Model B Burner

, O

NSTALLATION

PERATION

AND

ERVICE

ANUAL

ACCESS

COMBUSTION, LLC

The manual is not to be disclosed to others without consent of Access Combustion.

Unauthorized use is expressly forbidden.

For Information, Service, or Repair Please Contact:

Access Combustion, LLC.

www.Access-combustion.com

Phone: 918-576-7100

E-Mail: sales@accessburner.com

WARNING: Only Factory Authorized Burner Service Personnel Should Start, Adjust, or Service This

Equipment

Table of Contents

Summary of Contents for Access Combustion B

Page 1: Installation, Operation, And Service Manual
Copyright 2018 © by Access Combustion LLC. All rights reserved. This document is a proprietary property of Access Combustion, LLC. The manual is not to be disclosed to others without consent of Access Combustion. Unauthorized use is expressly forbidden. For Information, Service, or Repair Please Contact: Access Combustion, LLC.
Page 2: Table Of Contents
ACCESS COMBUSTION, LLC ABLE OF ONTENTS Installation, Operation, and Service Manual ......................1 Section I: General Safety and Warnings ........................3 Installation Checklist ..............................4 Section III: Burner Installation ............................6 Typical Gas Train ................................ 7 Gas Train Pressure Test ............................. 8 Electrical Connection ..............................
Page 3: Section I: General Safety And Warnings
Improper operation of the equipment will result in injury to persons or loss of life and damage to equipment. Access Combustion shall assume no responsibility for the improper or unsafe operation of the burner due to failure to adequately address the concerns above.
Page 4 Air Inlet Damper FGR Damper Access Combustion Model B, Package Forced Draft Burner utilizes stage fuel design and with flue gas recirculation (FGR) achieves Ultra-Low NOx emissions and near zero CO emissions when corrected to 3% O2. Fuel is delivered to the burner via the gas inlet pipe and is mixed with air inside the burner housing. Portion of the fuel is forced into the center of the diffuser.
Page 5: Installation Checklist
ACCESS COMBUSTION, LLC NSTALLATION HECKLIST Warning: Make sure the checklist is reviewed and verified before proceeding to Burner Commissioning section. Burner Check List Is the burner securely connected to the heat exchanger? Is the front plate properly installed and secured inside the heat exchanger?
Page 6: Section Iii: Burner Installation
ACCESS COMBUSTION, LLC III: B ECTION URNER NSTALLATION Page 6 of 19 WARNING: Only authorized burner service personnel should start, adjust, or service this equipment! Rev. 05...
Page 7: Typical Gas Train
ACCESS COMBUSTION, LLC YPICAL RAIN The gas outlet pressure setpoint adjustment screw is in the center of the regulator cover. Clockwise rotation of the setpoint adjustment screw increases the outlet gas pressure. Counterclockwise rotation decreases the outlet gas pressure. The hexagonal cap must be tightened after the setpoint screw has been adjusted and may be sealed from tampering by means of a wire and lead seal.
Page 8: Gas Train Pressure Test
Close the incoming gas valve if main gas pressure exceeds maximum pressure ratings on the gas train. b. Contact your local gas supply company for pressure adjustment. Contact Access Combustion Representative. 3. Check for gas leaks between main incoming gas and valve (2) on the gas train by either performing a bubble test or measuring gas pressure.
Page 9: Burner Sequence Of Operation
ACCESS COMBUSTION, LLC URNER EQUENCE OF PERATION Refer to a Specific Burner Management System (BMS) Manual provided with the burner for detailed information and control sequence timing information. 1. Burner is energized when demand is activated by heat exchanger limit switch.
Page 10: Section Iv: Burner Commissioning
Spark Pickup condition is present when the BMS doesn’t show an alarm and allows the main gas valves to open. Spark Pickup condition is not a safe operating condition and must be corrected before proceeding with commissioning the burner. Please contact Access Combustion Service Department for resolution. Page 10 of 19 WARNING: Only authorized burner service personnel should start, adjust, or service this equipment! Rev.
Page 11: Pilot Commissioning
13. Adjust pilot pressure. For more pressure adjust pilot pressure regulator by turning adjusting screw IN (clockwise). b. For less pressure adjust pilot pressure regulator by turning adjusting screw OUT (counterclockwise). Pilot gas pressure should be between 6 to 10inch W.C. (15 to 25mbar) 14.
Page 12: Main Flame Commissioning
ACCESS COMBUSTION, LLC LAME OMMISSIONING Caution! Make sure pilot flame signal is within BMS operation range before proceeding to the main flame test. The burner is factory adjusted for “dry run” conditions. Adjustments and initial settings MUST BE CHECKED prior to initial light off and settings MUST BE VERIFIED by combustion tests.
Page 13: Adjustment Of Air Flow Switch
ACCESS COMBUSTION, LLC DJUSTMENT OF WITCH Air flow switch is used to prove the flow of combustion air from the blower assembly. It causes a lockout and burner shutdown upon loss of or inadequate combustion air. Switch should be set to open when combustion air is below minimum fire set point.
Page 14: Adjustment Of Gas Pressure Switch
ACCESS COMBUSTION, LLC DJUSTMENT OF RESSURE WITCH Gas pressure switches may or may not be supplied with the burner. They are optional and depending on the local code and regulations, the size of the burner and job specific requirements. Gas pressure switches are pressure activated switch devices designed for safety shutoff when the gas pressure is either too high or too low.
Page 15: Section V: Maintenance
ACCESS COMBUSTION, LLC V: M ECTION AINTENANCE ENERAL AINTENANCE DAILY MAINTENANCE Observe the operation of the burner and operating controls to determine proper burner operation. Visually inspect the condition of the filter assembly. If the burner is installed on a boiler.
Page 16: Pilot Troubleshooting
ACCESS COMBUSTION, LLC ILOT ROUBLESHOOTING A problem with pilot operation is one of the most common problems to occur in a burner system. Typically, these problems are due to improper adjustment or maintenance. This list is intended to cover the most common pilot problems which occur and potential actions to take.
Page 17: Pilot Assembly
Make sure spark rod is clean and free of corrosion and/or soot. b. Make sure the spark rod location is as shown and the gap between spark rod and ignition tube is set to 1/8 inch. If not, the spark rod may be gently bent back into the proper position.
Page 18: Warranty Policy
Equipment, accessories and other parts and components not manufactured by Access Combustion are warranted only to the extent of and by the original manufacturer’s warranty to Access Combustion. In no event shall such other manufacturer’s warranty create any more extensive warranty obligations of Access Combustion to the Buyer than Access Combustion warranty covering equipment manufactured by Access Combustion.
Page 19 (if any) and express warranties, representations, instructions or defects from any cause in connection with the sale or use of the equipment. Access Combustion shall not be liable for any special, indirect or consequential damages or for loss, damage or expense, directly or indirectly arising from the use of the equipment...
