SOLR ® 100% OXYGEN MASK 60410X REPORTING ERRORS AND RECOMMENDING IMPROVEMENTS You can help improve this manual. If you find any mistakes or if you know of a way to improve the procedures please let us know. Mail your letter directly to: Airborne Systems, ATTN: Technical Publications, 5800 Magnolia Ave, Pennsauken, NJ.
Exhaust Valve Disassembly 1. Place mask with the opening facing self. Figure 5-1 Mask Facing Self 2. Gently bend the microphone upwards, exposing the exhaust valve and regulator locking rings. Figure 5-2 Bend Microphone Up 60410X...
Page 10
4. Using the needle nose pliers, remove the locking wire from the exhaust valve assembly and discard. Figure 5-4 Remove Locking Wire 5. Remove exhaust cover by hand and set off to the side. 6. Remove the diaphragm by hand and discard. Figure 5-5 Remove Diaphragm 60410X...
Page 11
PLASTIC PICK. USE OF A METAL PICK CAN RESULT IN DAMAGE TO COMPONENTS. 9. With a plastic pick, remove the sealing ring from the exhaust valve body and discard. Figure 5-8 Remove Sealing Ring 10. Place exhaust housing to the side. 60410X...
3. Place the locking ring and locking washer to the side. 4. Remove dust cap from the quick disconnect and discard. 5. Using a 3/8 socket and driver remove the inlet quick disconnect. Figure 5-11 Remove Inlet Quick Disconnect 60410X...
Page 13
8. Using a 0.05 hex driver, remove the set screw from the regulator housing and discard. Figure 5-13 Remove Set Screw 9. Using the large spanner wheel and socket driver, remove the cap from the regulator body and set to the side. Figure 5-14 Remove Regulator Cap 60410X...
Page 14
Figure 5-16 Remove and Discard Diaphragm CAUTION THE ANTI-SUFFOCATION COVER IS UNDER SPRING PRESSURE. USE CAUTION WHEN REMOVING 12. Using the T8 torx driver, remove the two screws from the anti-suffocation cover and set to the side. Figure 5-17 Remove the Two Hex Screws 60410X...
Page 15
NOTE SLIGHT PRESSURE MAY BE NEEDED TO FREE THE LEVER 17. Using a hollow tip screwdriver, turn the crown clockwise while holding the regulator on its side to free the lever. Figure 5-20 Turn Crown Clockwise to Free Lever 60410X...
Page 16
Figure 5-21 Once Lever Drops Remove it By Hand 19. Remove the insert body by hand. Figure 5-22 Remove Insert Body by Hand 20. Remove the balanced seat by hand from the insert body and discard. Figure 5-23 Remove Balanced Seat from the Insert Body 60410X...
Page 17
22. Remove O-ring ID .364 from the insert body and discard it. Place the insert body off to the side. Figure 5-25 Remove and Discard O-Ring 23. Remove O-ring ID .228 from crown and discard it. Set the crown to the side. Figure 5-26 Remove and Discard O-Ring 60410X...
Page 18
25. Using a plastic pick, remove the sealing ring from the regulator body and discard it. Figure 5-28 Remove and Discard Sealing Ring 26. Using the 0.05 hex screwdriver, remove the set screw from the regulator body and set to the side. Figure 5-29 Remove Set Screw 5-10 60410X...
Page 19
27. Using compressed air, aim the nozzle at the set screw opening and blast with compressed air to remove the balancing chamber. Figure 5-30 Remove Balancing Chamber 28. Using a plastic pick, remove the two O-rings ID .228 from the balancing chamber and discard. 29. Place balancing chamber and the regulator body to the side. 60410X 5-11...
Page 22
LEVEL 3 CLEANING After all of the parts have been fully cleaned and fully dried, place them in a container such that they cannot be contaminated. Re-sealable poly bag and clean bins with a lid works well for this application. 5-14 60410X...
