Thank you for choosing ZHUHAI VINO ENVIRONMENTAL TECHNOLOGY EQUIPMENT

CO., LTD, please read this owner's manual carefully before operation and retain it for

future reference.

Split AirConditioner

ESC09WMA1A/ES5FX09A

ESC12WMA2A/ES5FX12A

ESC18WMA3A/ES5FX18A

Table of Contents

Need help?

Do you have a question about the ESC09WMA1A/ES5FX09A and is the answer not in the manual?

Questions and answers

Summary of Contents for ENER-SAVE ESC09WMA1A/ES5FX09A

Page 1 Split AirConditioner ESC09WMA1A/ES5FX09A ESC12WMA2A/ES5FX12A ESC18WMA3A/ES5FX18A Thank you for choosing ZHUHAI VINO ENVIRONMENTAL TECHNOLOGY EQUIPMENT CO., LTD, please read this owner’s manual carefully before operation and retain it for future reference.
Page 2 Appliance filled with flammable gas R290. Caution, risk of fire Before use the appliance, read the owner’s manual first. Before install the appliance, read the installation manual first. Before repair the appliance, read the service manual first. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
Page 4 Annex CC (informative) Transportation, marking and storage for units that employ flammable refrigerants The following information is provided for units that employ flammable refrigerants. ● CC.1 Transport of equipment containing flammable refrigerants Attention is drawn to the fact that additional transportation regulations may exist with respect to equipment containing flammable gas.
Page 5: Table Of Contents
Content Operation Notices Precautions......................1 Parts name......................4 Operation Guide Operation guide..................... 6 Remote controller....................7 Bottons on remote controller................8 Maintenance Clean and maintenance..................14 Malfunction Malfunction anaysis....................16 Safety operation Safety operation of flammable refrigerant............20 Installation Notice Installation drawing....................22 Safety precautions for installing and relocating the unit.........23 Installation prepare....................24 Installation Installation of indoor unit..................26...
Page 6: Precautions
Precautions Operation and Maintenance This appliance is not intended for use by persons (including chindren) with reduced ● physical, sensory or mental capabilities, or lack of experience and knowledge,unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 7 Precautions If the air conditioner operates under abnormal conditions, it may cause malfunction, ● electric shock or fire hazard. When turning on or turning off the unit by emergency operation switch, please press ● this switch with an insulating object other than metal. Do not step on top panel of outdoor unit, or put heavy objects.
Page 8 Precautions Installation must be performed in accordance with the requirement of NEC and CEC ● by authorized personnel only. The air conditioner is the first class electric appliance. It must be properly grounding ● with specialized grounding device by a professional. Please make sure it is always grounded effectively, otherwise it may cause electric shock.
Page 9: Parts Name
Parts Name Indoor unit: Outdoor unit: Note: Actual product may be different from above graphics, please refer to actual products.
Page 10 Parts Name Remote controller: Display: Temp.indicator Power indicator...
Page 11: Operation Guide
Operation Guide Installation batteries 1. Press the back side of remote controller,as shown in the fig, and then push out the cover of battery box along the arrow direction. 2. Install two 7#(AAA1.5V) dry batteries, and make sure the position of “+” polar and “-” polar are correct.
Page 12: Remote Controller
Remote Controller I feel I feel button Health button ECO button...
Page 13: Bottons On Remote Controller
Buttons on Remote Controller After connecting the power, the air conditioner will be make a sound. Power indicator is NO.After that, you can operate the air conditioner by using remote controller. In state of turning on, pressing the button on the remote controller, the air conditioner will make a “beep”...
Page 14 Buttons on Remote Controller Fan button Press this button can set fan speed circularly as: auto(AUTO), fan1( ), fan2( Fan3( ), fan4( ), fan5( ), turbo( ), stepless speed. Note: In AUTO speed, air conditioner will select proper fan speed automatically according ●...
Page 15 Buttons on Remote Controller button Press this button can select left&right swing angle. Fan blow angle can be selected circularly as below: Note: When convert “NO display” into “ ” status, if press this button after 2s, swing ● status directly turns into “NO display”; if press this button within 2s, swing status changes according to the above order.
