SelectLine Video 8 Installation Manual

Economy functional & digital audio access systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
electLine
Economy functional & digital audio access systems
Video 8 & 16
Functional
Installation Manual
Select Manufacturing Limited
Unit H1 - The Seedbed Centre - Wyncolls Road - Severalls Business Park - Colchester - Essex CO4 9HT
Telephone +44(0)1206 855800 - Facsimile +44(0)1206 855801
E-mail sales@selectman.co.uk - http:/www.selectman.co.uk
07/06/2002
Functional Video
Revision 1.08 Date: 10/03/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Video 8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SelectLine Video 8

  • Page 1 Economy functional & digital audio access systems Video 8 & 16 Functional Installation Manual Select Manufacturing Limited Unit H1 - The Seedbed Centre - Wyncolls Road - Severalls Business Park - Colchester - Essex CO4 9HT Telephone +44(0)1206 855800 - Facsimile +44(0)1206 855801 E-mail sales@selectman.co.uk - http:/www.selectman.co.uk...
  • Page 2 Functional Video Installation Manual Page Contents VIDEO FUNCTIONAL SYSTEMS: System Overview System Controller Overview System Wiring Overview Single and Dual Entrance Panels Single Entrance Panel Wiring Detail Dual Entrance Panel Wiring Detail Amplifier, Dual Panel Display and Auxiliary Output Amplifier Wiring Detail Dual Panel Display Wiring Detail 12Vdc Auxiliary Output Wiring Detail Video Monitor, Video Distributor and Camera wiring detail...
  • Page 3 Functional Video Installation Manual Contents Page URMET Amplifier URMET Amplifier Wiring Detail PC Link Power and Battery PC Link Wiring Detail Power Connection Wiring Detail Battery Connection Wiring Detail System Controller Summary 17-18 System Default Settings Programming Instructions 20-22 Example System Settings Digital Time Clock GMT/BSTTime Clock System Wiring Colour Codes...
  • Page 4 Functional Video Installation Manual Functional Video Systems - 2 - Functional Video Revision 1.8 Date: 10/03/2009...
  • Page 5 Functional Video Installation Manual Functional Video System Overview with a PAC Reader Rear Entrance Strobe/Sounder elect ine Strobe/Sounder PRIVACY DOOR PRIVACY OPEN elect ine Monitor PRIVACY DOOR PRIVACY OPEN Monitor Emergency Emergency 4, 8, 12 &16 way Front Entrance Panel Override Override Video...
  • Page 6 Functional Video Installation Manual Functional Video System with Two Entrances with PAC Overview Strobe/Sounder elect ine Strobe/Sounder PRIVACY DOOR PRIVACY OPEN elect ine Monitor PRIVACY DOOR PRIVACY OPEN Monitor Emergency Emergency Override Override Front Entrance Panel 4, 8, 12 &16 way Video PUSH Distribution...
  • Page 7 Functional Video Installation Manual Functional System Controller Overview Functional System Controller Overview PANEL 1 + 18Vdc Monitor Supply 0V Monitor Supply Entrance Panel 1 Amplifier Entrance Panel 1 Button Common Entrance Panel 1 Busy & Enter Display Flat Called Indicator Entrance Panel 1 Lock Supply + Input (12V-24VAC/DC Buttons...

