Directions – Brushless Motor Controller (ESC)
Thanks for using DBY Brushless Motor Controllers. Please read the directions carefully before
you start to use new controllers.
Technical details:
Model
FM10A
FM20A
FM30A
FM40A
FM60A
FM80A
FM120A
Diagram for FM10A, FM20A, FM30A
Diagram For FM40A, FM60A, FM80A, FM120A
Main functions:
1.
Start up mode: it is possible to set two start up mode, Soft start up and Hard start up
Current (A)
10
max 1A
20
max 2A
30
max 2A
40
60
80
120
BEC
NiCd/NiMh 6-12
Li-Poly
NiCd/NiMh
Li-Poly
NiCd/NiMh 6-12
Li-Poly
NiCd/NiMh 6-18
No
Li-Poly
NiCd/NiMh 6-18
No
Li-Poly
NiCd/NiMh 6-18
No
Li-Poly
NiCd/NiMh 6-18
No
Li-Poly
Cells
Weight (g)
2-3
6-12
2-3
2-3
2-5
2-5
2-5
2-5
14
20
25
35
55
55
78
Advertisement
Table of Contents
Summary of Contents for DBY Technology FM10A
- Page 1 NiCd/NiMh 6-18 FM80A Li-Poly NiCd/NiMh 6-18 FM120A Li-Poly Diagram for FM10A, FM20A, FM30A Diagram For FM40A, FM60A, FM80A, FM120A Main functions: Start up mode: it is possible to set two start up mode, Soft start up and Hard start up...
- Page 2 Timing mode: Soft timing – for 2, 4, 6 pole brushless motors, Hard timing – for 6 and more pole motors Temperature protection: the controllers have automatic reduce output power with auto detection for temperature (120°C) Note: The controllers are supplied with soft start up and soft timing mode. Operating instructions: -Normal start up: Connect the controller and motor as above connection drawing.
