AMERICAN ULTRAVIOLET LESCO SUPERSPOT MAX Technical Reference Manual

Uv spotcure system
Hide thumbs
Table of Contents

Advertisement

Quick Links

SUPERSPOT™
MAX / MAX HP
Model: VSM3002
UV SPOTCURE SYSTEM
100 / 200 WATT
TECHNICAL REFERENCE
MANUAL
This product conforms to
CE Standards
See Appendix B for details
AUV\LESCO
A DIVISION OF AMERICAN ULTRAVIOLET COMPANY
WWW.LESCOUV.COM
23555 Telo Avenue
REV.
Torrance, CA 90505
F
1/26/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LESCO SUPERSPOT MAX and is the answer not in the manual?

Questions and answers

Related Manuals for AMERICAN ULTRAVIOLET LESCO SUPERSPOT MAX

Summary of Contents for AMERICAN ULTRAVIOLET LESCO SUPERSPOT MAX

  • Page 1 MAX / MAX HP Model: VSM3002 UV SPOTCURE SYSTEM 100 / 200 WATT TECHNICAL REFERENCE MANUAL This product conforms to CE Standards See Appendix B for details AUV\LESCO A DIVISION OF AMERICAN ULTRAVIOLET COMPANY WWW.LESCOUV.COM 23555 Telo Avenue REV. Torrance, CA 90505 1/26/10...
  • Page 2 KMD1042F.DOC...
  • Page 3 KMD1042F.DOC...
  • Page 4 KMD1042F.DOC...
  • Page 5 AUV\LESCO FIBER OPTIC LIGHTGUIDES WARRANTY POLICY WARRANTY: Fiber optic lightguides sold by AUV\LESCO are warranted to be free from defects in material and workmanship under normal and proper use for 60 days from date of original shipment. This warranty applies solely to defects in material and workmanship. AUV\LESCO will repair or replace at its option, any defective fiber optic lightguides when returned to AUV\LESCO by the purchaser, all transportation paid by the purchaser, within 60 days from date of original shipment.

  • Page 6: Table Of Contents

    Table of Contents General Information ................... 7 1.1 Scope of Manual..................7 1.2 System Description ................... 8 Safety ......................... 9 2.1 Ultraviolet Radiation.................. 9 2.2 Power up ....................10 Component Descriptions .................. 11 3.1 Front Panel ..................... 11 3.2 Back Panel....................13 3.3 Housing....................
  • Page 7 8.2 Optical Components ................31 Drawings/Schematics..................34 9.1 Main Schematic ..................34 9.2 I/O Connector - Parallel Interface ............41 9.3 Serial Communication................43 10.0 Accessories ...................... 46 10.1 Standard Replacement Parts..............46 10.2 Optional Liquid-Filled Lightguides............46 10.3 Fiber Optic Lightguides................46 10.4 Recommended Spare Parts Kit ..............

  • Page 8: General Information

    1.1 Scope of Manual This manual provides information necessary for operating and maintaining the AUV\LESCO SUPERSPOT MAX UV spot curing system (the MAX). It also includes safety requirements and references to pertinent mechanical and electrical drawings. Throughout this manual, precautions necessary to prevent injury to personnel are preceded by the heading WARNING;...

  • Page 9: System Description

    1.2 System Description The AUV\LESCO SUPERSPOT MAX curing systems are ultraviolet (UV) light sources that provide an intense concentration of UV light for the purpose of spot curing UV sensitive materials (photo polymerization). The MAX is the most powerful UV spot curing system that utilizes a lightguide delivery method (liquid filled or fiber type).

  • Page 10: Safety

    The AUV\LESCO SUPERSPOT MAX features: • UV intensity for 100 Watt MAX up to 25 Watts in UVA, up to 30 Watts or more total intensity (Traceable to NIST) • UV intensity for 200 Watt MAX HP up to 30 Watts in UVA, up to 45 Watts or more total intensity (Traceable to NIST) •...

  • Page 11: Power Up

    allowing any skin surface from coming within close proximity of the high intensity light output(s). Additionally, it is never advisable to stare directly at any high intensity light source whether visible or ultraviolet for prolonged periods unless precautions have been taken to reduce both visible and ultraviolet light to safe levels.

  • Page 12: Component Descriptions

    Component Descriptions 3.1 Front Panel The front panel is a membrane control pad with digital displays and LED indicators. The keypad controls all the major operating features of the MAX. Distal UV sensor Lightguide Port/Receptacle Connector UV digital display Timer digital display ON time Number of cure Power to the bulb in watts...
  • Page 13 The electric power displayed is the necessary excitation applied to the bulb to achieve the required intensity. It is a useful indicator to monitor the status of the bulb or its performance. The SELECT button is used to change modes. Each time the SELECT button is pressed, a different LED illuminates the specified mode.

