Greenhouse

Assembly Instructions

17x17ft

Size: 510Lx510Wx330Hcm 26m²

17/05/19

IMPORTANT

You must read these instructions carefully before you start to assemble this greenhouse.Please

ensure that you find all parts in the carton box in the correct type and quantity as mentioned in the

list illustrated in every page accordingly.

Please carry out the steps in the order set out in these instructions.

Do not tighten the steps in the greenhouse until completing on the assembly of the poly carbon

ate panels.

Keep these instructions in a safe place for future reference.

ZA510

Need help?

Do you have a question about the ZA510 and is the answer not in the manual?

Questions and answers

Summary of Contents for Evergreen Greenhouses ZA510

Page 1 Greenhouse Assembly Instructions 17x17ft Size: 510Lx510Wx330Hcm 26m² ZA510 17/05/19 IMPORTANT You must read these instructions carefully before you start to assemble this greenhouse.Please ensure that you find all parts in the carton box in the correct type and quantity as mentioned in the list illustrated in every page accordingly.
Page 2 TOOLS & EQUIPMENT REQUIRED SAFETY ADVICE We strongly recommend the use of work gloves during assembly. Protective Equipment: Do not attempt to assemble the greenhouse in windy or wet conditions, 1.Helmet Do not touch overhead power cables with the aluminum profiles. Always wear shoes and safety goggles when working with extruded aluminum.
Page 3 1. 3-4 people required, one is for measuring & taking marks to ensure the installation dimension ,the second person is responsible for the installation and the last ZA510 one do as assistant and assure the safety. 2. High-power electric tools are required, ensure the normal work of them and highly pay\attention to electric safety.