  • Page 8: Time Clock

    Functional Video Installation Manual Functional System Controller Overview Functional System Controller Overview Lock Release Tone and Door Open Tone Adjustment Panel Amplifier Active Door Open Indicator To Video PANEL 1 Monitor Entrance Panel 1 Amplifier 18VDC Monitor Entrance Panel 1 Button Common Supply Entrance Panel 1 Busy &...
  • Page 9 Functional Video Installation Manual Functional System Wiring Overview LINE 2 LINE 4 LINE 6 LINE 8 LINE 10 LINE 12 LINE 14 LINE 16 LINE 1 LINE 3 LINE 5 LINE 7 LINE 9 LINE11 LINE 13 LINE 15 Camera Power x 5 Camera Power x 5 - 6 - Functional Video...
  • Page 10 Functional Video Installation Manual Functional Video Panel wiring detail Camera Note: See Camera detail PANEL 1 Brown of White White of Brown Slate of White White of Slate Red of Orange Camera Supply x 5 Orange of Red Green of Red Red of Green Brown of Red Red of Brown...
  • Page 11 Functional Video Installation Manual Functional Video Panel wiring detail Camera Note: See Camera detail Camera Supply PANEL 1 Brown of White White of Brown Slate of White White of Slate Red of Orange Orange of Red Green of Red Red of Green Brown of Red Red of Brown VOUT...
  • Page 12 Functional Video Installation Manual AT-PID Telephone Privacy, Privacy On Indicator and Panel Amplifier wiring detail Door Monitoring Indicator wiring detail Panel Amplifier PANEL 1 Blue of White White of Blue Blue and Red Pair White of Orange and Orange of White Blue of White White of Blue White of Orange and Orange of White...
  • Page 13 Functional Video Installation Manual For Fail Secure (SE) Lock Releases. For Fail Safe (SA) Lock Releases. Emergency Override PANEL 1 Switch Emergency Override Switch Green of White RTE/T White of Green Common RTE/T Common Normally Open Normally System Normally Open Closed Controller Normally...
  • Page 14 Functional Video Installation Manual DC Fail Secure Lock Release wiring detail 1N4007 PANEL 1 Diode + LS - RTE/T To Fire Switch N/O Contact RTE/T Green of White White of Green Door Monitoring Contact Fail Secure Lock Release DC ( If Specified ) System Controller DC Fail Safe Lock Release wiring detail IN4007...
  • Page 15 Installation Manual Proximity Access wiring detail Both Door Times Must Fail Safe 2 second PAC Easikey 99 programed to 2 seconds Lock Output SelectLine Controller Fail Safe even if only one Reader1 Lock2 Reader2 Power Lock1 reader is being used. WITH...
  • Page 16 Functional Video Installation Manual Proximity Access wiring detail Both Door Times Must SelectLine Controller Fail Safe 2 second programed to 2 seconds PAC Easikey 250 Lock Output Fail Safe even if only one WITH Power Lock1 Reader1 Lock2 Reader2 reader is being used.
  • Page 17 Functional Video Installation Manual AMA-1202/BRT Video Monitor Video Monitor wiring detail connection plate Blue of White White of Blue White of Orange & Orange of White White of Green Green of White Brown of White White of Brown Grey of White & White of Grey Red of Blue &...

  • Page 18: Earth Continuity

    Functional Video Installation Manual 4, 8, 12 and 16 Video Distribution wiring detail Distributor Remove Jumperss except the LAST Distributor in line. Video Distributor Video Distributor U1 U2 E U5 U3 U4 U1 U2 E U5 U3 U4 Video Distributor Video Distributor U1 U2 E U5...