Page 16 Buttons on Remote Controller Sleep button Press this button to turn on or turn off the sleep function under cooling, dry, heating mode. Note: This function is off as defaulted after power on. ● It will be cleared after changing mode. ●...
Page 17 Buttons on Remote Controller temperature according to the detected temperature. Press this button again to close i feel function and “ ” will disappear. Note: Please put the remote controller near user and confirm the unit can receive the remote code when this function is set.
Page 18 Buttons on Remote Controller 2. Temperature display switchover function In the off mode, press “ ” and “ ” buttons simultaneously to switch temperature display between °C and °F . 3. Low temperature heating function setting In heating mode, pressing “ ”...
Page 19: Clean And Maintenance
Clean and Maintenance Turn off the air conditioner and disconnect the power before cleaning the air ● conditioner to avoid electric shock. Do not wash the air conditioner with water to avoid electric shock. ● Do not use volatile liquid to clean the air conditioner. ●...
Page 20 Clean and Maintenance Note: The filter should be cleaned every three months. If there is much dust in the operation ● environment, clean frequency can be increased. After removing the filter, do not touch fins to avoid injury. ● Do not use fire or hair dryer to dry the filter to avoid deformation or fire hazard. ●...
Page 21: Malfunction Anaysis
Malfunction Analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still can’t be eliminated, please contact local dealer or qualified professionals. Phenomenon Check items Solution Whether it’s interfered severely Pull out the plug. Reinsert the ( such as static electricity, stable plug after about 3min, and then voltage)?
Page 22 Malfunction Analysis Phenomenon Check items Solution Because indoor air is cooled Mist is emitted from Indoor temperature and humidity rapidly. After a while, indoor indoor unit’s air is high? temperature and humidity will be outlet. decrease and mist will display. Temperature can’t be adjusted Unit is operating under auto under auto mode.
Page 23 Malfunction Analysis Error Code When air conditioner status is abnormal, temperature indicator on indoor unit will blink to display corresponding error code. Please refer to below list for identification of error code. Note: Above indicator diagram is only for reference. Please refer to actual product for the actual indicator and position.
Page 24 Malfunction Analysis Contact us When below phenomenon occurs, please turn off air conditioner and disconnect power immediately, and then contact the dealer or qualified professionals for service. Power cord is overheating or damaged. ● Air conditioner gives off burning smell. ●...
Page 25: Safety Operation Of Flammable Refrigerant
Safety operation of flammable refrigerant Qualification requirement for installation and maintenance All the work men who are engaging in the refrigeration system should bear the ● valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant.
Page 26 Safety operation of flammable refrigerant Welding If you should cut or weld the refrigerant system pipes in the process of maintaining, ● please follow the steps as below: a. Shut down the unit and cut power supply b. Eliminate the refrigerant c.
Page 27: Installation Drawing
Installation Drawing...
Page 28: Safety Precautions For Installing And Relocating The Unit
Safety precautions for installing and relocating the unit To ensure safety, please be mindful of the following precautions. When installing or relocating the unit, be sure to keep the refrigerant ● circuit free from air or substances other than the specified refrigerant. Any presence of air or other foreign substance in the refrigerant circuit will cause system pressure rise or compressor rupture, resulting in injury.
Page 29: Installation Prepare
Installation Prepare Tools 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 12 Universal meter 13 Inner hexagon spanner 14 Measuring tape Selection of location Basic requirement...
Page 31: Installation Of Indoor Unit
Installation of Indoor unit Step 1: Choosing installation location Recommend the installation location to the client and then confirm it with the client. Step 2: Install wall-mounting frame 1. Hang the wall-mounting frame on the wall; adjust it in horizontal position with the level meter and then point out the screw fixing holes on the wall.
Page 32 Installation of Indoor unit Step 4: Outlet pipe 2. When select leading out the pipe from 1. The pipe can be led out in the left or right, please cut off the direction of right, near right or left. corresponding hole on the bottom case. rear right right Step 5: Connect the pipe of indoor unit...
