Split type wall mounted air conditioner

Advertisement

SPLIT TYPE WALL MOUNTED AIR CONDITIONER
USER'S
MANUAL
Read the manual carefully before operation and keep it for reference.
This manual is only for reference, please comply with actual appliance
you selected. manufacturer hold the authority to redesign or modify its
products without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7K and is the answer not in the manual?

Questions and answers

DALE
May 19, 2025

MINI SPLIT STUCK IN COOLING MODE.DOES NOT CHANGE USING REMOTE

1 comments:
Mr. Anderson
May 23, 2025

The CONFORTotal mini split model 7K may be stuck in cooling mode and not responding to the remote due to one or more of the following reasons based on the manual:

1. Fan speed control limitations: In some modes like SWEEP or dehumidifying operation, temperature and fan speed settings cannot be adjusted, and the remote may seem unresponsive.

2. Heating overload prevention: If the unit is in HEAT mode and enters overload prevention, fan speed control is disabled, which may cause the unit to behave as if stuck in cooling.

3. Remote issues: If the clock or timer settings are not set correctly, certain remote functions may not work as expected.

4. Power or connection issues: If the unit is not properly grounded, or if there is damage to the power cord or plug, the unit may not respond correctly.

Check the mode settings, ensure proper electrical connection, inspect the remote control for correct settings, and verify that the unit is not in a restricted operation mode.

This answer is automatically generated

Randy Stoppenhagen
April 29, 2025

My A/C's are set at (max) 32C (89.6F), but the room temp will not get above 76F. Leaving (FL) for the summer, and want to keep my house temps around 83F. All 3 do the same thing! How can I get my AC's from cooling so much?

1 comments:
Mr. Anderson
May 15, 2025

To maintain a room temperature around 83°F (about 28°C) instead of cooling to 76°F (about 24°C), use the temperature adjustment buttons on the remote control. Press the “▲” button to increase the temperature setting up to your desired level. The air conditioner allows temperature settings between 16°C and 32°C (about 61°F to 90°F). Set it to 28°C to maintain around 83°F.

This answer is automatically generated

Evelyn
January 27, 2025

what settings should heat be at?

1 comments:
Mr. Anderson
May 14, 2025

The recommended heating temperature range for the CONFORTotal 7K is -7℃ to 43℃ for standard models and -7℃ to 52℃ for T3 models.

This answer is automatically generated

James Gowen
May 15, 2025

How do I change over from Celsius to farnheit

Sandy
April 25, 2025

How do you change from Celsius to Farhanheit

Michael mayo
March 10, 2025

Have a 12k cicon121-c is the 110 plug the power supply for the indoor and out door units?

Subscribe to Our Youtube Channel

Summary of Contents for CONFORTotal 7K

  • Page 1 SPLIT TYPE WALL MOUNTED AIR CONDITIONER USER’S MANUAL Read the manual carefully before operation and keep it for reference. This manual is only for reference, please comply with actual appliance you selected. manufacturer hold the authority to redesign or modify its products without notice.
  • Page 2 SAFETY PRECAUTIONS Following these basic precautions will reduce the WARNING: risk of fire, electrical shock, injury or death when using your air conditioner. 1. Air conditioner must be connected to proper electrical outlet or breaker with the correct electrical supply. And only the specified power can be used. 2.
  • Page 3: Table Of Contents

    USER’S MANUAL CONTENTS 1. SAFETY INSTRUCTIONS Symbol Description…………………………………………………..……….………..….2 Installation Instruction…………………………………………………..…….……….…. 2 Operating Instruction………………………………………………………….……….…..3 Safety Instruction… …………………………………………………………..……….… 6 2. PRODUCT INTRODUCTION Protect Functions………………………………………………….. …….….………….…7 3. DESCRIPTION OF COMPONENTS View of Unit………………………………………………………………………...…………8 Display screen………………………………………………………………….……..……...9 Indicator light………………………………………………………………….……..……. 9 Remote Controller…………….……………………………..……………….….………..10 Remote Controller Display…………………………………………………….………….11 4.
  • Page 4: Safety Instructions

    USER’S MANUAL SAFETY INSTRUCTIONS 〖Symbol Description〗 A symbol indicating operation which may cause personnel Warning: casualties or serious damages. A symbol indicating operation which may cause personnel Caution: casualties or property damages. 〖Installation Instruction〗 Warning  Never install by yourself Split type air conditioner will work for you for a long period of time if it is correctly installed.
  • Page 5: Operating Instruction

