Summary of Contents for ONESIGHT SystemView10
- Page 1 SH-SystemView10 Configuration SH-SystemView10 Configuration v2.0 Document Change Log Jan 2019 Document created for new version ofSystemView10.
-
Page 2: Table Of Contents
SH-SystemView10 Configuration Table of Contents Introduction ............................3 Specifications ............................4 Dimension ............................... 5 Hardware Installation ..........................5 Ethernet/Date & time ..........................7 SystemView 2.0a ............................ 8 SystemView 2.0a Settings ........................9 Configurations ............................10 Jan 2019 Document created for new version of... -
Page 3: Introduction
SH-SystemView10 Configuration Introduction This user guide will help you to configure SystemView10 in a fast and efficient manner. This device is based on Android OS and so there are several settings that device is expecting to get from the network in order to work properly. -
Page 4: Specifications
SH-SystemView10 Configuration Specifications Model: SystemView10 Hardware Solution: Allwinner A83T processor Specs CPU: 8-Core ARM Cortex A7 CPU, 1.2Ghz Display: 10.1 Inch IPS Display,Resolution:1280 x 800, Brightness:350 nit, Ratio:16:10 RAM: Nand Flash: Sound System: 1W X 1, With Speaker Tunnel Protection... -
Page 5: Dimension
SH-SystemView10 Configuration Dimensions Hardware Installation Requirements: • 4x metal clips • 1x metal bracket • 2x screws... - Page 6 SH-SystemView10 Configuration 1. Make the cutout for the tablet 2. Screw the metal clips to hold the metal bracket...
-
Page 7: Ethernet/Date & Time
Go to Settings->Ethernet, enable Ethernet and if you want to use Static IP address click on Static IP • Set the IP Address of your SystemView10; • Set the Subnet mask of your network (usually 255.255.255.0); • Set the Gateway. -
Page 8: Systemview 2.0A
SH-SystemView10 Configuration SystemView 2.0a This app was made to keep the web page opened and to exit only through password. SystemView app will open on boot and even when the tablet reboots it will open automatically. To configure this app you just need to set the IP of your device and first time you power the tablet you need to set to open this app always on boot. -
Page 9: Systemview 2.0A Settings
SH-SystemView10 Configuration Uninstall. After this you need to connect an USB stick with the latest app and go to Menu->File Manager->USB->usbhost1 and click on latest SystemView apk file, do install and after the installation is done you need to reboot the tablet. -
Page 10: Configurations
SH-SystemView10 Configuration Configurations By default this SystemView device must come with this configuration from factory, anyway you can check these configuration to make sure it works correctly. - SystemView 2.0a app installed. - screensaver.png image must be pasted into folder /storage/emulated/0/systemview/screensaver/...
