PowerLink AT2 Manual v1.2

PowerLink AT2 Manual

Hardware Overview

• Power Button on Top

• 48v and 24v buttons on front of unit

• LCD screen to tell you current status

• Light on top

• Power Over Ethernet LAN Port

• USB-C Charging system 2A

• USB Power Out

• Optional 5 GHz Access Point

Quick Start

• Power-On Powerlink AT2 Device

• Press the voltage you need to power your CPE

• Use a short CAT5 cable to go between the LAN port on the PowerLink AT2 and the CPE.

• Connect to

www.linktechs.net

• IP address should come from CPE (if you are configured for DHCP on your wireless device), or you will

need to statically configure it.

• Connect to your CPE using web/winbox or installation application.

Normally there is no need to login to the PowerLink, unless you wish to do some kind of special configuration,

things like change VLANs, SSIDs, security etc. Most of the time the unit will be completely pass-though, and

transparent bridging. Most manufacture applications prefer this.

Link Technologies, Inc.

www.linktechs.net

www.towercoverage.com

www.LinkTechs.net

SSID

314.735.0270

647.725.7011

636.660.1534

sales@LinkTechs.net

support@LinkTechs.net

invoices@LinkTechs.net

8839 Oermann Road

Dittmer, MO 63023

Table of Contents

Need help?

Do you have a question about the PowerLink AT2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Link Technologies PowerLink AT2

