ELECTRIC RANDOM ORBITAL SANDER INSTRUCTION MANUAL
706500AN/706502AN/706510AN/706512AN
152 mm (6 in.),127 mm (5 in.); 4,000 – 10,000/min
706522AN
EN
77 mm (3 in. - 2.5mm); 4,000 - 9,000/min
706535AN
70 mm x 198 mm; 5,000 – 8,500/min
INPUT: 220-240 Va.c. 50-60 Hz 150 W (350 W S2 1 m)
Original Instructions
GUARANTEE & WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
another reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure. If the goods cannot be
repaired, you are entitled to a replacement or refund.
Any warranty of guarantee offered on our goods or services is in addition to any right and
remedies that you have as a consumer under Australian Consumer Law.
For extra details about any warranty that we provide, you can contact our Customer Service.
Customer service:
Australia: 1300 742 123
New Zealand: 0800 742 123
Email: sia.au@sia-abrasives.com
B-E240E-DM-8-AU
Revision 2020/10

Advertisement

loading
Need help?

Need help?

Do you have a question about the 706500AN and is the answer not in the manual?

Questions and answers

Summary of Contents for DELMEQ 706500AN

  • Page 1 ELECTRIC RANDOM ORBITAL SANDER INSTRUCTION MANUAL 706500AN/706502AN/706510AN/706512AN 152 mm (6 in.),127 mm (5 in.); 4,000 – 10,000/min 706522AN 77 mm (3 in. - 2.5mm); 4,000 - 9,000/min 706535AN 70 mm x 198 mm; 5,000 – 8,500/min INPUT: 220-240 Va.c. 50-60 Hz 150 W (350 W S2 1 m) Original Instructions GUARANTEE &...
  • Page 2 It should only be used for such sanding applications and within marked capacity and ratings. Only accessories specifically recommended by DELMEQ should be used with this tool. Use in any other manner or with other accessories could lead to unsafe operating conditions.
  • Page 3: Sanders And Polishers Safety Warnings

    Correct or replace the suspect component. If abnormal • Separate collection of used products and packaging allows materials to noise or vibration still exists, return the tool to DELMEQ for repair or be recycled. Use of recycled materials helps prevent environmental replacement.
  • Page 4 DELMEQ cannot be held responsible for the consequences of using declared values instead of actual exposure values for any individual risk assessment.
  • Page 5 MAXIMUM SPEED FUNCTION CLEANING The Electric Random Orbital Sander has Seven preset Maximum Speeds 1. Periodically blow out all air passages and area above Disk Pad and 4,000, 5,000, 6,000, 7,000, 8,000, 9,000 and 10,000/min (RPM) under shroud with dry compressed air. All plastic parts should be The Maximum Speed can be changed at any time while the Sander is cleaned with a soft damp cloth.
  • Page 6 PARTS LIST: 706500AN – 706502AN – 706510AN – 706512AN Description Item E706512M Motor Assembly 5"x 3/32" (220V) E706510M Motor Assembly 5"x 3/16" (220V) E706502M Motor Assembly 6"x 3/32" (220V) E706500M Motor Assembly 6"x 3/16" (220V) EOS10-E2 Lock Ring Assembly EOS50101...
  • Page 7 PARTS LIST: 706500AN – 706502AN – 706510AN – 706512AN PARTS LIST 706500 – 706502 – 706510 – 706512 PARTS LIST 706500 – 706502 – 706510 – 706512 PARTS LIST 706500 – 706502 – 706510 – 706512 Belangrijke informatie Beoogd gebruik...
  • Page 8 Parts List: 706522AN Item Description QTY. EOS30025-2N Motor Assembly 3"x 3/32" EOS30026-2N Motor Assembly 3"x 3/16" XP10 Lock Ring Assembly EOS30023 Cooling Fan (3/16" Orbit) TOP EOS30038 Cooling Fan (3/16" Orbit) Bottom EOS30022 Cooling Fan (3/32" Orbit) EOS30037 Spacer-Cooling Fan (3/32" Orbit) EOS32013 Grip EOS30051...
  • Page 9 Parts List: 706522AN...
  • Page 10 Parts List: 706535AN Item Description QTY. EOS50224-2 (XP2-J1) Motor Assembly 70x198mm 1/8" EOS10-E2 Lock Ring Assembly EOS50225 Cooling Fan XPG0065 Cooling Fan EOS52144 Grip EOS50435 Lever for 8,500 OPM (1/8") Orbit EOS50232 Valve Stem Assembly EOS50102 Dust Cover EOS50129 Spring S4-3012B Button Head Screw (M3x12) EOS52181...
  • Page 11 Parts List: 706535AN...