Page 33 Installation of Indoor unit Step 6: Install drain hose 1. Connect the drain hose to the outlet pipe of indoor unit. 2. Bind the joint with tape. drain outlet hose pipe Add insulating pipe in the indoor drain hose in order to prevent condensation. ●...
Page 34 Installation of Indoor unit Step 8: Bind up pipe 1. Bind up the connection pipe, power cord and drain hose with the band. 2. Reserve a certain length of drain hose and power cord for installation when binding them. When binding to a certain degree, separate the indoor power and then separate the drain hose.
Page 35: Installation Of Outdoor Unit
Installation of Outdoor unit Step 1: Fix the support of outdoor Select it according to the actual installation situation. 1. Select installation location according to the house structure. 2. Fix the support of outdoor unit on the selected location with expansion screws. Note: Take sufficient protective measures when ●...
Page 36 Installation of Outdoor unit Step 4: Connect indoor and outdoor pipe 2. Remove the screw cap of valve and 1. Remove the screw on the right handle of aim the pipe joint at the bellmouth outdoor unit and then remove the handle. of pipe Tighten the union nut with torque 3.
Page 37 Installation of Outdoor unit Step 6: Neaten the pipes 1. The pipes should be placed along the wall, bent reasonably and hidden possibly. Min.semidiameter of bending the pipe is 10cm. 2. If the outdoor unit is higher than the wall hole, you must set a U-shaped curve in the pipe before pipe goes into the room, in order to prevent rain from getting into the room .
Page 38 Installation of Outdoor unit Step 7: Vacuum pumping Use vacuum pump 1. Remove the valve caps on the liquid valve and gas valve and the nut of refrigerant charging vent. 2. Connect the charging hose of piezometer to the refrigerant charging vent of gas valve and then connect the other charging hose to the vacuum pump.
Page 39: Check After Installation
Check after Installation Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been installed firmly? The unit may drop, shake or emit noise. It may cause in sufficient cooling(heating) Have you done the refrigerant leakage test? capacity.
Page 40: Configuration Of Connection Pipe
Configuration of connection pipe 1. Standard length of connection pipe ● 5m, 7.5m ,8m 2. Min.length of connection pipe is 3m 3. Max.length of connection pipe and max.high difference. Cooling Max length of Max height Cooling Max length of Max height capacity connection pipe difference...
Page 41: Pipe Expanding Method
Pipe expanding method Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps: A:cut the pipe E:Expand the port Confirm the pipe length according to the Expand the port with expander. distance of indoor unit and outdoor unit.
Page 42: Maintenance Safety Precautions
Maintenance Information on servicing Checks to the area ● Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
Page 43: Maintenance
Maintenance The following checks shall be applied to installations using flammable refrigerants: – The charge size is in accordance with the room size within which the refrigerant containing parts are installed; – The ventilation machinery and outlets are operating adequately and are not obstructed; –...
Page 44 Maintenance Note: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment. Intrinsically safe components do not have to be isolated prior to working on them. Repair to intrinsically safe components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use.
Page 45 Maintenance If a leak is suspected, all naked flames shall be removed/ extinguished. If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system, or isolated (by means of shut off valves) in a part of the system remote from the leak.
Page 46 Maintenance leak tested on completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site. Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail.
Page 47 Maintenance Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available.
Page 48: Specifications
Specifications Unit Specifications INDOOR UNIT ESC09WMA1A ESC12WMA2A ESC18WMA3A MODEL OUTDOOR UNIT ES5FX09A ES5FX12A ES5FX18A Btu/h 9,000 12,000 18,000 TOTAL COOLING CAPACITY 2,638 3,517 5,275 INPUT POWER 1030 1600 RUNNING CURRENT 3.42 4.57 7.10 Wh/Wh 3.43 3.41 3.30 POWER SOURCE V/Ph/Hz 220-240/1/50 REFRIGERANT TYPE...
Page 49 ZHUHAI VINO ENVIRONMENTAL TECHNOLOGY EQUIPMENT CO., LTD Unit 3-B, Building 4, Zhongdian high tech industrial park, 7th technology road, Tangjiawan town, Xiangzhou District, Zhuhai City, China...
