Summary of Contents for TELEMAGNETICA 184/6KV
- Page 1 Holiday Detector mod. 184/6KV Telemagnetica S.r.l. Via Teocrito, 36 - 20128 Milan - Italy Tel: +39-022552900 - Fax: +39-022553097 e-mail: info@telemagnetica.com - http: \\ www.telemagnetica.com January 2013 BR-184-13-6KV-ENG-00 Pag. 1 of 10...
-
Page 2: Technical Data
Holiday Detector mod. 184-13-6KV Generals Mod. 184 The Holiday Detector mod. 184 is used to check the integrity of insulating coatings applied to metallic structures. Technical Data - Power 60VA - Max pulse voltage on 900pF - Pulse duration 10 ÷ 12µs. - Pulse repetition frequency 20 ÷... - Page 3 Holiday Detector mod. 184-13-6KV Instruction for use a) Holiday Detector Mod. 184 has been designed for the inspection, on the production line, of the piping insulating coating. b) The inspection is made connecting the grounding clamp to the back bare end of the pipe section, before the bare front of pipe reaches the inspection point that is made by a conductive brush connected to the hot point that feels the whole coated pipe surface, discovering any possible leaks in coating.
-
Page 4: Maintenance
Holiday Detector mod. 184-13-6KV Safety The unit feeded by 230Vac – 50Hz main, is used for the “on-line” inspection of different kinds of coatings applied on metallic surfaces in the production sites. The unit generates an output pulse voltage of more than 6.000 V (max. value) with a duration of some tens of microseconds and a repetition frequency of 20 ÷... -
Page 5: Components List
Holiday Detector mod. 184-13-6KV Components list Description Changeover switch 5922/E/1B/12/20A P-9059-000 (see DWG. PR-0765-004) P-7263-008 Microswitch cod. NAT AZH 2041 Main switch green M22 P-7434-126 (see DWG. PR-0765-004) P-7007-038 Green Led 230V 3W for M22 P-7434-126 P-7429-005 Wire potentiometer 10 kΩ... -
Page 6: Attached Drawings
Holiday Detector mod. 184-13-6KV Attached drawings PR-0765-004 FRONT VIEW S-0409-006 BLOCK DIAGRAM S-0372-001 H.V. OUTPUT WAVEFORM S-0373-000 H.V. COIL AND TRIGGER WAVEFORMS PR-1097-000 PIPE AND INSPECTION BRUSH CONNECTIONS January 2013 BR-184-13-6KV-ENG-00 Pag. 6 of 10... - Page 7 Holiday Detector mod. 184-13-6KV PR-0765-004 - FRONT VIEW January 2013 BR-184-13-6KV-ENG-00 Pag. 7 of 10...
- Page 8 Holiday Detector mod. 184-13-6KV S-0409-006 - BLOCK DIAGRAM S-0372-001- H.V. OUTPUT WAVEFORM January 2013 BR-184-13-6KV-ENG-00 Pag. 8 of 10...
- Page 9 Holiday Detector mod. 184-13-6KV S-0373-000- H.V. COIL AND TRIGGER WAVEFORMS January 2013 BR-184-13-6KV-ENG-00 Pag. 9 of 10...
- Page 10 Holiday Detector mod. 184-13-6KV PR-1097-000- PIPE AND INSPECTION BRUSH CONNECTIONS January 2013 BR-184-13-6KV-ENG-00 Pag. 10 of 10...
