Technical notice
Installation
Assembly
Maintenance
Safety
Air conditioners of the type:
SF3, SF6, DF3, DF4.5, DF6
For your safety and for your information,
it is imperative that you read this notice
before installation
Climinox
Z.A. Rue St Éloi
61100 St Georges des Groseillers
France
Tel: +33 (0) 233 62 29 50
Fax: +33 (0) 233 62 29 54
Email: climinox@wanadoo.fr
www.climinox.fr
Advertisement
Table of Contents
Summary of Contents for Climinox ModulAir SF3
- Page 1 Safety Air conditioners of the type: SF3, SF6, DF3, DF4.5, DF6 For your safety and for your information, it is imperative that you read this notice before installation Note Climinox published on 01/01/2011 (this document can be modified without notice)
-
Page 2: Table Of Contents
Blowing duct ……………………………………………………………………………..8 – Accessories …………………………………………………………………….… p.12 Maintenance & Safety ……………………………... p.12 Upkeep ……………………………………………………………………………….. p.13 Maintenance ………………………………………………………………………….. p.13 EC declaration of conformity ……………………… p.14 Note Climinox published on 01/01/2011 (this document can be modified without notice) 2 / 14... -
Page 3: Introduction
1.3 Liability limitation Climinox cannot accept any liability if the machine is used with the doors or access hatches open, if the protections are not in place or if the conditions set out in this manual are not met. -
Page 4: General Points
CH: Frame mounted on the floor. The 2nd code provides info on the cooling battery: n F: The number of rows in the chilled water battery. Note Climinox published on 01/01/2011 (this document can be modified without notice) 4 / 14... -
Page 5: Suspension & Weight
Ordinary nuts risk becoming unscrewed with the vibrations caused by the ventilation. Note Climinox published on 01/01/2011 (this document can be modified without notice) 5 / 14... -
Page 6: Electrical Power Supply
Assemble the splashback with the triangular plate and the stand carrier crosspiece. Fasten the ceiling jambs onto the plates of the machine. Use ø8 washers and nuts Note Climinox published on 01/01/2011 (this document can be modified without notice) 6 / 14... -
Page 7: Installing The Frame
Finally, finish with the crosspiece for attaching the condensate pan. OR via the ventilation module in the case of a frame model on the floor. Note Climinox published on 01/01/2011 (this document can be modified without notice) 7 / 14... -
Page 8: Connection Of The Layers
- Ø 8/85 connector bolts - Ø 8 flat washers and nuts Seal to be used: - Ø25x5x35 O-ring seals - Ø 38x1.5 retaining rings Note Climinox published on 01/01/2011 (this document can be modified without notice) 8 / 14... -
Page 9: Installation Of The Façade Panels
2. inserting the top hooks in the hooking slots 3. folding back The pan for recovering the condensation water is then suspended under the air conditioner. Note Climinox published on 01/01/2011 (this document can be modified without notice) 9 / 14... -
Page 10: Options
The stream must not be directed towards the battery or the wall of the condensate pan. It has to be axed towards the opposite corner of the pan. Note Climinox published on 01/01/2011 (this document can be modified without notice) 10 / 14... -
Page 11: Blowing Duct
Otherwise there will be premature wear and the duct will be torn. Note Climinox published on 01/01/2011 (this document can be modified without notice) 11 / 14... -
Page 12: Accessories
The quality of the measurement is essential in order to obtain a safe and reliable adjustment. Climinox provides psychrometer wall supports. The support is separated from the wall in order to protect the sensors from the radiating effect of the wall. They have a substantial reservoir of water. -
Page 13: Upkeep
The person intervening must also ensure that the heating batteries are cool enough. Upkeep Climinox air conditioners are designed to be washed with a high-pressure hose. - Prewash with clean water. - Spray the detergent, with a foam gun. (the PH of the solution must be suitable for stainless steel), - Rinse with plenty of clean water. -
Page 14: Ec Declaration Of Conformity
SARL with a capital of 60,000 Euros / SIRET: 415 245 927 00017 / APE: 2599B / EEC: FR Tel: +33 (0) 233 62 29 50 / Fax : +33 (0) 233 62 29 54 / Mail : climinox@wanadoo.fr Note Climinox published on 01/01/2011 (this document can be modified without notice) 14 / 14...
