Gerjak Dear Customer,
We would like to wish you much pleasure with your new Gerjak product.
We very much appreciate that you have chosen our product! Following are some hints and tips to
give you pleasure for years to come with your Gerjak Annexe.
Please note that it is advisable to set up your new awning and check it before you go on vacation.
This will make for easier assembly at the site of your destination.
You will find below information that includes:
• Pre assembly checks and roof pole hook attachments.
• Trap Spanner, Robuusta hostelry, Corner Tie Downs.
• The use of zippers and unpacking the frame.
• Setting up the tent/annexe.
• Maintenance and cleaning tent material, windows & frame.
• Condensation, mildew and stains fight, wear zipper
Is the caravan rail in order?
To avoid damaging the tendon of the awning and to ensure best use of your awning, inspect the
caravan rail for unevenness and look for sharp protrusions.
Is everything in place?
Make sure all standard accessories are in the boxes delivered, such as: Tent, frame, pipe clamps,
hook pads, draft skirt and wheel arch cover, curtains.
Clip-on System or Roof Pole Hook Pads
All tents are equipped with a double tendon. The thickest tendon should make to slide through the
skirting rail on the caravan. The extra tendon is used for the clip-on cubes which attach to the (3)
roof pole hooks. The cubes are supplied for used on selected models only.
Through the rail, you are free each time to choose where to place the rafters. This can be important
if, for example you are setting up on sloping terrain.
The clip-on cubes or suction hook pads are ideally situated right and left at about 200-210 cm from
the ground. Clip-on cubes need to be pinched to open (like a clothes pin) and attached to the thinner
tendon. Then you can lock the block by turning the screw.
See pictures on following page-
Advertisement
Table of Contents
Summary of Contents for Gerjak Annexe
- Page 1 Gerjak Dear Customer, We would like to wish you much pleasure with your new Gerjak product. We very much appreciate that you have chosen our product! Following are some hints and tips to give you pleasure for years to come with your Gerjak Annexe.
- Page 2 Once in position the leg can be adjusted to achieve the correct roof height and tension. Robuusta afspanning Gerjak tents feature sturdy afspannig Robuusta. This allows you to tightly tension your tent. No more fiddling with loose elastic. In your accessories bag, you will find the corresponding blocks...
- Page 3 As a result, the possibility exists to use the zippers as a door or as a zipper to attach a veranda. Tie Down Straps The Gerjak tents have on the outside edges a feature called Tie Down Straps. These allow added tightening of the tent and for the corners to be properly secured. When setting, it is therefore desirable to first tighten the corners so you get a square before then tightening down the intermediate pegs.
- Page 4 Unpacking/identifying the frame The easiest way is to take the frame components from the bag and sort through them piece by piece to identify the different items. By doing this it soon becomes clear as to where many pieces need to be positioned in order to fit together.
- Page 5 Setting up the tent 1. Turn your caravan level. 2. Place frame according to drawing on the site. 3. Check your rail unevenness to prevent damage to your awning. 4. First remove the detachable walls of the tent. This helps to make it lighter and easier to manage. 5.