  • Page 14: Back Panel

    3.2 Back Panel The MAX housing is made of stainless steel, making it ideal for clean room applications. The following parts and connections are located on the rear of the system. Cooling Fan I/O Connector Footswitch Connector Power Control Switch RS-232 Connector RS-485 Connector ** CAUTION **...
  • Page 15 3.2.2 Power Entry Module It contains the power switch, power cord socket (IEC type), main fuse, and EMI filter. ** WARNING ** For continued protection against risk of fire, replace only with the same type and rating of fuse. Input volts Fuse rating 115-120 4A T, 250 VAC, Slow Blow...

  • Page 16: Housing

    Housing The MAX housing is made of stainless steel, making the equipment suitable for clean room operations and allowing for easy cleaning. The housing consists of 3 main sections: Chassis - The vertical design allows for more efficient use of counter-top space. The optical assembly is located in the upper compartment.
  • Page 17 3.3.1 Lamp Housing Compartment This area contains the optical transmission assembly, bulb, reflector, optical feedback sensor and electrical lamp connections. The function and relationship of each component in the lamp housing is described below: Bulb Reflector Sub-Assembly Lightguide Receptacle UV Bulb UV Bulb Connector Block 3.3.2 Shutter Assembly The Shutter Assembly is a shutter plate that is connected to a positive open, spring return,...
  • Page 18 3.3.3 Bulb The MAX uses a proprietary high-pressure short arc mercury vapor bulb designed for long life at very high intensity. 3.3.4 Reflector The reflector is a high precision, first surface elliptical reflector used to gather and focus the highest concentration of the available energy from the bulb. 3.3.5 Bulb Reflector Sub-Assembly The Bulb Reflector Sub-Assembly is detachable, and it consists of the bulb holder and an elliptical metal-formed reflector.

  • Page 19: Special Features

    3.3.8 Lightguide Receptacle The Lightguide Receptacle is a precision mechanical assembly that aligns the bulb, bulb reflector assembly, and lightguide for optimal focal point location. It also supports the shutter assembly, optical feedback sensor, lightguide safety switch, and infrared filter. 3.4 Special Features Here are several special features that can be accessed via the front panel.

  • Page 20: Interior Control Components

    3.4.3 Alarm Latching The High Limit Alarm indicator can be latched on. If an alarm is latched on, it will remain set on until power is turned off. The Alarm Reset button will silence the beeper sound only. When the non-latching mode is selected, the Alarm indication (both visual and audible) will extinguish upon shutter closure.
  • Page 21 The Display/CPU board allows setting of the UV output; shutter ON/OFF times and number of desired exposures, power alert and reset, hour meter and provides access to user calibration procedure. All these functions are explained in Section 3.0. The CPU on this board and the battery back up SRAM allow data storage for up to 5 years, which is accessible through the serial communications ports located on the rear panel (see Section 3.2).

  • Page 22: Installation/Start Up

    Installation/Start Up Before unpacking the system, inspect the shipping container for any damage such as broken corners, deformity, holes and tears. After unpacking the system, examine the equipment for any damage i.e. unusual dents or rattling of components. Check components against the packing list to make sure all components were shipped correctly.
  • Page 23 4. Replace the nut on the end of the bulb and tighten against the reflector base. Then, using serrated pliers tighten the nut 1/8 to 1/4 turns. UV Bulb Knurled nut Reflector Bulb Connector Reflector base Bulb ** CAUTION ** Lamp surface is hot during normal operation.

  • Page 24: Voltage Setting

    ** WARNING ** Do not look into the emitting end of the lightguide. Use proper shielding at all times. Safety glasses are provided with each system. Avoid exposing skin to UV light. Shielded UV enclosures and safety glasses are available for purchase from AUV\LESCO. ** CAUTION ** Check input voltage and set input power module switch before plug in.
  • Page 25 See Detail A-A Figure 1. Detail A-A To change from 120VAC to 240VAC input, move the connector shown in Detail A-A 1 pin position forward as shown below. Voltage Selection Connector 120 VAC 240 VAC Figure 1A. Voltage Setting. KMD1042F.DOC...

  • Page 26: Operation

    Operation Turn on the power switch located on the back of the MAX above the power cord receptacle. After an initial hardware check, indicated by the sequential illumination of the front panel indicators, the system shows its serial address in the front displays as Adr XX and then ignites the bulb.