    USER’S MANUAL 〖Operating Instruction〗 WARNINGS Following the safety messages is very important. These messages can save you from being injured or killed. Warning symbols alert you to be careful and means danger. Always follow instructions to be safe and reduce chances of injury or death.
  • Page 6 USER’S MANUAL 7. The fuse for indoor unit main board: T3.15AL 250V~(9K-22K); The fuse for indoor unit main board: T 5AL 250V~(18K-24K); The fuse for outdoor unit main board: T15AL 250V~or T20AL 250V~(9K-12K); The fuse for outdoor unit main board: T30AL 250V~(18K-24K); Tips ...
  • Page 7 USER’S MANUAL 〖Operating Instruction〗 Use the specified power cord; do not Only single-phase a.c. power can be used. change it. please refer to nameplate for details. Do not put fingers or sticks into the inlet or Do not put anything on the outdoor unit. outlet of air conditioner;...
  • Page 8: Safety Instruction

    USER’S MANUAL 〖Safety Instruction〗 The appliance is not intend for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance. If the supply cord is damaged, it must be replaced by the manufacturer Warning or its service agent or a similarly qualified person in order to avoid a hazard.
  • Page 9: Product Introduction

    USER’S MANUAL PRODUCT INTRODUCTION 〖Protect Functions〗 Protect functions can prolong the air conditioner’ s service life and provide more comfortable airflow. Delay-starting protection for the compressor The compressor will restart working at least 3 minutes after being turned off to keep the pressure balance of the cooling system.
  • Page 10: Description Of Components

    USER’S MANUAL DESCRIPTION OF COMPONENTS 〖View of Unit〗 Air inlet Indoor unit Air outlet Power cord Pipe and wires Outdoor unit Air inlet(back) Air outlet Drain pipe Remarks: The air conditioner is consisting of indoor unit, outdoor unit and remote controller. The design and shape are different for different models.
  • Page 11: Display Screen

    USER’S MANUAL 〖Display screen〗 “RUN” indicator:This signal light is on when the unit is When is in “RUNNING” status. in Defrosting or Cooling airflow proof ,the indicator is flashing “TIMER” indicator:This signal light is on when the unit is in Timer. “compressor”...
  • Page 12: Remote Controller

    USER’S MANUAL 〖Remote Controller〗 Display Screen For setting display DISPLAY Button start stop DISPLAY when conditioner is in RUNNIG. SWING Button vertical For changing Sleep Button blades position swing or not. For setting sleep function. Mode selection Button For selecting On/Off Button AUTO HEAT...
  • Page 13: Remote Controller Display

    USER’S MANUAL 〖Remote Controller Display〗 Operating Mode Selection Display Turbo Display AUTO It appears when turbo function is set in COOLING or HEAT HEAT Signal Emission Symbol COOL mode, and will flash. It appears when control signal is emitted. SWEEP Wind Speed Selection Setting temp Display Display...
  • Page 14: Operating Method

    USER’S MANUAL  Don’ t sprinkle water or juice on the remote controller, use soft cloth for cleaning if it occurs.  The batteries must be removed from the appliance before it is scrapped and that they are disposed of safety. OPERATING METHOD 〖AUTO, HEAT, COOL,SWEEP and DRY operation〗...
  • Page 15: Clock Setting And On Timer

    USER’S MANUAL 〖Clock Setting〗 Press “Set Time” button to select to set time , hour of clock display will flash. Press “HOUR” button to change the hour display, each press of Hour button will increase the time display by 1 hour; hour display will be changed continuously when pressing it continuously.
  • Page 16: Off Timer And Program Control

    USER’S MANUAL 〖Off Timer〗 Set the clock time as 〖Clock Setting〗, Press “Set Time” button to select “Timer OFF” , hour of clock display will flash. Press “HOUR” or “MINU” button; set the time to turn on the air conditioner on timer.
  • Page 17: Emergency Run

    USER’S MANUAL 〖Emergency Run〗 When the remote controller is missing or the batteries are run out, you can use the Emergency Button Operation Method: Under the “OFF” condition, open the front board and press Emergency Button with the tip end of a ball-pen or the like and the Air conditioner will operate in “AUTO”...
  • Page 18: Service And Maintenance

    USER’S MANUAL SERVICE AND MAINTENANCE Careful maintenance and overhaul in advance can prolong the air conditioner’ s service life and save electricity charges. Caution: 1. Stop air conditioner by remote controller and pull off the plug before service and maintenance. 2.
  • Page 19: No Use For Long Time

    USER’S MANUAL 〖No Use for Long Time〗 1. Swing 3-4 hours to dry the internal 2. Stop operation by remote controller, then air conditioner. cut off the power source of air conditioner. 3. Maintain air filter net. 4. Take out batteries from remote controller. -17-...
  • Page 20: Recommendations For Energy Saving