  • Page 19: Connection Detail

    Functional Video Installation Manual System Controller Summary Connection Detail Controller Controller Video Monitor Trades Clock Speaker/Electronic Call Secondary Trades Clock Microphone Secondary Trades Clock Note: N/O Clean Contacts Common Lock Release Privacy Switch Auxiliary Supplies Privacy On Indicator 3 x 0V Output Door Monitoring Indicator 3 x 12VDC Output Note: 3 Amp (3 x 12VDC)
  • Page 20 Functional Video Installation Manual System Controller Summary cont... Connection Detail Controller Auxiliary Supplies 3 x 0V Output 3 x 12VDC Output Note: 3 Amp (3 x 12VDC) Overall Output Power Input to Controller 12VAC Input 12VAC Input Battery Back Up +12VDC Battery Input 0V Battery Input System Busy Output to Functional Panel...
  • Page 21 Functional Video Installation Manual System Controller Programming Instructions To be used in conjunction with the Controller Programming Instruction. PROGRAMMING LINES By setting all FUNCTION switches to ON and then pressing enter will set the system to default. (See System function Programming for set up and manufactures default settings). Select the line number to program using the FUNCTION switches 1 - 5, note that position 6, Controller Programming Instruction).
  • Page 22 Functional Video Installation Manual Controller Programming Settings 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 SYSTEM CONFIGURATION Notes FUNCTION SWITCH DATA SWITCH 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Default setting for all items X X X X X X X X Send setup to serial Port...
  • Page 23 Functional Video Installation Manual Controller Programming Example Settings EXAMPLE SYSTEM SETTINGS Notes FUNCTION SWITCH DATA SWITCH Default setting fo r all items Send setup to serial P o rt Lo w Call Vo lume and P rivacy Time Line1-P rivacy 10 M ins M edium Call Vo lume and P rivacy Time Line5-P rivacy 50 M ins No minal Call Vo lume and P rivacy Time...

  • Page 24: Programme Button

    Functional Video Installation Manual Digital Trades Clock Operating Instructions Change Button Programme Button Sets Hours, Minutes Used to select the clock time and the 4 and Trade Times On/Off programmed times and to review them once set Output Status Showing Trades ON or OFF Programming iii.

  • Page 25: Programming Instructions

    Functional Video Installation Manual .Display shows:- GMT/BST TIME SWITCH TIME ? 17:12:56 Programming Instructions Using the Green and Grey buttons as previously set the display to the correct time (24 hour clock). Select Manufacturing Limited Note:- The time entered is always normal ‘clock’ time i.e. Unit G3 GMT during winter and BST during summer-time.
  • Page 26 Functional Video Installation Manual System Wiring Colour Codes System Wiring Colour Codes System Controllers to System Controllers to Telephone Handset Functional and Landing Entrance Panels Controller Controller Entrance Panel Monitor Blue of White Brown of White Button White of Blue White of Brown Button White of Orange and Orange of White...
  • Page 27 Functional Video Installation Manual System Wiring Colour Codes cont... Controller to Lock Release (AC/DC) Lock Release (Fail Safe DC) Controller Lock Release Connection Lock Release Connection Controller Lock Release (Fail Secure DC) Lock Release Connection Lock Release Connection Controller Request To Exit Button (Timed) Switch Contact (Normally Open Contacts) RTE T RTE T...

  • Page 28: Power Specification

    Functional Video Installation Manual Power Specification Power Input System Controller 230VAC Working Voltage 12AC Amplifier 6-12VDC Controller Outputs Lock Release (Fail Secure) 12VDC (Normally Open)(Rated 1Amp) Lock Release (Fail Safe) 12VDC (Normally Closed)(Rated 1Amp) Lock Release (Fail Secure) 12VAC (Normally Open)(Rated 1Amp) Auxiliary Supply 3 x 12VDC (Rated 3Amp overall) Battery Back Up:...
  • Page 29 Functional Video Installation Manual Video Monitor User Instruction Leaflet. Door Release Button (illuminates when visitor calls) On/Off DOOR elect ine RELEASE Privacy Button PRIVACY DOOR PRIVACY OPEN Contrast Brightness Call Volume Once the Visitor has called you have the following options and indicators available to you: To Release the Door Press the Door Release button when illuminated : this will cause Door Open indicator to flash to confirm the door is being released...
  • Page 30 Functional Video Installation Manual Tel: 01206 855800 Fax: 01206 855801 Select Manufacturing Limited Functional & Digital Audio/Video Systems ELECT Commissioning/Final Inspection Test Sheet. Commissioning Engineer: Client Name: Site Address: Installer Name: Telephone No.: Controller Comments Trades Trades settings General System Comments: Please use reverse - 24 - Functional Video...
