Summary of Contents for HydraBed ProSpear
- Page 1 PEAR YDRA OWNER’S MANUAL H B B YDRA The Original Flatbed Bale Handler 902 Hwy K246 · P.O. Box 248 Sabetha, KS 66534 (785) 284-3674 · (800) 530-5624 fax (785) 284-3931 website: www.hydrabeds.com...
- Page 2 Thank you for choosing Pro Spear ® /HydraBed. It is a sincere privilege to serve North America’s farmers and ranchers and an opportunity we take seriously. Our goal is to provide the most rugged and reliable equipment while continuing to build on a legacy of innovative products that solve real ranch problems.
- Page 3 (800) 530-5624 OPERATION | Make certain that the upper surface of the unit is clear. | Utilizing the hand held pendant | Back into the flat side of the bale, in the cab of the truck, lower lifting piercing the surface until the rear spears to the bottom of their travel lifting mechanism makes contact by activating the “Unload”...
- Page 4 WWW.HYDRABEDS.COM INSTALLATION PRO SPEAR TO TRUCK CHASSIS Tools Required: 15/16” wrench, 15/16” socket and ratchet or impact wrench, drill with 5/8” bit, welder and low- hydrogen rod or wire, combination square, hammer, pry bar, 7/16” socket and ratchet, wire pliers, Phillips screwdriver. Important Safety Notice: Correct any leakage of liquid or vapors from any part of the fuel system before proceeding! 1) Completely remove all non-factory additions to frame of truck (fifth wheel, rear hitches, etc).
- Page 5 (800) 530-5624 INSTALLATION OF PRO SPEAR HYDRAULICS 1) Mount the hydraulic power pack inside the passenger side underbody toolbox using the two predrilled holes. Secure using two 3/8 x 1” hex head cap screws and two 3/8” lock washers. 2) Position the power pack with the oil reservoir toward the truck cab. 3) Install one of the short 90-degree hydraulic adapters into the valve port marked “UP”.
- Page 6 WWW.HYDRABEDS.COM...
- Page 7 You must properly complete and return the warranty card found at the front of the Owners Manual. What does this Warranty cover? Triple C will warranty the HYDRABED®, ProSpear, HydraFeeder, Post Hole Digger, Across Bed Toolbox, and Dump Box to be free from defects in material and workmanship when properly installed and operated under normal conditions.
