Summary of Contents for Radicson HDR-510
- Page 1 Radicson Technology HDR-510 Proffesional Full HD Recorder Record Live Voice Schedule Recording Record Videos to the USB Storage Instant Video Playback after Recording Various Video Input Signals (HDMI,VGA,AV,YPbPr) www.radicson.com info@radicson.com Radicson Technology...
-
Page 2: Table Of Contents
Radicson Technology HDR-510 Full HD Recorder Contents Safety Notices ......................2 Product Specifications ....................3 Supported Resolutions ....................3 Remote Control ......................4 How to record videos to the USB storage device ........... 5 1. Connect ......................... 5 Tips on selecting a proper USB flash drive ............. 5 2. -
Page 3: Safety Notices
Before using HDR-510 device, please ensure that you read and understand the safety precautions below: - Do not attempt to open the case of HDR-510 or modify it in any way, as this will void the warranty. - Keep the HDR-510 away from water and other liquids, as this may cause the unit to malfunction. -
Page 4: Product Specifications
Radicson Technology HDR-510 Full HD Recorder Product Specifications Output Format MP4 (H.264) Video Standards (Input) NTSC, PAL, PAL-60 Supported Disk Formats FAT32, NTFS Input Signals HDMI, VGA, YPbPr, AV, Audio L/R Output Signals HDMI (Pass-Through), USB, Micro USB Bitrate Max: 16Mbps... -
Page 5: Remote Control
Radicson Technology HDR-510 Full HD Recorder Remote Control Power on / Power off Capture an image Select HDMI as the input signal Select VGA as the input signal Select YPbPr as the input signal Select AV as the input signal... -
Page 6: How To Record Videos To The Usb Storage Device
How to record videos to the USB storage device 1. Connect - Connect the video source to IN port on HDR-510 via HDMI cable - Connect HDR-510 from OUT port to Monitor via an HDMI Cable - Plug the USB storage device into the “Storage” port of HDR-510... -
Page 7: Record
- After all devices are connected properly, press and hold the “ON/OFF” button for a few seconds to switch on the HDR-510 and turn on other devices. - Press the REC/STOP button on the device or press REC button on the remote control to start recording. - Page 8 Radicson Technology HDR-510 Full HD Recorder - Press the “SCHEDULE” button on the remote control, Set the recording frequency, start time and recording time by using the four buttons of volume on the remote control, Then select Save to finish the setting.
-
Page 9: Playback
4. Playback - after all devices are connected properly, plug the USB storage device into HDR-510 and press the Playback button on the remote control to enter the playback menu interface. - Select one category and press OK, Then you can select a partition. - Page 10 Radicson Technology HDR-510 Full HD Recorder - You will see the file list. Select your desired file by using the four buttons of volume control on the remote control. You can preview the files & press OK to select multiple files.
-
Page 11: Menu Navigation
Full HD Recorder 5. Menu Navigation Press on the remote control to browse the menu setting of HDR-510, which are TIME, PICTURE, SOUND and OPTION. - Under the TIME column, there are four aspects: System Time, Schedule Recording, Recording Bitrate and Frimware Update. -
Page 12: Picture Submenu
Radicson Technology HDR-510 Full HD Recorder Picture Mode: Mild, User, Dynamic and Standard are available. Color Temperature: Medium, Warm, User and Cool are available. Aspect Ratio: Auto, 4:3, 16:9 (default), Zoom 1, Zoom 2, Just Scan are available. - Under the SOUND column, there are 2 aspects: Sound Mode and Equalizer. -
Page 13: Option Submenu
Radicson Technology HDR-510 Full HD Recorder Sound Mode: Standard, Music, Movie, Sport and User are available. Equalizer: 120 Hz, 500 Hz, 1.5 Khz, 5 Khz and 10 KHz are available. - Under the OPTION column, there are five aspects: OSD Language, Restore Factory Default, OSD Transparency, OSD Duration and Firmware Version. -
Page 14: Frequently Asked Questions
- Why is there a prompt “Can’t Detect USB Device”? Please format your USB stick or unplug the USB stick from the USB port and plug it into HDR-510 again. If the solutions don’t work, please send an email to support@radicson.com for direct help.