Page 4 Installation instructions and illustrations 1.Make sure the ground flat and firm before installing, avoid the ground subsidence and cause the 1.Before installation, you need to know the meaning of the following symbols. greenhouse to tilt. 2.Follow the pattern to install faster and less effort. 2.
Page 5 ZA510 PARTS LIST （ 4-1 ） Front wall and back wall Front wall and back wall NO. Qty. NO. Qty. 1915 1900 2323 1900 Down 2730 ZA-D2 1019 ZA-D3 1500 2783 ZA-A5B 1692 A6LB 1907 A6RB A7LB 2315 A7RB Down...
Page 6 （ 4-2 ） ZA510 PARTS LIST Front wall and back wall NO. Qty. NO. Qty. NO. Qty. ZA-B1 2537 ZA-B2 1507 ZA-C11 2152 Down 2491 2138 1432 NO. Qty. NO. Qty. NO. Qty.
Page 7 （ 4-3 ） ZA510 PARTS LIST Left and right walls and top Left and right walls and top NO. Qty. NO. Qty. 1500 ZA-B1 2537 2785 1500 ZA-A1 2128 2790 1500 ZA-A3 2834 A7AC 2790 A7AD 2080 WA1A 2128 2100...
Page 8 ZA510 （ 4-4 ） PARTS LIST SUMMARY STATEMENT FOR POLYCARBONATE PANEL P1 P1 P1 P1...
Page 9 Towards the white film side to the sun as it is UV-protected. Advice:According to the thickness and quantity of polycarbonate, please buy suitable polycarboante sealing tape . sealing tape It can effectively avoid insects, dust, water vapor into the sun plate end. The required length is (L + W) x8.
Page 10 Back wall Ⅰ F4 x68 ZA-A5 ZA-A5 ZA-A1 ZA-A3 ZA-B1 ZA-B1 -10-...
Page 11 ZA-B1 F4 x14 B7 x2 Ⅱ Ⅱ Ⅱ Ⅱ Ⅱ Ⅱ Ⅱ ZA-B1 Ⅱ Ⅰ ZA-B1 Ⅱ Ⅰ ZA-B1 ZA-B1 ZA-B1 -11-...
Page 12 ZA-A1 F4 x12 ZA-A3 Ⅳ Ⅲ Ⅴ Ⅱ ZA-A3 Ⅱ Ⅰ Ⅴ ZA-B1 Ⅱ Ⅲ ZA-A1 Ⅳ ZA-B1 Ⅳ Ⅴ ZA-A3 ZA-A1 ZA-A1 ZA-A3 ZA-A3 ZA-B1 Ⅲ ZA-B1 Ⅱ Ⅰ ZA-A3 ZA-A1 -12-...
Page 13 A4 x2 Down <ZA-A1> <ZA-A3 > Ⅰ Ⅱ Ⅱ Ⅱ Ⅲ Ⅱ Ⅱ Ⅰ Ⅱ Ⅰ Ⅲ -13-...
Page 14 Ⅰ LC1 x2 F4 x16 A10 x2 C4 x2 Ⅰ Ⅰ Ⅰ Ⅴ Ⅰ Ⅰ Ⅱ Ⅴ Ⅲ Ⅰ Ⅴ Ⅲ Ⅱ Ⅳ Ⅳ A4 x9 Ⅲ Ⅱ Ⅳ b.-b. F4 x6 b.-b. 223mm±1 223mm±1 -14-...