1. Place the exhaust valve into the exhaust assembly and insert the stem through the hole in the center. Cut off excess stem. Figure 5-31 Cut Off Excess Stem 2. Ensure the exhaust valve is properly seated. Figure 5-32 Ensure Exhaust Valve is Properly Seated 60410X 5-15...
Page 24
4. Place the seal plate valve on the spring. Figure 5-34 Place Seal Plate Valve on Spring 5. Using the small spanner wheel with torque wrench, thread and secure the locking ring to 12-inch-lbs. Figure 5-35 Thread Locking Ring 5-16 60410X...
Page 25
8. Starting with the left side, insert the locking wire. Stop once it is 1/2 to 1-inch from the bend. Figure 5-37 Insert Locking Wire on the Left Side 9. Begin inserting the locking wire on the right side. Figure 5-38 Insert Locking Wire on the Right Side 60410X 5-17...
Page 26
Figure 5-40 Align the Notches with the Mask to the Exhaust Assembly 13. Insert exhaust assembly into the right side of the mask. 14. Place locking washer onto exhaust assembly with the raised edge facing down. Figure 5-41 Place Locking Washer with Raised Edge Facing Down onto Exhaust Assembly 5-18 60410X...
Page 27
SOLR 100% OXYGEN MASK LEVEL 3 TM0063-2 ® 15. Using the medium spanner wheel and torque wrench, thread the locking ring onto the exhaust assembly turning it clockwise, to 20-inch-lbs. Figure 5-42 Thread Locking Ring onto Exhaust Assembly 60410X 5-19...
Figure 5-44 Place Balancing Chamber in Regulator Body NOTE USE LIGHT AMOUNT OF EVERSEAL ON SET SCREW 4. Using the 0.05 hex driver, thread the set screw into the regulator, ensuring its flush. Figure 5-45 Thread Set Screw into Regulator 5-20 60410X...
Page 29
7. Using the provided O-ring tool, place O-ring ID .364 on the insert body. Figure 5-48 Place O-Ring on Insert Body 8. Using the plastic assist tool, insert crown into insert body. Figure 5-49 Insert Crown into Insert Body 60410X 5-21...
Page 30
ENSURE THE BALANCED SEAT IS CLEAN AND FREE FROM DEFECTS BEFORE INSERTING. 10. Insert the balanced seat into the insert body. Figure 5-51 Insert Balanced Seat 11. Place the valve spring on the balanced seat. Figure 5-52 Place Valve Spring on Balanced Seat 5-22 60410X...
Page 31
Figure 5-54 Move Balanced Seat Forward NOTE USE LIGHT AMOUNT OF CHRISTO LUBE ON LEVER 14. Place the lever in cleared slot while rotating the insert body 90 degrees clockwise. Figure 5-55 Place Lever in Cleared Slot 60410X 5-23...
Page 32
17. Once the lever is fully raised, turn the crown clockwise and stop as soon as the lever begins to drop. Figure 5-57 Raise the Lever by Turning the Crown 18. Place the diaphragm in the regulator body, ensuring it is seated below the threads. Figure 5-58 Place Diaphragm in Regulator 5-24 60410X...
Page 33
20. Using the large spanner wheel and torque wrench, thread the regulator cover onto the regulator body to 12-inch-lbs. Figure 5-60 Thread Regulator Cover to the Regulator Body 21. Using a 0.05 hex drive, thread the set screw into the regulator body. Figure 5-61 Thread Set Screw 60410X 5-25...
Page 34
Figure 5-63 Thread Inlet Quick Disconnect into the Insert Body 24. Place O-ring ID .140 onto anti-suffocation piston by hand. 25. Insert the anti-suffocation piston in the regulator body. Ensure the depression in the piston is facing up. Figure 5-64 Insert Anti-Suffocation Piston 5-26 60410X...
