Summary of Contents for Dr. Nano 12,000 LBS
- Page 1 12,000 LBS ELECTRIC WINCH USER MANUAL REGISTER PRODUCT WARRANTY AT www.drnanoinc.com...
-
Page 2: Know Your Winch
KNOW YOUR WINCH Motor: The winch motor is powered by the vehicle’s battery. The motor provides power to the gear mechanism, which turns the winch drum and winds the winch rope. Winch Drum: The winch drum is the cylinder onto which the winch rope feeds. The drum is driven by the motor and drive train. - Page 3 NO. NAME QTY. NO. NAME QTY. MOTOR BOX COVER 1 & 2-STAGE INNER GEAR MOTOR ROTOR SUN GEAR MOTOR OUTER BARREL 1-STAGE PLANETARY MOTOR BASE 2-STAGE PLANETARY SLIDING BEARING 3-STAGE PLANETARY MOTOR STEEL SLEEVE 3-STAGE INNER GEAR TRANSMISSION SHAFT DRUM SUPPORT BAR WIRELESS REMOTE GEAR BOX BASE...
-
Page 4: Winch Installation
Mount the winch on the vehicle using the M10 x 35 bolts and spring washers provided. The winch must be mounted in position with the rope spooling off the bottom of the reel not the top. Improper mounting could damage your winch and void the Dr. Nano warranty. - Page 5 Wireless Control Your Dr. Nano winch is installed with a wireless control unit housed in the control box. This unit should have an operating range of at least 10 meters. If problems are experienced with the wireless control, it may be of benefit to open the control box, locate the wireless control unit attached to the inside of the case, locate the aerial and feed it out through the bottom of the control box into a more exposed position.
-
Page 6: Winch Operation
WINCH OPERATION Suggestion The best way to get acquainted with how your winch operates is to make a few test runs before you actually need to use it. Plan your test in advance. Remember you can hear your winch as well as you can see it operate. Get to recognize the sound of a light steady pull, a heavy pull, and sounds caused by the load jerking or shifting. -
Page 7: Maintenance
Dr. Nano accepts no liability for any consequences of using this product if not used in accord with... -
Page 8: Safety Precautions
SAFETY PRECAUTIONS Warning! Observe safety precautions for personal safety and the safety of others. Improper equipment operation may cause personal injury and equipment damage. Read the following carefully before attempting to operate your winch and keep the instructions for future reference. Dress properly: Do not wear loose clothing or jewellery;... - Page 9 Repairing your winch: When repairing the winch use only genuine Dr. Nano replacement parts, as ▪ using any other parts will invalidate the warranty and may result in injury to the user Re-spooling the Rope: Leather gloves must be worn while re-spooling.
-
Page 10: Operation Warnings
OPERATION WARNINGS Read the following carefully before attempting to operate your Dr. Nano winch and keep the instructions for future reference. The uneven spooling of rope while pulling a load is not a problem, unless ▪ there is a rope pile up at one end of the drum. If this happens reverse the winch to relieve the load and move your anchor point further to the centre of the vehicle. - Page 11 C. Have the engine running when using the winch to avoid draining the battery. Winch rope; ▪ A. Be sure that the rope is in good condition and is attached properly. B. Do not use the winch if rope is frayed. C.
-
Page 12: Troubleshooting
TROUBLE SHOOTING...
