DL Wholesale B-Lite mini Quick Start Manual

INSTRUCTIONS

1. Remove the ballast from its packaging. Attach the rubber feet to the base of the ballast.
2. Mount the ballast as needed (using the attached mounting brackets) or set it on a flat surface, with
the rubber feet down. Make sure there is plenty of empty space/breathing room around the ballast,
as it will give off heat and needs to be properly ventilated.
3. Plug the reflector cord into the ballast. Make sure the connection is snug.
4. Set the wattage dimming knob to 100%. Please Note: Always start your bulb at 100%. Once the
bulb has been warmed up, afte approximately 10-15 minutes, you may dim it as desired. Do not
rapidly adjust the dimming knob. Allow the bulb to adjust after each turn.
5. Plug the included power cord into the ballast, and plug the other end into your power source/timer/
controller. You will know the ballast is on when it starts to hum, however it can take up to 10 minutes
for a bulb to initially ignite.

SMART DETECTION FEATURE

Super
Lumens
100%
60%
40%
Normal manner
Super
Lumens
100%
60%
40%
High temperature
protection
Flashing Slowly Flashing Quickly
Super
Red Green
Lumens
100%
60%
40%
Over voltage
Super
Red Green
Lumens
100%
60%
40%
Short circuit
Super
Red Green
Lumens
100%
60%
40%
Under voltage
protection
Super
Red Green
Lumens
100%
60%
40%
protection
Red Green
protection
Red Green
Open circuit
protection