Page 15 Ⅱ Ⅰ Ⅲ ZA-A5 x2 F4 x3 F4 x2 F4 x26 Ⅳ Ⅰ Ⅲ Ⅲ ZA-A5 Ⅰ Ⅴ Ⅵ Ⅱ ZA-A5 Ⅳ Ⅵ Ⅴ Ⅱ F4 x7 F4 x7 ZA-A5 ZA-A5 Ⅵ Ⅴ ZA-A5 188mm±1 188mm±1 F4 x4 ZA-A5 ZA-A5 F4 x2 -15-...
Page 16 C3 x4 Ⅱ Ⅱ ZA-A5 Ⅱ Ⅰ ZA-A5 Ⅱ Ⅱ Ⅰ 46mm ZA-A5 ZA-A5 ZA-A5 ZA-A5 -16-...
Page 17 Front wall Ⅱ F4 x81 ZA-A5 ZA-A5 ZA-C11 ZA-D8 ZA-A2 ZA-A2 ZA-B2 ZA-B2 ZA-D9 -17-...
Page 18 ZA-B2 B8 x2 F4 x12 B7 x2 Ⅰ Ⅰ Ⅰ Ⅰ ZA-B2 Ⅱ Ⅰ Ⅱ ZA-B2 ZA-B2 Ⅱ a.-a. a.-a. ZA-B2 ZA-B2 ZA-B2 B7 ZA-B2 -18-...
Page 19 F4 x12 D5 x12 Ⅰ Ⅲ ZA-B2 ZA-B2 D5x6 D5x6 Ⅲ Ⅲ Ⅱ F4 x2 F4 x2 ZA-B2 ZA-B2 Ⅲ F4x6 F4x6 Ⅲ Ⅰ Ⅲ ZA-B2 Ⅲ Ⅰ ZA-B2 -19-...
Page 20 ZA-A2 F4 x6 Down Ⅳ Ⅲ Ⅳ 65mm Ⅲ Ⅲ Ⅲ 565mm 65mm Ⅳ Ⅳ ZA-A2 Ⅰ 565mm Ⅱ 65mm Ⅱ ZA-B2 Ⅰ ZA-A2 196mm ZA-B2 -20-...
Page 21 Ⅳ Ⅰ Ⅲ ZA-A2 ZA-A2 ZA-B2 ZA-B2 Ⅱ ZA-A2 ZA-A2 ZA-B2 ZA-B2 -21-...
Page 22 ZA-A5 x2 F4 x14 Down Ⅰ Ⅱ Ⅳ Ⅲ F4 x6 F4 F4 Ⅰ Ⅱ Ⅴ Ⅰ ZA-A5 Ⅱ Ⅴ Ⅴ ZA-A5 A4 x3 Ⅲ Ⅳ Ⅳ Ⅲ -22-...
Page 23 ZA-D8 F4 x7 Down ZA-C11 Down Ⅰ Ⅱ Ⅲ F4x2 ZA-C11 Ⅰ <A9L> Ⅰ Ⅱ Ⅱ <A9R> Ⅱ Ⅳ Ⅳ F4x4 Ⅲ ZA-C11 Ⅲ Ⅳ ZA-D8 ZA-C11 ZA-D8 -23-...
Page 24 ZA-A5 x2 F4 x28 A10 x2 C3 x4 C4 x2 Ⅲ Ⅱ Ⅱ Ⅰ C5 C3 ZA-A5 Ⅱ Ⅰ Ⅵ ZA-A5 Ⅶ Ⅳ Ⅱ Ⅱ ZA-C11 VIII ZA-D8 Ⅵ VIII Ⅳ Ⅴ Ⅴ -24-...
Page 25 Ⅰ Ⅲ Ⅳ Ⅱ F4 x7 F4 x2 b.-b. b.-b. F4 x7 ZA-A5 223mm±1 ZA-A5 223mm±1 Ⅴ Ⅵ Ⅶ 188mm±1 188mm±1 ZA-A5 F4 x4 ZA-A5 ZA-A5 F4 x2 VIII 46mm ZA-A5 ZA-A5 ZA-C11 ZA-D8 ZA-A5 ZA-A5 ZA-C11 ZA-D8 F4x4 -25-...
Page 26 F8 x4 F4 x2 ZA-D9 Ⅰ F8 x2 ZA-D9 Ⅰ ZA-D9 Ⅰ -26-...
Page 27 Door ZA-D3 ZA-D3 Ⅲ 710mm 710mm ZA-D2 ZA-D2 ZA-D2 ZA-D2 710mm 710mm ZA-D3 ZA-D3 -27-...
Page 28 ZA-D2 x2 D6 x6 F4 x12 ZA-D3 x2 F1 x16 Ⅰ ZA-D3 Ⅱ Ⅲ Ⅴ Ⅲ Ⅲ ZA-D3 Ⅳ Ⅳ Ⅱ ZA-D2 Ⅴ Ⅳ Ⅵ Ⅳ Ⅳ Ø3mm ZA-D2 ZA-D2 Ⅲ Ⅲ Ø3mm ZA-D3 -28-...
Page 29 ZA-D2 x2 F1 x16 ZA-D3 x2 ZA-D3 ZA-D3 ZA-D2 ZA-D2 ZA-D2 ZA-D3 -29-...
Page 30 Left and right walls Ⅳ F4 x132 WA1A WA3A ZA-A1 ZA-A3 ZA-B1 ZA-B1 -30-...
Page 31 ZA-B1 F4 x28 B7 x4 Ⅱ Ⅱ Ⅱ Ⅱ Ⅱ Ⅱ Ⅱ ZA-B1 Ⅱ Ⅰ ZA-B1 Ⅱ Ⅰ ZA-B1 ZA-B1 ZA-B1 -31-...