    USER’S MANUAL 〖Recommendations for Energy Saving 〗 Avoid Direct Sunlight Appropriate Temp Setting When it is cooling, please use curtain or It is harmful to health if the room is too cold. blind to obstruct direct sunlight. Close Doors and Windows Avoid Heat Sources Incoming outdoor air will affect the cooling When it is cooling, using other heat sources...
  • Page 21: Troubleshooting

    USER’S MANUAL TROUBLE SHOOTING 〖Air Conditioner is in Error〗 Normal phenomena normal phenomenon Reason Plastic parts of indoor unit make sounds During cooling, plastic parts expand with heat and contract with cold. During cooling, water drops are generated If the indoor humidity is too large, the from indoor unit.
  • Page 22: Remote Controller Is In Error

    USER’S MANUAL Failure inspection Please conduct the following inspections before maintenance. Failure Inspection items phenomena 1. Whether the power line is installed well or not? 2. Whether fuse of power supply is fusing or circuit breaker is open. Air conditioner 3.
  • Page 23: Normal Phenomenons

    USER’S MANUAL NORMAL PHENOMENONS When it is heating or cooling, plastic f the indoor humidity is too high, water substance may give out a sound because of drops may form on the front grill of indoor the temperature change. unit. This is a normal phenomenon. There may be gentle “rustle”...
  • Page 24 INSTALLATION MANUAL 〖Installation Guide〗  This air conditioner meets the safety and operation standards promulgated by the Nation.  You need to invite professional air conditioner service and maintenance personnel to install or remove the air conditioner. Problems may occur and you may suffer losses if non- professionals install the air conditioner.
  • Page 25  The all figures are only schematic, and they may be slightly different from the actual appliances you selected. 〖Position for Outdoor Unit〗  Avoid direct sunlight.  Away from heat source, steam source, leakage of flammable gas, smoke and dust. ...
  • Page 26 Tubing Size Standard tubing Max tubing Height Additional Difference (m) refrigerants(g/.m) Length (m) Length (m) Narrow (mm) Wide (mm) φ6.35(1/4”) φ9.52(3/8”) φ6.35(1/4”) φ12.7(1/2”) φ6.35(1/4”) φ15.88(5/8”) φ9.52(3/8”) φ15.88(5/8”) 〖Fixing Installation Panel〗  Dismantle the metal installation board of the indoor unit. Adjust the mounting panel to horizontal position.
  • Page 27 〖Indoor Unit Installation〗 The tube may be connected in several directions as below shown Figures. 1. Connecting right back tube (similar to right lower tube) (Optional, Pipeline Refer to Fig.7)  Pull out the tubing from bottom of the chassis; and connect the drainpipe.
  • Page 28 〖Outdoor Unit Installation〗  If installation brackets for installing outdoor unit are needed, user could buy the brackets from our company or agents(Fig.10).  Assemble the mounting frame and supports with the attached 6 screws , plain washers, spring washers, and nuts. ...
  • Page 29 Screw the table(Table3). Fig.13 Table 3 Power connecting Signal control Power cord wires wire Max. Length ≥ ≥ ≥ 7K/9K/12K/16K 2.5 mm 1.5 mm 1.5mm Cross sectional ≥ ≥ ≥ area 18K/21K/24K/28K 2.5 mm 1.5 mm 2.5 mm...
  • Page 30 7K/9K/12K/16K Brown Brown Brown Blue Blue Blue Yellow/Green Yellow/Green Yellow/Green Gray(White) Black 9 K / 1 2 K / 1 8 K / 2 4 K D C I n v e r t e r Brown Gray Yellow/Green Yellow/Green...
  • Page 31 〖Tube Strapping〗  Strapping with PVC Protective tape must be careful, do not damage the pipeline and drain pipe.  Strapping should start from the lower part of the outdoor unit to the indoor unit.  Fix the PVC tape with adhesive tape to prevent loosing. ...
  • Page 32 〖Exhaust〗 Exhausting type  Make sure that all the tubes of indoor and outdoor unit are connecting well.  Take off valve bonnet and service port valve bonnet from two-port valve (small pipe cut-off valve) and three-port valve (large pipe cut-off valve). ...
  • Page 33  Screw tightly the entire valve bonnet by torque spanner.  Check with soap water or leak detector whether there are leakage at all indoor and outdoors’ connections.  Put the valve bonnet and lid back to position. Fig.17 〖Drainage〗 No need drainage treatment In regions where become cold in the winter, don't install the drain elbow joint to prevent drain water from freezing and causing the fan to be damaged.
  • Page 34 Installation for the cover of valve( Optional For the whole unit that individual cover of valve is available (refer to packing list), the installing method is as follow: After connecting the connection pipes between indoor and outdoor units followed by the installing method mentioned above, take out the cover of valve from the accessory bag, and fix it on the side of outdoor unit with three corresponding screws ( inside the accessory bag ).
  • Page 36 JUZ3.867.10453...
