Summary of Contents for Detonate Fairmont II
- Page 1 Fairmont II Smart Watch + Cell Phone User Manual...
- Page 2 Please read the manual carefully before use...
- Page 3 Many thanks for your purchase of our Fairmont II Surf Smart Watch + Cell Phone! , it is water-proof 3M, shock-proof, dust-proof and snow-proof sports smart watch, monitor your heart rate in real time, track steps walked , the distance taken and calories burned while you surf, swim, or workout.
-
Page 4: Specification
Specification: Screen，1.54“ Card，Nano Card Battery Capacity，300mAh GSM Frequency，850MHZ/900MHZ/1800MHZ/1900MHZ Bluetooth ，BT V3.0 & V4.0 Waterproof Rating: IP68, submersible in 3M. No deep diving. - Page 5 Touch Operation Guide： Swipe right to enter function option, select your wanted menu by scrolling up and down, and click to operate. Slide right to return to last page. Long-press clock interface accesses to the clock menu, there are three clock styles for option.
-
Page 7: Battery Charging
Battery Charging The notch of the charging dock is locked towards right button of watch, put charging dock into the slots of watchbase and hear a “Ka” sound come out, then plug Mini USB of charging cable into charging dock and another USB plug into slot of computer or mobile adaptor. - Page 8 APK Download and Installation PC terminal APK download: For PC terminal download, pls access to https://play.google.com/ store/apps/details?id=com.kct.fundowear.btnotification download Fundo Wear ,english and chinese version for...
- Page 9 option. Android User: Support Android 4.4 and above, lower version supports partial functions. 1: QR Code---Scan QR code on smart watch , download Fundo Wear...
- Page 10 APK and click the English version to install after successful installation, Fundo Wear...
- Page 12 will be shown in your mobile. 2. Connect Bluetooth V 3.0 firstly--- Switch on bluetooth on phone and smart watch to search each other, after successful finding and pairing with matching code, the blue bluetooth icon will be shown on the top left corner of menu and Bluetooth 3.0 is done. 3.
- Page 13 after done, go back main menu and you will find a green round icon “+” ， clicking green“+” show red bluetooth icon and click again to search matchable smart watch, after pairing successful, Green bluetooth icon will be shown on the top left corner of menu, blue and green bluetooth icon is shown on menu at the same time, smart watch is ready now.
- Page 14 Support IOS7.0 and above. 1. Accessing to AppStore to download “Fundo wear”，after successful installation, Fundo Wear will be shown in your mobile. 2. Connect Bluetooth V 3.0 firstly--- Switch on bluetooth on phone and smart watch to search each other, after successful finding and pairing with matching code, the blue bluetooth icon will be shown on the top left corner of menu and Bluetooth 3.0 is done.
- Page 15 3. Connect Bluetooth 4.0--- Run Fundo Wear on phone into main interface , and click three points icon on the top left corner to log in， via email ID, wechat or QQ, to log in. After done, go back main menu and you will find a green round icon “+” ， clicking green“+”...
- Page 16 register and log in, sport and healthy data could not synchronize to phone. Functions for IOS and Android System After Connection， 1. Select your wanted language after first- time starting smart watch; 2. Sync current time and date with phone ;...
- Page 17 3. Anti-Lost: start the button of finding device on smart watch, phone will alert and vibrate ,after smart watch is far away around 10 meters, smart watch will alert and vibrate too; the smart watch and phone can be found each other ，...
- Page 18 Facebook,Twitter, Wechat, QQ etc, sync instant voice talk, sync voice message and picture notification with phone 9.1 Remote Camera for Android User: Click “remote camera”on watch to take pictures as selfie sticker 9.2. Remote Camera for IOS User: Run video or photo on iphone, and click “remote camera”on watch to take pictures or video as selfie sticker 10.1 DuVoice to make a voice call...
- Page 19 SMS are pushed from phone to smart watch which can be editted ,texted and sent back; 12. Change bluetooth name (only for Android phone) 13. Download the Yahoo Weather from phone application to watch and install to check global instant weather condition (Android User) 14.
-
Page 20: Other Functions
Other Functions 1. Heart Rate Monitoring : “Once” and “Repeat ”mode for option; 2. Pedometer Record steps taken, distance traveled and calorie burned. target steps and weight can be preset on menu and always save the latest 10-time update; 3. Sedentary Reminder ，... - Page 21 5. Menu Style ，White and orange theme for option; 6. Power Saving : Normal and power saving mode; 7. Alarm ，Customized five kinds of alarms are provided; 8. Stopwatch : Save the latest 20-time update record; 9. Motion Sensor: Adjustable 5- motion sensor mode ，flip to mute incoming call;...
- Page 22 10. Others: Calculator , Calender Heart Rate Monitoring Method and Notes The Fairmont II is taking use of the advanced photoelectric sensor, high precision full-seal waterproof structure design and high-precise algorithm, is a light-weight and useful outdoor sports smart watch to provide real time heart rate monitoring anytime and anywhere.
- Page 23 monitoring, please don’t move and stay for around 10 seconds till heart rate reading. There is a different reading if wearing it on different skin color. In lower battery indication, heart rate accuracy will be affected and not so accurate, which requests you to recharge till full. Warning: The watch is not medical device, it is a recreational product, all the data on watch are just for reference and could not regard as a standard for clinic monitoring!
- Page 24 Before shipment every Smartwatch is completely tested by high-precision waterproof test equipment to make sure of worry- free service. Before use it, please install and waterproof test as following procedures: Step 1 ， Using a finger to pull SIM Card cover out, while pulling up, if longer fingernail, please control your used strength to avoid hurting cover and digging out a tent.
- Page 25 Step 2：Install the SIM card cover as the left arrow direction of below figure，back cover is completely coupled with the watch, press tightly to seal well. and then put watch into water to test for several minutes. Step 3：Take watch out from water and wipe-off, open the SIM...
- Page 26 card cover slowly, if any small waterdrop on sides of cover dry these carefully. And check to make sure there is no water inside or on the Sim Card Cradle, and that there are no obstructions, hairs etc,, that could make the waterproof seal not work correctly.
- Page 27 Step 4： Open SIM card slot ,put SIM card inside and cover it tightly, the watch is ready now While swimming in water, before picking up phone call, it is best to pour out the extra water of speaker slot, water will stay inside of slots and affect the sound quality if don’t pour out or blow it out.
- Page 28 Notice: The manufacturer however reserves the right to amend the specifications according to market demand without notice. Company Information and Support: Website : https://www.detonate.co https://facebook.com/detonate.co https://instagram.com/detonate_surf_co Webshop: www.shop.detonate.co Customer Service Email Support: Smartwatch@detonate.co...
-
Page 29: Warranty Card
Warranty Card Item No Buyer Telephone Purchase Date SKU# Address... - Page 30 Distributor Signature & Stamp Distributor Telephone Address Repair Record...