Page 32 ZA-A1 x2 C2 x2 F4 x16 ZA-A3 x2 Ⅲ Ⅱ Ⅱ ZA-A3 Ⅱ Ⅰ Ⅲ Ⅱ Ⅱ ZA-A1 ZA-B1 ZA-B1 Ⅱ Ⅰ Ⅲ ZA-A1 ZA-A3 ZA-A3 ZA-B1 F4 ZA-B1 -32-...
Page 33 WA1A x2 WA4 x2 F4 x48 WA3A x2 Ⅱ Ⅱ Ⅰ Ⅱ Ⅱ Ⅱ WA3A F4 x6 WA1A WA1A WA3A Ⅰ WA3A F4 x6 Ⅱ WA1A F4 x6 F4 x6 -33-...
Page 34 A10 x4 A6A x12 F4 x40 C1 x16 Ⅳ Ⅴ WA3A Ⅴ Ⅳ Ⅰ Ⅰ WA1A Ⅱ Ⅰ Ⅰ Ⅰ Ⅲ Ⅰ ZA-A3 Ⅰ Ⅱ Ⅰ Ⅲ Ⅰ ZA-A1 -34-...
Page 35 Ⅰ WA3A WA1A WA1A WA3A ZA-A1 ZA-A3 ZA-A3 ZA-A1 Ⅱ Ⅲ WA3A WA1A ZA-A3 ZA-A1 ZA-A1 ZA-A5 Ⅳ Ⅴ F4 x3 F4 x3 F4 x2 WA1A WA3A F4 x2 F4 x3 WA1A F4 x3 WA3A -35-...
Page 36 Assembled above the foundation Ⅳ Ⅰ Ⅱ Ⅳ -36-...
Page 37 Ⅱ ZA-A5 Ⅲ B8 x6 ZA-A5 Wooden Mallet F4 x4 Ⅱ Ⅰ Ⅲ Ⅰ F4 x6 Ⅰ B8 B8 Remove Ⅱ ZA-A5 B8 B8 Ⅰ Ⅲ Step1: Cut the A10; Step2: Loose the F4 on fixed C1 to make C1 slide up and down; Step3: Assemble two pcs of C1 with WA1A or WA3A Step4: Assemble the A10 with the below C1...
Page 38 B7 x2 B9 x2 B8 x2 F4 x10 Ⅰ Ⅱ Ⅰ Ⅱ Ⅰ Ⅱ F4 x4 -38-...
Page 39 Wooden Mallet F4 x4 Ⅰ Ⅱ Ⅰ Remove Ⅰ ZA-A5 Ⅱ Ⅱ Step1: Cut the A10; Step2: Loose the F4 on fixed C1 to make C1 slide up and down; Step3: Assemble two pcs of C1 with WA1A or WA3A Step4: Assemble the A10 with the below C1 -39-...
Page 40 B9 x2 B7 x2 B8 x2 F4 x10 Ⅰ Ⅰ Ⅱ Ⅱ Ⅰ Ⅱ F4 x4 -40-...
Page 41 Window Window Window Window -41-...
Page 42 Window SW4 SW4 SW4 SW4 -42-...
Page 43 W1 x8 F10 x8 F4 x32 W2 x8 -43-...
Page 44 W3 x4 F8 x8 F4 x8 SW1 x4 152mm±20 -44-...
Page 45 Silicon W4 x8 Silicon SW4 x16 F11 x4 -45-...
Page 46 F4 x12 TA5 x1 Ⅰ Ⅰ Ⅰ Ⅰ Ⅰ Ⅰ Ⅰ F4 x6 F4 x6 -46-...
Page 47 Ⅰ ZA-A3 Ⅰ ZA-A3 Ⅰ C1 x4 F4 x12 Wooden Mallet ZA-A5 ZA-A5 ZA-A3 ZA-A3 Ⅱ ZA-A5 ZA-A5 -47-...
Page 48 Ⅰ A11 x4 Ⅱ Ⅰ F4 x8 Ⅱ Ⅱ WA1A Ⅱ Ⅰ WA3A Ⅱ ZA-A5 ZA-A5 WA3A WA1A -48-...
Page 49 A7A x8 F4 x40 Ⅱ Ⅰ F4 x5 Ⅱ Ⅱ Ⅱ Ⅱ Ⅲ Ⅳ Ⅲ Ⅳ Ⅳ Ⅲ Ⅲ Ⅳ Ⅳ Ⅲ WA3A WA3A -49-...
Page 50 A7A x4 F4 x8 Ⅰ Ⅱ F4 x2 Ⅱ Ⅱ Ⅲ Ⅲ Ⅲ WA3A -50-...
Page 51 Window Ⅱ Ⅰ Ⅰ Ⅱ Ⅰ Ø3mm Ø3mm Help to exclude rain Ⅱ Window Window -51-...
