replacement instructions are described in this manual. All other parts of the product must be replaced by a certified repair partner.
1.3. Operation The intended operation of the product involves: • Having read and understood this manual, particularly the chapter “Important safety information” on page 3. • Only using the product in the conditions and limitations described in this manual. “Incorrect usage” means using the product in a way not described in this manual. 2.
3. OPERATION 3.1. Adjusting the headset Place the set on the head by pulling the eardomes apart , and centring them on the ears, then adjust the height of the stems and the position of the headbands to change support points. 3.2.
3.3. Flip-away eardome The eardome without the microphone can be pulled back to free up the ear. 3.4. Adjusting microphone sensitivity (FL20 IA & FL20 P) The sensitivity of the microphone can be adjusted: • Remove the windshield. • Use a mini flathead insulated screwdriver*. •...
3.5. Using the ANR function To activate the ANR function, flip the switch upwards on the microphone- equipped eardome. The LED indicator on the opposite eardome will illuminate. 4. CLEANING AND MAINTENANCE 4.1. Warning The use of liquids is prohibited. Liquids can penetrate the headset and cause short-circuits.
4.2. Replacing the earpads For hygiene and comfort, it is recommended to replace the earpads at least once per year. To remove an earpad, pull firmly on the side to release it from the eardome. Insert the lip behind the earpad into the eardome groove rotate it competely round to fully install it 4.3.
7.5. Wiring CS20-10-20X5 Cable SIGNAL Audio Hi Audio Lo / (DC-) Microphone Hi Microphone Lo Power Supply (DC+) CS20-10-20P5 Cable SIGNAL Audio Hi Audio Lo CS20-10-20N8 Cable SIGNAL Audio Hi Audio Lo Microphone Lo Microphone Hi (DC-) Power Supply (DC+) •...
Audio Lo (DC-) Power Supply (DC+) Microphone Hi Microphone Lo WARRANTY AND COMPLIANCE Warranty FACTEM guarantees the product for 4 years. Warranty conditions are available on the site www.factem.com Statement of compliance • RoHS Directive • Reach Directive ETSO ETSO/TSO C139a...
Page 13
MANUEL D'UTILISATION FL20 TABLE DES MATIÈRES 1.Informations de sécurité importantes 1.1. Prévenir les problèmes de santé et les accidents 1.2. Prévenir les dommages au produit et les dysfonctionnements 1.3. Utilisation 2.Description générale 3.Utilisation 3.1. Ajuster le casque 3.2. Régler la position du microphone (FL20 IA & FL20 P) 3.3.
• Nettoyer le produit uniquement avec un chiffon doux et sec. Ne jamais réparer ou tenter de réparer vous-même un produit défectueux. Contacter votre partenaire FACTEM. Ne remplacer que les pièces du produit dont le remplacement est décrit dans ce manuel. Toutes les autres parties du produit doivent être remplacées par un réparateur agréé.
1.3. Utilisation L’utilisation prévue du produit implique : • D’avoir lu et compris ce manuel, en particulier le chapitre « Informations de sécurité importantes » à la page 3. • D’utiliser le produit dans les conditions d’utilisation et les limitations décrites dans ce manuel.
3.UTILISATION 3.1. Ajuster le casque Placer le casque sur la tête en écartant les cavités , centrer les oreillettes sur les oreilles, ajuster la hauteur des fourches et l’écartement des lames d’arceau pour changer les points d’appui du casque. 3.2. Régler la position du microphone (FL20 IA &...
3.3. Escamoter la cavité La cavité opposée au microphone peut être basculée vers l’arrière pour libérer l’oreille. 3.4. Ajuster la sensibilité du microphone (FL20 IA & FL20 P) La sensibilité du microphone peut être ajustée : • Enlever la bonnette anti-vent. •...
3.5. Utiliser la fonction ANR Pour activer la fonction ANR, basculer le bouton de la cavité équipée du microphone vers le haut. Le témoin LED de la cavité opposée est allumé. 4.NETTOYAGE ET ENTRETIEN 4.1. Précautions L’utilisation de liquides est interdite. Les liquides peuvent pénétrer dans le casque et entrainer des courts-circuits.
4.2. Remplacement des oreillettes Pour l’hygiène et le confort, il est recommandé de remplacer les oreillettes au moins une fois par an. Pour enlever une oreillette, tirer fortement sur le côté pour séparer celle-ci de la cavité. Insérer l’ourlet arrière de l’oreillette dans l’encoche de la cavité...
7.5. Câblage Câble CS20-10-20X5 Contact SIGNAL Audio Hi Audio Lo / (DC-) Microphone Hi Microphone Lo Alimentation (DC+) Câble CS20-10-20P5 Contact SIGNAL Audio Hi Audio Lo Câble CS20-10-20N8 Contact SIGNAL Audio Hi Audio Lo Microphone Lo Microphone Hi (DC-) Alimentation (DC+) •...
Audio Lo (DC-) Alimentation (DC+) Microphone Hi Microphone Lo 8. GARANTIE ET CONFORMITÉS Garantie FACTEM garantit le produit 4 ans. Les conditions de garantie sont consultables sur le site www.factem.com. Déclaration de conformité • Directive RoHS • Directive Reach ETSO ETSO/TSO C139a •...
Page 24
SALES OFFICE Bureaux Commerciaux 8, rue Edouard Naud 92130 Issy les Moulineaux France FACTORY Usine 32, route de Caen 14406 - Bayeux Cedex France Tel : + 33 2 31 51 27 51 contact@factem.com WWW.FACTEM.COM...