  • Page 27: Alarm Latching (Al)

    5.2 Alarm Latching (Al) The Optical Feedback Alarm is set when the control loop can no longer operate. When the Alarm Latching mode is selected, the indicator will remain ON until power is turned off, including the ALARM LED blinking, the I/O connector output and the serial interface. The buzzer will also sound, but it may be silenced by pressing the ALARM RESET button.

  • Page 28: Calibration Error

    Once the Low value is found, that number will freeze in the left-hand display and the right-hand display will continue the count until the high value is found. The high value corresponds to the highest bulb output at the power supply maximum setting. Once these values are found, the shutter will close automatically.

  • Page 29: Serial Communication Datamax

    7.0 Serial Communication DataMAX 7.1 Serial Communication The Super Spot Max has remote data acquisition access and control capability. It is possible to connect up to 100 Super Spot Max units when using a multidrop RS485 serial communications link. Each unit has to be individually addressed 0 to 99 and each system will respond to a command when its address appears in the command.

  • Page 30: Data Max Interface

    Daughter Card Controller Average Restart Read Feedback Photodiode Load DAC Feedback Gain Help High Limit Threshold Low Limit Threshold Monitor Gain Open/Closed Loop Mode Read Lamp Power Read Monitor Photodiode Limit Status Lamp Start Bit 7.2 Data MAX Interface There is a Virtual Instrument (VI) interface to help communication to the MAX unit using a standard computer or a laptop.

  • Page 31: Maintenance

    Maintenance 8.1 Housing The MAX is a simple, rugged unit and does not require complicated routine maintenance. Routine maintenance consists of keeping the unit clean, periodical cleaning of air filters, and periodical UV output measurements to ensure that the unit performs optimally. 8.1.1 Cleaning **WARNING** Make sure the main power switch is turned off and...

  • Page 32: Optical Components

    8.1.2 Air Filter Cleaning The MAX has two fans located at the rear panel; each of the fans is equipped with a removable air filter. To remove the air filter, snap off the flexible plastic fan cover. The air filter is easily removable from the fan opening. Wash the filter with warm water and air dry. When dry, place the filter inside the plastic cover and snap shut over fan.
  • Page 33 8.2.4 Lightguides AUV\LESCO lightguides are available in either “liquid-filled” (LF) or “fiber optic” (FO) types. Liquid-filled Lightguides The standard lightguide shipped with most AUV\LESCO SUPERSPOT cure products is a 1M x 5mm LF model. This device allows flexible delivery of high intensities of light with approximately 80% transmission efficiency in the UV ”A”...
  • Page 34 All lightguides can be damaged or suffer impaired light transmission if not used properly. Minimize bending a lightguide radically (i.e. – more than 90° over a 6” radius for a LF). Be extremely careful not to scratch, mar or accidentally apply curable material to the guide end tips.

  • Page 35: Drawings/Schematics

    Drawings/Schematics The following section is a set of drawings and schematics complete with specifications for the MAX system and accessories. 9.1 Main Schematic KTM2224 Electrical Schematic KMD1042F.DOC...
  • Page 36 KMD1042F.DOC...
  • Page 37 KMD1042F.DOC...
  • Page 38 KMD1042F.DOC...
  • Page 39 KMD1042F.DOC...
  • Page 40 KMD1042F.DOC...
  • Page 41 KMD1042F.DOC...

  • Page 42: I/O Connector - Parallel Interface

    9.2 I/O Connector - Parallel Interface The MAX unit incorporates an external parallel interface connector in its back panel. The MAX unit communicates with external equipment using inputs and outputs. There are several combinations available that include different shutter trigger signals and external safety interlock.
  • Page 43 I/O Pin-Out viewed from rear of unit 9.2.1 Standard Parallel Interface Input Option 9.2.1.1 VUM1029 A jumper between pin 1 and pin 2 will activate the shutter cycle. If a semiconductor switch is used, the sourcing input pin 1 must be drain to pin 2 with a device able to handle 15mA DC.

