Bynolyt searanger IV Quick Start Manual

Bynolyt searanger IV
rectangular button on the top left side of the binocular.
compass calibration procedure
this calibration procedure will ensure that the displayed readings are accurate for the area in which the
compass will be used. The calibration should be done outdoors if possible, and with the binocular kept at
least 7 feet away from any large metal objects. Facing due north is not required for calibration.
For the best results, the compass should be calibrated again:
1) After any significant change in your location since the last calibration
2) After changing the battery, especially if a different brand is used
3) If the binocular was in direct contact with a large metal object (for example a steel table) while the
power was on (note that the power automatically shuts off after one minute, so this should not be
common)
To calibrate the compass: after turning on the compass by pressing the power button on the top right
side of the binocular, rotate the entire binocular clockwise or counter-clockwise once in a full circle (360
degrees) along each of these three axes, in this order, returning to the starting position at the end of each
step (see the diagrams on the following page)
Step 1: Pitch (rotate 1 full cycle "end over end", in a vertical plane up/down)
Step 2: Yaw (rotate 1 full cycle "spinning around"', in a horizontal plane left/right)
Step 3: roll (rotate 1 full cycle as shown along the binocular's center hinge axis)