Page 52 Window Ⅴ Ⅲ Ⅳ F4 x2 Ⅱ F4 x2 770mm Ⅰ 510mm -52-...
Page 53 Window Close Open -53-...
Page 54 F12 x24 CW8 x4 CW6 x8 SW3 x12 F4 x24 F13 x4 CW7 x4 SW2 x12 Ⅱ Ⅰ Ⅲ -54-...
Page 55 W5 x4 TC1 x6 SW4 x8 F11 x4 Ⅳ Ⅴ Window Open Close Ⅵ 663mm -55-...
Page 56 A12 x14 Ⅰ Ⅱ Ⅲ WA1A WA3A WA1A WA3A Ⅳ Ⅳ Ⅱ Ⅰ Ⅰ Ⅰ Ⅱ Ⅲ Ⅰ Ⅰ Ⅳ Ⅲ Ⅰ Ⅰ -56-...
Page 57 J1 x35 Ⅰ Ⅰ Ⅰ Ⅰ Ⅰ P3L P4L Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅲ Ⅰ Ⅱ Ⅲ WA1A WA3A -57-...
Page 58 Ⅰ ZA-A5B ZA-A5B C7 x2 ZA-A5B Ⅰ ZA-A5B A9LB ZA-A5B A10L A9RB A8RB A8LB A7RB A10R ZA-A5B A6RB A7LB A6LB A4B A4B A6LB A6RB Ⅰ Ⅱ Ⅲ Ⅴ Ⅳ ZA-A5B ZA-A5 -58-...
Page 59 ZA-A5C A**C A**D ZA-A5C A7AC A7AD ZA-A5C A7AD A7AC A7AD A7AD ZA-A5C A4C A4C Ⅰ Ⅰ Ⅱ Ⅱ -59-...
Page 60 WA1B x2 Silicon WA3B x2 Silicon C8 x2 F4 x4 WA1C x6 Ⅰ Ⅱ Ⅳ WA1B WA1C WA3B WA3B Ⅴ Ⅴ WA1B Ⅳ Ⅴ WA1B Ⅴ Ⅲ WA3B Ⅴ Ⅳ -60-...
Page 61 G1 x4 G2 x4 F5 x8 Silicon Silicon C6L x2 C6R x2 G3 x12 ZT-C16 x2 G5 x4 G4 x4 F4 x12 S6L x2 S6R x2 Ⅴ Ⅵ Ⅳ Ⅲ Ⅵ Ⅱ Ⅳ Ⅵ Ⅴ Ⅲ Ⅴ Ⅳ Ⅲ Ⅱ Ⅲ...
Page 62 Ⅱ Ⅰ Ⅲ Ⅳ WA1B G3 x3 WA1B ZT-C16 Ⅵ Ⅴ ZA-A5 Silicon ZA-A5 -62-...
Page 63 F7 x24 L3 x2 L2 x2 F2 x6 C9 x4 F3 x8 F6 x6 Door Door -63-...
Page 64 Ⅰ Ⅲ 10mm±3 Door F7 x2 F7 x2 Door Door F6 x3 F3 x4 5-8mm Ⅱ 5-8mm Ø5mm Door Determine the appropriate location before installing Door F3 x4 the door touch L2. 10mm±3 <5mm Tighten the screws F1 Install the screws C9 to remove the door Ⅳ...
Page 65 Tighten all screws -65-...
Page 66 Maintenance: In a timely manner the centralizer skeleton. 1.If the ground not level off, loose soil layer thickness is differ, wall shed may tilt to one end, once found, should be timely the centralizer, in case of deformation. The shed may be slant when facing the un-level ground or loose soil layer, please righting the shed urgently to avoid deformation 2.Prevent increased loading-weight artificially.
