Summary of Contents for Tenaris ULTRA SF
- Page 1 IPSCO CONNECTIONS RUNNIG MANUAL ULTRA SF & SFII IPSCO CONNECTIONS RUNNING MANUAL...
- Page 2 ULTRA™ SF & SFII In addition to this section, ensure that all instructions from the GENERAL GUIDELINES section starting on page 9 are followed. Refer to the Pre-run Checklist on page ¡Error! No se encuentra el origen de la referencia.¡Error! No se encuentra el origen de la referencia.¡Error! Marcador no definido.¡Error! No se encuentra el origen de la referencia.
- Page 3 Interchangeability ULTRA™ SF and SFII are neither compatible between both connections nor interchangeable between different weights of the same connection and nominal OD. A crossover is needed if running a mixed weight string or accessories. Features ULTRA™ SF and SFII connections have unique run-in and run-out threads on the pin and box: ...
- Page 4 This area may or may not be prominent depending on the actual pipe diameter on which the connection is threaded. This area will decrease in length as delta torque is applied. This feature is there to allow the box to make up over the machined surface and it is not intended as a make-up indicator.
- Page 5 Thread Compound Application Tenaris recommends the use of thread compounds that meet or exceed ISO 13678 or API RP 5A3 requirements. The use of an applicator “moustache” brush is recommended for the box and a paintbrush for the pin to best control the application and quantity of thread compound.
- Page 6 Care is to be taken to prevent thread compound from going into the pin and box center shoulder seal groove to avoid dope squeeze and anomalies in the torque turn graph. Make-up Torque ULTRA™ SF and SFII connections shall be made up to the torque specified on the most current Connection Data Sheet.
- Page 7 Downhole Rotation Tenaris recommends using the minimum amount of torque necessary to break the friction between the tubing or casing and the well bore if downhole rotation of the string is required. The minimum make-up torque is the safest downhole rotating torque. This will ensure that the connection can be broken out and made up again.
- Page 8 Field Repair Field repair of ULTRA™ SF and SFII connections shall only be conducted by Field Service Technicians certified by Tenaris. Minor tears, galls, dents or burrs on the thread profile may be able to be repaired by qualified personnel in the field.
- Page 9 IPSCO CONNECTIONS RUNNING MANUAL...