  • Page 44: Serial Communication

    9.3 Serial Communication The MAX system includes a powerful serial communication protocol, allowing it to interconnect using the popular RS485 or RS232 interfaces to other devices such as computers, PLC and other embedded controller systems. The RS485 serial interface is capable of supporting up to 100 MAX systems at a time, with each unit set at a unique address to communicate with the host device.
  • Page 45 9.3.4 Connection Cable RS485 DB 9 DB 9 Inverting Receiver Input Non-Inverting Receiver Input RS485 Adapter MAX 00 MAX 01 MAX 99 9.3.5 Connection Cable RS232 DB 9 IMPORTANT NOTICE: RS232 for point-to-point (1 unit) application, NOT intended for Multidrop Network. Computer RS232 KMD1042F.DOC...
  • Page 46 9.3.6 Networking Adapter SSM3076 for VSM3002 Use Adapter SSM3076 for Super Spot MAX Model VSM3002 networking. SSM3076 adapts the RS-485 DB9 standard connector (VSM3002) to the RS-485 circular connector (VSM3001). KMD1042F.DOC...

  • Page 47: Accessories

    10.0 Accessories 10.1 Standard Replacement Parts To order replacement parts please call the AUV\LESCO spare parts dept. in Torrance, CA. TOLL FREE (800) 615-3726 or (310) 784-2930. Shutter NZB1010 2 Amp, 120V AC input fuse EFB1008 4 Amp, 240V AC input fuse EFB1007 Foot Pedal EVB2115...

  • Page 48: Recommended Spare Parts Kit

    10.4 Recommended Spare Parts Kit RECOMMENDED SPARE PARTS KIT FOR VSM3002 SSMAX100W (Level I – qty 1-4 units)______________ .LESCO Part # Description EFB1007 Fuse, 4 Amp, 250V EFB1008 Fuse, 2 Amp, 220V EPB1054 Top & Bottom fan ITB1096 Teflon stop EXB1111 Board Amp KFB1019...
  • Page 49 RECOMMENDED SPARE PARTS KIT FOR VSM3002 SSMAX 200W ____________________ (Level I – qty 1 – 5 units)_____________ .LESCO Part # Description EFB1007 Fuse, 4 Amp, 250V EFB1008 Fuse, 2 Amp, 220V EPB1025 Top & Bottom fan ECB2051 Lamp Connector ITB1096 Teflon stop EXB1111 Board Amp...

  • Page 50: Troubleshooting

    11.0 Troubleshooting *** CAUTION *** PARTS MAY BE HOT. If unit was running allow time for cool down. Exercise care when touching internal optical parts. *** WARNING: HIGH VOLTAGE *** High voltage may be present in bulb terminal connections. Allow 2 minutes to bleed down capacitor voltage. *** CAUTION *** Disconnect power from system or unplug system from wall or VAC power source before connecting the footswitch adapter.
  • Page 51 Open circuit voltage (no bulb). Open circuit voltage should rise to approx. +2340 Vdc for a few seconds, and then drop to approx. +330 Vdc. If power supply blows fuses without a load, then power supply components, wiring or shorts may be the problem. Perform visual inspection of power supply components and wiring.
  • Page 52 Verify that the lightguide is properly pushed into the lightguide socket and that the ball plunger is in the detent groove. MAX unit safety system disallows shutter operation if no lightguide is sensed by interlock switch within nosepiece. Set the unit to "Manual" mode. Turn the power ON. With a DC voltmeter, verify 24 VDC are present on the harness side of the solenoid connector and the footswitch is depressed.
  • Page 53 lightguide is standard 1M x 5mm LFLG type without radical bends. radiometer measurement through lightguide substantially less, replace lightguide (see Lightguides section of this manual or AUV\LESCO website). **WARNING** Bulbs are extremely hot when first shut off and can cause severe burns! Disconnect and remove the bulb;...
  • Page 54 Appendix A – UV Protective Eye Glasses Appendix B – Agency Approvals KMD1042F.DOC...
  • Page 55 KMD1042F.DOC...
  • Page 56 KMD1042F.DOC...
  • Page 57 KMD1042F.DOC...
  • Page 58 Appendix C – IR Filter Description Presented here are the different spectral output graphs of our various filters on the UV SpotCure series. Filter OFB1004 280nm-480nm Intensity (counts) 4000 3000 2000 1000 Wavelength (nm) Filter OFB1008 280nm-400nm Intensity (counts) 4000 3000 2000 1000...
  • Page 59 Filter OFB1013 275nm-500nm Intensity (counts) 4000 3000 2000 1000 Wavelength (nm) Filter OFB1014 280nm-320nm Intensity (counts) 4000 3000 2000 1000 Wavelength (nm) Filter OFB1019 400nm-500nm KMD1042F.DOC...
  • Page 60 Filter OFB1021 320nm-420nm Intensity (counts) 4000 3000 2000 1000 Wavelength (nm) KMD1042F.DOC...
