Summary of Contents for ERICSON UVC-PKCART-ULTRA
- Page 1 UVC-PKCART-ULTRA Surface Disinfection Unit QUICK START GUIDE Models: UVC-PKCART-ULTRA...
- Page 2 MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE CREATED BY THE DESCRIPTIONS AND DEPICTIONS OF THE PRODUCTS SHOWN IN THIS MANUAL. Ericson makes no warranty (and assumes no liability) as to function of equipment or operation of systems built according to customer design or of the ability of any of its products to interface, operate or function with any portions of customer systems not provided by Ericson.
- Page 3 INDEX Advisories (Purpose/Contents) Page 4 Safe Operation Procedure Page 5 Safety Guidelines Page 5 System Description Page 6 System Delivery Page 7 Operation Overview Page 7 Operation Settings (Default) Page 8 Operation Settings (Customizable) Page 8 Cycle Stop Status Screens Page 9 System Care Page 10...
- Page 4 ADVISORIES Purpose Contents The Ericson UV-C Perma-Kleen Cart (PK-CART) system has This manual will serve as your reference guide for been designed to offer direct disinfection exposure to surface installation, operation, and service of your UV-C Perma-Kleen areas. The system design allows for microbial disinfection Cart (PK-CART).
- Page 5 Therefore, there are no OSHA-mandated employee exposure limits to ultraviolet The Ericson PK-CART is designed for zero user exposure to radiation. UV-C; however, we will review safety factors regarding UV-C for better knowledge and understanding.
-
Page 6: System Description
SYSTEM DESCRIPTION The Ericson PK-CART is designed for maximum disinfection through the shortest exposure time. More UV-C wattage allows shorter exposure times to surfaces. Exposure times vary based on furthest distance from the UV-C source. The system design provides the optimum in: UV dosage output to footprint served •... - Page 7 Please perform the following procedure: 1. Unpack your new system and stand upright 2. Inspect fully for damage (If damage present, contact Ericson prior to use at 1-(800)ERICSON) 3. Verify secure lamp installation 4. Plug in system power cord 5. Do not activate unit without reading and adhering to instructions below.
-
Page 8: Operation Settings
OPERATION SETTINGS Normal operation for factory default settings are covered on this page. 1. Review system for condition. a. There should be no physical damage to the system b. Lamps should be clean c. System frame should be in good condition d. - Page 9 OPERATION SETTINGS Room Sensing Feature The PK-CART ULTRA is equipped with Room Sensing 3. Cycle time is displayed on Room Sensing screen and Technology in which the device will calculate the distance can be observed automatically adjusting with movement between walls and calculate the required machine run-time of the machine and selection of target Operation mode depending on Operation Mode (Bacteria or Spores) selected.
- Page 10 Observe the alert type on the control panel Select HOME button to resume normal system operation Ensure all system alerts have been properly addressed Should Alarm persist, contact Ericson customer service Select HOME button to return to main screen 1.800.ERICSON.
-
Page 11: System Care
SYSTEM CARE The Ericson PK-CART system is designed for repeat performance with consistent results. Based on system designs, minimal maintenance is required. Adherence to the following regular service of your system should provide years of disinfection. Each Duty Cycle 1. Inspect the system interior, exterior, and lamps for clean conditions 2. -
Page 12: Frequently Asked Questions
A: Verify the start cycle button is pressed A: Inspect the lamp for age or physical failure A: Contact Ericson Support for further information Q: My system is running fine, how do I verify the lamp output is correct? A: The system has a status screen at the end of the cycle A: Use dosimeter cards in the space to verify UVC dosage. -
Page 13: Troubleshooting And Faq
TROUBLESHOOTING & FAQ The below statements are listed as troubleshooting guidelines. Further information is available through Ericson support. Q: Is UV-C disinfection strictly line of sight? A: Yes, it needs to shine on the surface to disinfect. It will not go around objects or disinfect shadowed areas. -
Page 14: Appendix A: Dose Guidelines
APPENDIX A: DOSE GUIDELINES Ericson Model: ULTRA & MAX MAX LP UV-C Wattage: Time: Time in Minutes Time in Minutes Time in Minutes Feet Room Room *Time in Time in *Time in Time in *Time in Time in From Dims...
