SURE-GRIP XL™ Tool Mounts
Models SG-VM-XL & SG-VM-XLS
Parts and Instruction manual
*
* Figures shown with 19-1/2" strap (SG-VM-XL). 15-1/2" Strap (SG-VM-XLS) is similar.
MODEL
SG-VM-XL
SG-VM-XLS
ITEM
1
2
3A
3B
4
5
6
7
8
9
10
DESCRIPTION
SURE-GRIP XL Bracket - 3" - 4" grip range
SURE-GRIP XL Bracket - 2" - 3" grip range
PART NUMBER
3085-505-105
3085-505-107
3085-505-109
STRAP, STANDARD 19.5" (SG-VM-XL)
3085-510-109
9125-191306
SCREW, #6-20 x 3/8", PLASTIC THREAD
9010-262528
9013-172500
NUT, 1/4-20 HEX HEAD, LOW-PRO NYLON
9014-262500
LOCK WASHER, 1/4" EXTERNAL TOOTH,
9014-161600
FENDER WASHER, #8 X 1.000 O.D. ZPS
3085-505-901
9014-112500
DESCRIPTION
SURE GRIP BASE
STRAP PLATE
STRAP, SHORT 15.5" (SG-VM-XLS)
CUTTING, SS, 94629A70
SCREW, 1/4-20 x 2" TRUSS HEAD ZPS
LOCK, ZPS
ZPS
PAD WITH ADHESIVE, 3" x 4"
FLAT WASHER, 1/4" ZPS
ZICO
®
3085PM3
REV. 4-19-21
WT./@
IN LBS.
.90
.90
QTY.
1
1
1
1
4
2
2
2
1
1
2
Advertisement
Table of Contents
Summary of Contents for Ziamatic Zico SURE-GRIP XL SG-VM-XL
- Page 1 ZICO ® SURE-GRIP XL™ Tool Mounts 3085PM3 Models SG-VM-XL & SG-VM-XLS Parts and Instruction manual REV. 4-19-21 * Figures shown with 19-1/2" strap (SG-VM-XL). 15-1/2" Strap (SG-VM-XLS) is similar. WT./@ MODEL DESCRIPTION IN LBS. SG-VM-XL SURE-GRIP XL Bracket - 3" - 4" grip range SG-VM-XLS SURE-GRIP XL Bracket - 2"...
- Page 2 Page 2...
- Page 3 Page 3...
- Page 4 TOLL FREE: 800-711-3473 10 West College Avenue, P.O. Box 337, Yardley, PA 19067-0587 • (215) 493-3618 • FAX: (215) 493-1401 Copyright Ziamatic Corp. 4-21 *ZICO is a registered trademark for fire, safety and marine products made by Ziamatic Corp. Page 4...
