Summary of Contents for hugolog JU01
- Page 1 JU01 Installation Guide...
- Page 2 Installation Guide Interior assembly Mounting Battery plate cover Mounting screws(2) Bolt Screws(3) Latch/Strike screws(2) Exterior assembly Reinforcement screws(2) Strike...
-
Page 3: Interior Assembly
Lock installation Addtional Parts Tools Needed #2 Philips screwdriver Door prep Important Notice: Optional Bolt 1. 2-1/8” (54mm) hole saw Make sure your door is prepared prior to installation. Faceplate 2. 1” (26mm) boring bit 3. 7/64” (2.5mm) drill bit 4. -
Page 4: Preparing For Installation
Preparing for Installation A. Measure the dimension of the hole shown. C. Adjust the deadbolt. NOTE: Bolt ships with backset in 2-3/8”(60mm) position. If No adjustment needed. required, turn the bolt case and pull to extend to 2-3/4” (70 mm)backset position. (see picture below) φ2-1/8”... -
Page 5: Installation
3. Make sure the bolt in retracted(unlocked) Installation postion. NOTE: The bolt must be in retracted (Unlocked) 1. Install the bolt on the door frame. position before installing the lockset. NOTE: Make sure to allow for the bolt to be centered in the strike. strike 4. - Page 6 5. Positon the inside mounting plate by first routing the cable and connector through the mounting plate’s PCB connector cable hole. Cable connector 6. Secure both assemblies using 8/32x30 screws.Make sure that exterior assembly is vertically aligned.Tighten securely with a #2 Philips screwdriver.
- Page 7 9. Secure using screw through the interior assembly onto the mouting plate. NOTE: Testing operation using thumb turn before installing batteries, see if bolt works smoothly. Actual Size Insert the last battery, and If reset is successful, the bolt will keep holding the reset button for extend on its own to learn the another 3 seconds until hearing...
- Page 8 JU01 Programming Instructions...
- Page 9 Warnings Failure to follow these instructions could result in damage to the product and avoid the factory warranty. The accuracy of the door preparation is critical for the proper functioning and security of this product. Misalignment can cause performance degradation and lessening of security. Finish Care: This lockset is designed to provide the highest standard of product quality and performance.
-
Page 10: Parts Illustrations
Parts Illustrations Item Specifications Remarks Last up to one year AA alkaline battery x4 Battery (Operation voltage: 4.6~6.0V) (10 times open/close per day) Exterior assembly Interior assembly Battery cover Keypad Reset button Light indicater Thumb turn Reboot button Micro USB power port... - Page 11 Definitions Master Mode Manual Mode: The master mode could be entered by entering[ * * Auto re-lock function could be adjusted to manual + Master PIN Code + # ] to program the lock. mode. In manual mode the lock could be locked only by pressing any key for 2 seconds from outside or using Master PIN Code: thumb turn from inside.
- Page 12 The default master pin code is 12345678. Please change it prior to programming of the lock. New Master PIN Code New Master PIN Code Change Press Master PIN Code Master Code Wait for Wait for Wait for Succeed Long Green Lights Green Light Flash Green Light Flash Green Light Flash...
- Page 13 Enable Auto Re-lock Succeed Press Enable/ Master PIN Code Green Light Flash Disable Auto Re-lock Disable Auto Re-lock Succeed(Manual Mode) Wait for Wait for Green Light Flash Long Green Lights Green Light Flash Press Master PIN Code Away Mode Wait for Wait for Enable Away Mode Succeed Green Light Flash...
- Page 14 by using 8361813719214710 password Random digits...
- Page 15 beeper sound.
