Summary of Contents for ONAK Foldable Origami Canoe
- Page 1 Manual Foldable Origami Canoe...
- Page 2 Watch the assembly video for more tips and tricks www.onakcanoes.com/instructions...
-
Page 3: What's In The Box
What´s in the box Small seat Large seat Borders female (6) Wheels (2) Origami Canoe (folded) Wheel split (2) Wheel axle (2) Wheel spacer (4) Borders male (4) - Page 4 1. Unfold your ONAK Topview C: Nose strap C: Nose strap (bottom) (bottom)
- Page 5 2. Attach the borders Male Female Put the borders through the straps and connect them Click the borders on both sides and tighten straps A and B...
- Page 6 3. Fold the noses Fold the nose and pull the nose straps (C) on both ends...
- Page 7 4. Pull the straps and guide the sides Pull strap D alternately to shape the ONAK to look the same as the drawing Fold the wing inwards and then pull strap E fully Pull strap B fully and guide the...
- Page 8 5. Insert the seats Put the seats in the canoe, start with the big seat - connect one side first Push the hooks forward so they are easy to connect - place the lock in the opening Slide the hook forward to make mounting easier Positions To change positions all high...
- Page 9 6. Insert the rib The hook at the end of the rib has to be placed around the inner screw next to strap A Slide the rib towards the dented line on the bottom It helps if you lift the bottom section of the rib...
- Page 10 7. Final tightening of every strap Tighten every straps B, C, E all the way to the end and cross D as much as possible Check whether every strap is completely tightened Sailing direction Two persons One person...
- Page 11 8. Ready to paddle On strap B and C the black buckle needs to be close to the grey buckle...
- Page 12 9. Pack your ONAK together Release cross straps D Dismantle the seats and rib Loosen every strap Flatten the canoe hull and take o the borders Roll the canoe together...
- Page 13 10. Packing the canoe hull Mount the bottom lid and turn the canoe around Place the rib around the small seat and put one seat on each side, the paddles and borders are next Close the case by placing the top lid Turn the canoe...
- Page 14 Assemble the lids...
-
Page 15: Safety First
On onakcanoes.com we invite you to connect with other users and exchange adventures. Reach out and let us know what you think! At ONAK we take feedback very seriously, as it helps us enhance both the products we sell and the services we provide.