Page 1: Hardware Overview
Quick Start • Power-On Powerlink AT2 Device • Press the voltage you need to power your CPE • Use a short CAT5 cable to go between the LAN port on the PowerLink AT2 and the CPE. • Connect to www.linktechs.net SSID •...
Page 2: Table Of Contents
PowerLink AT2 Manual v1.2 Contents Hardware Overview ..............................1 Quick Start ................................1 Features: ................................3 WiFi Speed ..............................4 Optional USB AC Stick ............................. 4 Hardware ................................4 Top Features ............................... 4 Front Buttons/Leds ............................
Page 3: Features
PowerLink AT2 Manual v1.2 Features • 1.5-inch TFT RGB display • Passive Power Over Ethernet Device, Ubiquiti, Mikrotik, Cambium, etc. • Switchable 24V and 48V - 30W PoE. • Will power up 802.3at devices using 8 wires •...
Page 4: Wifi Speed
PowerLink AT2 Manual v1.2 WiFi Speed (theoretical): 2.4 GHz Width 40Mhz = 86 Mbps 2.4 GHz Width 20Mhz = 43 Mbps Optional USB AC Stick AC 5Ghz Width 80Mhz = 292Mbps AC 5Ghz Width 40Mhz = 150Mbps...
Page 5: Functions
PowerLink AT2 Manual v1.2 Functions Top Button This is the button on the top of the unit, next to the LAN and Power In port. • One click – Turn on Router and WiFi Turn on AT2 •...
Page 6: Display
PowerLink AT2 Manual v1.2 Timeout If the PoE out is on and the power is lower then 2W, unit turns off after 2 minutes. If only WiFi is on, it turn off after 15 minutes. You can remove this timeout from configuration.
Page 7: Default Configuration
PowerLink AT2 Manual v1.2 Default Configuration To Connect to the device and change options, you can connect via web browser via http://192.168.1.69 or SSH to the same IP address. The default Address: 192.168.1.69...
Page 8 PowerLink AT2 Manual v1.2 Web Interface You can access the web interface by browsing to 192.168.1.69. The username is root and password is either linktechs or geva. Link Technologies, Inc. 8839 Oermann Road www.linktechs.net Dittmer, MO 63023 www.towercoverage.com...
Page 9 PowerLink AT2 Manual v1.2 Status The tight menu gives you the status page. This includes, overview, Firewall, routes, logs, processes and graphing. The Status page gives you Hardware, Firmware versions and uptime. The network section tells you what is in-use and connected to the device.
Page 10: Iperf3
PowerLink AT2 Manual v1.2 Interface / Bridge Under Network → Interfaces, you have the option to configure new interfaces and/or edit the existing. The default should be LAN, this is a br-lan bridge group. Link Technologies, Inc.
Page 11 PowerLink AT2 Manual v1.2 By clicking edit, you can edit the LAN interface, this will bring up the following menu options: Here, you have options to select what protocol you wish, this could be used on the ethernet or any other interface.
Page 12 PowerLink AT2 Manual v1.2 Other options include; PPP, DHCP Client, or PPPoE. I would always recommend that you bring up the default interface stactially as well as upon boot. NOTE, there is options here that can render the device not reachable, and then a factory reset would be the only option.
Page 13 This section under status, gives you the wireless access point, SSID and encryption as well as the channel of radios0, this is the 2.4 GHz radio built into the PowerLink AT2. The radio1 would be if you have added the 5 GHz module into the unit.
Page 14 PowerLink AT2 Manual v1.2 In advanced settings at the top, you can select your country you are operating in, therefor it will keep the power levels to the max your country supports. NOTE, if you have legacy 802.11b devices, you will need to check the box to allow 802.11b devices, else you can uncheck this.
Page 15 PowerLink AT2 Manual v1.2 Under General Setup, you have options for what mode you wish to operate in, Access Point being the most common. Other options include client, ad-hoc, Monitor, and various WDS modes. Changing SSID You will change your SSID by going to Network →...
Page 16 PowerLink AT2 Manual v1.2 VLANs Under the Network → Switch, you have the ability to add VLANs to your configuration. What VLAN ID and what tag or untagged port it should come from. Link Technologies, Inc.
Page 17 314.735.0270 314.735.0270 647.725.7011 647.725.7011 636.660.1534 636.660.1534 sales@LinkTechs.net sales@LinkTechs.net www.LinkTechs.net www.LinkTechs.net support@LinkTechs.net support@LinkTechs.net invoices@LinkTechs.net invoices@LinkTechs.net PowerLink AT2 Manual v1.2 Firewall Link Technologies, Inc. 8839 Oermann Road www.linktechs.net Dittmer, MO 63023 www.towercoverage.com...
Page 18 PowerLink AT2 Manual v1.2 Change Password To Change the PowerLink ATs default password, go to System → Administration. Here you can change the default password. Link Technologies, Inc. 8839 Oermann Road www.linktechs.net Dittmer, MO 63023...
Page 19 PowerLink AT2 Manual v1.2 DHCP and DNS Iperf3 Iperf3 is always running. You can run the following command: iperf3 –c 192.168.1.69 On any Linux device, CPE, PC, etc. This Ethernet Test: root@PowerLinkAT:/# iperf3 -s...
Page 20: Samba3 And Usb Flash Key
PowerLink AT2 Manual v1.2 Samba3 and USB flash key USB flash memory FAT32 mounted in /mnt/usbkey Android and Linux shared as: 192.168.1.69/usbkey Samba3 does not work with windows 10, but you can enable it. (Search in google)
Page 21 PowerLink AT2 Manual v1.2 d. Release reset once you access this page 3. On HTML page of the router a. system, backup, update. Link Technologies, Inc. 8839 Oermann Road www.linktechs.net Dittmer, MO 63023...
Page 22: Special Functions
PowerLink AT2 Manual v1.2 Special Functions Connecting to the console, in ssh, and send command for: echo AutoOff=NO > /dev/ttyS0 Disable Auto WiFi Off, Turning the PoE Off echo AutoOff=YES > /dev/ttyS0 Enable Auto WiFi Off, Turning the PoE Off (Default) echo AutoOn=NO >...
Page 23 PowerLink AT2 Manual v1.2 Appendix: Cat5 Pinout Cambium Cable This cable Is for those cambium CPEs that require reversed power pins. It is available on www.linktechs.net Below is a chart of the Cambium CPE Reversed Power Pin Out...
