Summary of Contents for ClairiTech Innovations Humidex HCS-BS
- Page 1 September 2019 Humidex HCS Wall Control Rev 2.1 En HCS Wall Control Operational Manual English Manufactured by: ClairiTech Innovations Inc. 1095 Ohio Rd. Boudreau-Ouest, NB Canada E4P 6N4...
-
Page 2: Table Of Contents
Humidex Table of Contents Table of Contents ........................1 Service and Warranty ......................... 2 ........................2 USTOMER SSISTANCE ........................ 3 ONSUMER IMITED ARRANTY Installation ..........................4 ..............................4 ESCRIPTION ....................4 IRING AND TTACHING THE ONTROL LCD Display and Control Layout ..................... 6 LCD D ............................ -
Page 3: Service And Warranty
Humidex Service and Warranty For Customer Assistance To aid in answering questions if you call for service or warranty purposes, please record below the model and serial number located on the side of the unit. Product Name: Model #: Date of Manufacturing: Date of Purchase: Serial #: Dealer Name (If Any):... -
Page 4: Consumer Limited Warranty
Humidex Consumer Limited Warranty ClairiTech Innovations Inc. warrants to the first consumer that this product, when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its discretion, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for the period(s) set forth below. -
Page 5: Installation
Humidex Installation Description The HCS Wall Control is intended for the following models: HCS-BS (included) HCS-CS (included) HCS-APT (optional) HCS-APTHC (optional) The LCD display on this unit has a built-in backlight to allow for better readability in darker locations. This backlight turns on when any button on the control panel is pressed and turns off after no button has been pressed on the unit for a period of 10 seconds. - Page 6 Humidex With the control mounted on the wall, the wires must then be stripped and connected following this guide: Yellow Wire – B Green Wire – A Black Wire – GND Red Wire – VCC Once the wires have been connected, the control can be closed and the screw tightened.
-
Page 7: Lcd Display And Control Layout
Humidex LCD Display and Control Layout The following sections of this operating manual refer to the user interface presented below: The user interface consists of: 1- LCD Display 2- Up Arrow Button 3- Down Arrow Button 4- Cancel Button 5- Ok Button... -
Page 8: The Lcd Display
Humidex The LCD Display The LCD Display consists of: 1- User Set Humidity Level 2- Operating Fan Speed 3- Desired Max Fan Speed Indicator Navigating the LCD Menu The HCS has an LCD display that allows the unit to display information about its operation. The LCD display also has a 4 button user interface that allows the user to navigate the LCD menu and change settings such as the maximum operating speed of the unit, the dehumidistat setting, as well as access the unit’s built in override mode. -
Page 9: Entering The Main Menu
Humidex Entering the Main Menu To change any settings for the HCS, you must first enter the main menu. To do so simply press the up arrow and cancel button at the same time. Once inside the main menu, the arrows keys can be used to cycle through the relative humidity menu, override menu and fan speed menu. -
Page 10: Override Timer Menu
Humidex Override Timer Menu The override function allows you to provide maximum ventilation for a predetermined amount of time, regardless of the fan speed chosen by the computerized/sensor control, to alleviate certain conditions such as fumes from new paint, flooring, furniture or excess moisture from hot showers, cooking, etc.