Page 35
HOLD IT IN PLACE UNTIL IT IS PROPERLY SECURED TO THE REGULATOR. 29. Using the T8 torx drive with the torque wrench, thread the screws in the anti-suffocation cover, securing it to the regulator body, to 6-inch-lbs. Figure 5-67 Secure the Anti-Suffocation Cover to the Regulator Body 60410X 5-27...
Page 36
32. Using the T8 torx driver, connect the microphone cable to the regulator. Adjust the microphone wire until the female end of the microphone wire is even with the end of the quick disconnect, ± 1/8-inch. Figure 5-70 Ensure Microphone Wire is Even with the Quick Disconnect 5-28 60410X...
Page 37
Figure 5-72 Align the Notches on the Mask and the Regulator 35. Insert the regulator assembly into the left side of the mask. 36. Place locking washer onto regulator assembly with the raised edge facing down. Figure 5-73 Place Locking Washer with Raised Edge Facing Down onto Regulator 60410X 5-29...
Page 38
37. Using the medium spanner wheel, thread the locking ring onto the regulator turning it clockwise and torque to 20-inch-lbs. Figure 5-74 Thread Locking Ring onto Regulator 38. Connect the microphone wire to the microphone housing. Figure 5-75 Connect the Microphone Wire to the Housing 5-30 60410X...
Functions check must be performed prior to initial use, after any level 2 service, and continuing at every 6 months. Functions check must be performed on a calibrated Airborne Systems Test Stand. Refer to the Test Stand manual for proper set up and calibration. Start each test with the oxygen cylinder valve open, V1 open, and the regulator RI set at 0 PSI on G2.
Page 40
Close V4 and V7, open V6 and V5 a minimum of 4 revolutions. Open V9. b. Using V3 adjust the flow to 100 SLPM on FM1. c. G4 must be less than 3-inches of water. d. Close V3, V5, V6, V9 60410X...
45 ± 2 Below 3-Inches of Water @ 70 SLPM IN. H2O Below 3-Inches of Water @100 SLPM IN. H2O Exhalation Effort 45 ± 2 Below 3-Inches of Water @100 SLPM IN. H2O NOTE DATA CAN BE RECORDED AS PASS/FAIL. 60410X...
Remove and replace Defective Valve Spring the valve spring. Remove the quick disconnect, adjust the Inhalation Effort Above Misadjusted Lever Inhalation Effort crown out (counter 3” H2O Height clockwise) 1/8 of a turn, reinstall. Remove, clean, Stuck Lever/Seat Stem reassemble. 60410X...
Page 44
Exhalation Effort check valve Debris in the Exhaust Disassemble, clean, Valve reassemble. Plug Communications Wire Harness/Adapter Directly into the Malfunctioning Microphone, if this Microphone Cable Action Remedies Communication Does Communications Problem Replace Not Occur Microphone Wire Malfunctioning Replace Microphone Microphone 60410X...
This section lists and illustrates replacement parts for maintenance and in procurement, requisition or storage, issue and identification of new or reclaimed parts for the oxygen mask. The following explains the arrangement of parts identification. ILLUSTRATED PARTS BREAKDOWN Figure 6-1 100% Oxygen Mask Illustrated Parts Breakdown 60410X...
DRIVE BIT, POWER TO DRIVE, 1/4" 601762-0 DRIVE 2” BIT, POWER TO TORX T8, 601762-3 2” BIT POWER TO #2 PHILLIPS 601762-2 2” TORQUE DRIVER, 6-30 601757-0 INCH LBS, CLICK 601747-0 TORX DRIVER T8 601751-5 HEX DRIVER, .05” 60410X 6-23...
0.454 grams ounces 0.035 short tons metric tons 0.907 kilograms pounds 2.205 pound-feet newton-meters 1.356 metric tons short tons 1.102 pound-inches newton-meters 0.113 Temperature (Exact) To Change Fahrenheit Temperature To Celsius Temperature Subtract 32 than Multiply 0.556 60410X...
