HARDWARE

Colours

Cassette / Bottom
Rail
i. White
ii. Ivory
iii. Anodised Silver
iv. Black
Cord
i. White
ii. Ivory
iii. Silver
iv. Black

Cord Length

500mm – 2500mm (in 250mm increments)
Maxim um / Minimum Blind Sizes
M inimum Width :
Maximum Width :
Minimum Drop :
Maximum Drop :
Zebra Blinds
PRODUCT INFORMATION
300mm
2700mm (recommend to keep it under 2600mm)
600mm
3000mm (for most fabrics) /
2800mm (for Blackout fabrics)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zebra and is the answer not in the manual?

Questions and answers

Summary of Contents for Blinds on the Net Zebra

  • Page 1 Zebra Blinds PRODUCT INFORMATION HARDWARE Colours Cassette / Bottom Rail i. White ii. Ivory iii. Anodised Silver iv. Black Cord i. White ii. Ivory iii. Silver iv. Black Cord Length 500mm – 2500mm (in 250mm increments) Maxim um / Minimum Blind Sizes...
  • Page 2 **Max. Drop varies depending on fabric thickness. Most light ltering fabrics can reach 300 0mm, but fo r the t hicker blockout fabrics (such as Valen tine Blackout ser ies) anything more than 2800mm may require an upgrade to our larger ‘Wintron ’...
  • Page 3 SUITABLE USES Dual Shades should be where possible avoided in certain situations: a. Very breezy or windy locations. [Fabric edges will be damaged]. b. In reach of pets or young children. [No brainer] c. Constantly moist areas [Mildew will eventually form] d.
  • Page 4 MEASURING 1. Inside Mount [Reveal Installation] – SEE Fig 1. i. Measure inside Reveal at “A” [width] and “B” [drop]. It is important that “A” is measured where the Cassette will be installed, as it is the widest part of the blind. [The Cassette is approximately 30mm wider than the fabric – 20mm (control) & 10mm (idle).
  • Page 5 ii. Measurement “D” is from top of architrave to bottom of architrave. No deductions necessary. INSTALLATION Installation of Dual Shades are not so different to other Cassette Roller blind systems. Installation Brackets are Universal [Both Inside and Outside Mount]. At least one bracket should be located as near as possible to the control end of the blind to support the chain operation of the blind;...
  • Page 6 and the dye lot of the swatch will not be exactly the dye lot of the finished blinds. DISCLAIMER The recommendations in this Information Manual are a guide only. Individual interpretation based on specific jobs, will be necessary.
